April 8, 2002

Estate Master

13-2511-12

ESTATE

ESTATE MASTER

• The rear mounted grass box holds 170 litres and can be emptied

without the driver leaving the driving seat.

• A signal indicates when the grass box is full and ready for empty-

ing.

• The narrowercutting deck makes the Mastersuitable for smaller

gardens.

• The Stiga Estate Master is comfortable to drive, has a small turn-

ing circle and cuts close on both sides.

• 72 cm floating cutting deck with central cutting heigth adjust-

ment. There are 7 cutting heights from 30 - 80 mm.

• Reliable, 12.5 hp Briggs & Stratton Quiet I/C engine with electric

start. Removable starting key. The petrol tank holds 4 litres.

• Mechanical gearbox with five forward and reverse gears. Brake

pedal and parking hand brake.

• Accessories: deflector for cutting high grass without a collection

box and front weight.

Estate Master (13-2511-12)

MOTOR

Brand Briggs & Stratton

Power 12,5 hp I/C Quiet

Cylinders 1 - cyl.

Speed 1,5 - 7 km/h

Safety brake Yes

Battery 12 V /18 Ah

FUEL

Type of fuel Petrol

Tank volume 4 l

SPEED CONTROL

Type of transmission Transaxle

Number of gears 5 + R

STEERING

Type of steering Front wheel steering

WHEELS

Type of wheels Lawn tyre tread

Wheel size Front 11'Rear15'''

Bearings Plain

Tyre pressure Front 1,5 bar. Rear 1 bar

Driving Rear wheel drive

CUTTING SYSTEM

Type of cutting system Rear discharge

Cutting heights 30