StarTech.com WIFI2HDVGAGE Manuale utente

Manual Revision: 03/19/2019

User Manual

For the latest information and specications visit

www.startech.com/WIFI2HDVGA

www.startech.com/WIFI2HDVGAGE

Presentation Hub for Wireless Video

Actual product may vary from photos

SKU#: WIFI2HDVGA/WIFI2HDVGAGE

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Compliance Statements

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class

B digital device, pursuant to part 15 of the FCC Rules. These limits are designed

to provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may

cause harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation. If this

equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment o and on, the user is

encouraged to try to correct the interference by one or more of the following

measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment and receiver

• Connect the equipment into an outlet on a circuit dierent from that to

which the receiver is connected

• Consult the dealer or an experienced radio/TV technician for help

Industry Canada Statement

This Class B digital apparatus complies with Canadian ICES-003.

Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du

Canada.

CAN ICES-3 (B)/NMB-3(B)

Use of Trademarks, Registered Trademarks, and other

Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and

other protected names and/or symbols of third-party companies not related in

any way to StarTech.com. Where they occur these references are for illustrative

purposes only and do not represent an endorsement of a product or service

by StarTech.com, or an endorsement of the product(s) to which this manual

applies by the third-party company in question. Regardless of any direct

acknowledgement elsewhere in the body of this document, StarTech.com

hereby acknowledges that all trademarks, registered trademarks, service marks,

and other protected names and/or symbols contained in this manual and

related documents are the property of their respective holders.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Safety Statements

Safety Measures

• Wiring terminations should not be made with the product and/or electric

lines under power.

• Cables (including power and charging cables) should be placed and routed

to avoid creating electric, tripping or safety hazards.

Mesures de sécurité

• Les terminaisons de câblâge ne doivent pas être eectuées lorsque le produit

et/ou les câbles électriques sont sous tension.

• Les câbles (y compris les câbles d’alimentation et de chargement) doivent

être placés et acheminés de façon à éviter tout risque électrique, de chute ou

de sécurité

安全対策

• 電源が入っている状態の製品または電線の終端処理を行わないでくださ

い。

• ケーブル（電源ケーブルと充電ケーブルを含む）は、適切な配置と引き回し

を行い、電気障害やつまづきの危険性など、安全上のリスクを回避するよう

にしてください。

Misure di sicurezza

• I terminiali dei li elettrici non devono essere realizzate con il prodotto e/o le

linee elettriche sotto tensione.

• I cavi (inclusi i cavi di alimentazione e di ricarica) devono essere posizionati

e stesi in modo da evitare pericoli di inciampo, rischi di scosse elettriche o

pericoli per la sicurezza.

Säkerhetsåtgärder

• Montering av kabelavslutningar får inte göras när produkten och/eller

elledningarna är strömförda.

• Kablar (inklusive elkablar och laddningskablar) ska dras och placeras på så

sätt att risk för snubblingsolyckor och andra olyckor kan undvikas.

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Table of Contents

Compliance Statements........................................................................1

Safety Statements..................................................................................2

Product Diagram ....................................................................................5

Front View.................................................................................................................................................... 5

Side View...................................................................................................................................................... 5

Rear View...................................................................................................................................................... 6

Bottom View................................................................................................................................................ 6

Product Information ..............................................................................7

Packaging Contents ................................................................................................................................. 7

System Requirements.............................................................................................................................. 7

Installation ..............................................................................................8

Connecting the Presentation Hub...................................................................................................... 8

Connecting to a Wired Network .......................................................................................................... 8

Connecting to a Wireless Network...................................................................................................... 9

Disconnecting from a Wireless Network........................................................................................... 9

WebUI.......................................................................................................10

Accessing the WebUI ............................................................................................................................... 10

Changing the Screen Language.......................................................................................................... 11

Viewing the Presentation Hub Status and General Information.............................................. 13

Conguring Network Settings.............................................................................................................. 15

Creating a Network Bridge .................................................................................................................... 17

Conguring Audio Settings................................................................................................................... 18

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Conguring Video Settings ................................................................................................................... 21

Resetting the Presentation Hub Password ...................................................................................... 23

Conguring Advance Settings ............................................................................................................. 24

Applying a Firmware Update................................................................................................................ 26

Using the Media Remote........................................................................................................................ 27

Restarting the Presentation Hub......................................................................................................... 28

Operation ................................................................................................30

Power On the Presentation Hub.......................................................................................................... 30

Power O the Presentation Hub.......................................................................................................... 30

Firmware Upgrade Button ..................................................................................................................... 30

Resetting the Presentation Hub using the Reset Button............................................................ 30

Boardroom Collaboration Mode..........................................................31

Install nScreenShare on your Computer........................................................................................... 31

Accessing nScreenShare......................................................................................................................... 32

nScreenShare Panel Controls................................................................................................................ 34

Conguring Display Mode..................................................................................................................... 35

Conguring Display Resolution........................................................................................................... 36

Conguring the Display’s Aspect Ratio............................................................................................. 37

Enabling Conference Mode................................................................................................................... 38

Conguring Basic Settings..................................................................................................................... 39

Exiting the nScreenShare App.............................................................................................................. 41

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Diagram

Front View

1USB-A Port

2Power Button

Side View

1Fireware Upgrade Button

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Rear View

1DC 5V Port 5HDMI Port

2TosLink Port 6VGA Port

3Left Audio Port 7RJ45 Port

4Right Audio Port

Bottom View

1Reset Button

1 2 3 4 5 6 7

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Product Information

Packaging Contents

• Presentation Hub x 1

• Universal Power Adapter x 1

• User Manual x 1

System Requirements

Operating system support is subject to change. For the latest

requirements, please visit www.startech.com/WIFI2HDVGA.

• VGA or HDMI® Display with Cabling (i.e. Television, Projector)

For Firmware Upgrade:

• USB Drive

For Boardroom Collaboration Mode:

• One or more Wi-Fi Enabled Computers with:

• Microsoft Windows® 8 / 8.1 (32/64), 7(32/64), Vista (32/64)

• Apple® OSX Yosemite (10.10), Mavericks (10.9), Mountain

Lion (10.8), Lion (10.7), Snow Leopard (10.6)

For Wireless Display Mode:

• WiDi or Miracast Enabled Video Source Device (i.e.

Smartphone, Tablet, or Computer) with:

• Microsoft Windows® 8 / 8.1 (32/64), 7(32/64), Vista (32/64)

• Android (v.4.3 and above)

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Installation

Connecting the Presentation Hub

1. Using the required Video Cable (not included), connect the

Presentation Hub to your VGA or HDMI Display.

Note: The VGA and HDMI Output Ports cannot operate

at the same time. If both of the Ports are connected only the

HDMI Port will function.

2. Connect the Universal Power Adapter to the DC 5V Port

on the Presentation Hub and the other end to an AC Power

Outlet.

3. Press the Power button on the Presentation Hub, to turn it

on.

4. After a few moments the main screen will be displayed.

Connecting to a Wired Network

1. Connect an Ethernet Cable to your Network Device.

2. Connect the other end of the Ethernet Cable to the LAN

Port on the Presentation Hub.

Note: A xed or static IP address cannot be manually as-

signed using the Web GUI. The Presentation Hub will auto-

matically assign an IP address via Dynamic Host Congura-

tion Protocol (DHCP).

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Connecting to a Wireless Network

1. Enter your device’s current IP address to access the Web

GUI, scroll to the bottom of the page and select the Remote

Control link.

- or -

Select the AirFun app, select the Advanced Settings, and

select the Remote Control.

2. Using the Remote Control, select WI-FI Connection and

toggle the WI-FI Connection to On.

3. All available wireless access points will appear on your

Display. Select the wireless access point you would like to

connect to.

4. After the Presentation Hub has successfully connected to

the wireless access point of your choice, the access point’s

name will display in the bottom right hand corner of your

standby screen.

Disconnecting from a Wireless Network

1. Using the Remote Control, select WI-FI Connection and

toggle the WI-FI Connection to O.

2. When the Presentation Hub has successfully disconnected

from the wireless access point, the access point’s name

will disappear from the bottom right hand corner of your

standby screen.

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali StarTech.com Interruttore

StarTech.com

StarTech.com ST7202USBGB Manuale utente

StarTech.com

StarTech.com P2DD46A22-KVM-SWITCH Manuale utente

StarTech.com

StarTech.com ConvergeAV VS410HDMIE Manuale utente

StarTech.com

StarTech.com 5G7AIBS-USB-HUB-EU Manuale utente

StarTech.com

StarTech.com 5G4AIBS-USB-HUB-EU Manuale utente

StarTech.com

StarTech.com P2DD46A2-KVM-SWITCH Manuale utente

StarTech.com

StarTech.com SV431USBAE Manuale utente

StarTech.com

StarTech.com SV231HU34K6 Manuale utente

StarTech.com

StarTech.com SV231DD2DUA Manuale utente

StarTech.com

StarTech.com SV201 Manuale utente

StarTech.com

StarTech.com IESC1G50UP Manuale utente

StarTech.com

StarTech.com DH5102E Manuale utente

StarTech.com

StarTech.com SV431HDU3A2 Manuale utente

StarTech.com

StarTech.com VS221HD2VGA Manuale utente

StarTech.com

StarTech.com STARVIEW SV231DDUSB Manuale utente

StarTech.com

StarTech.com ConvergeAV VS410HDMIE Manuale utente

StarTech.com

StarTech.com VS421HDDP Manuale utente

StarTech.com

StarTech.com SV231DPU Manuale utente

StarTech.com

StarTech.com HB30C5A2CST Manuale utente

StarTech.com

StarTech.com DS254 Manuale del sistema

StarTech.com

StarTech.com BOX4HDECP Manuale utente

StarTech.com

StarTech.com SV221MICRO Manuale utente

StarTech.com

StarTech.com MSTDP122DP Manuale utente

StarTech.com

StarTech.com ICUSB2324I Manuale utente

Manuali Interruttore popolari di altre marche

URC

URC Total Control MFS-8 Manuale utente

Azbil

Azbil HPQ-D11 Manuale utente

Sony

Sony DFS-900M Manuale utente

SICK

SICK i17S Manuale utente

F&F

F&F SZR-277 Manuale utente

Shure

Shure UAMS/BK Manuale utente

Dräger

Dräger X-zone Switch Off Manuale utente

Asco

Asco Joucomatic 349 Series Manuale utente

BT Mini Hub Manuale utente

D-Link

D-Link DES-1226G Manuale utente

Johnson Controls

Johnson Controls FS80-C Manuale utente

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuale utente

MicroNet

MicroNet SP1200A Manuale utente

Ruijie

Ruijie RG-PF2920 Series Manuale di installazione e funzionamento

Altinex

Altinex DA1914SX Manuale utente

MiLAN

MiLAN MIL-SM2401M Manuale utente

RJM

RJM MASTERMIND PBC/6X Manuale utente

Atlas

Atlas MMK-KVM8 Manuale utente
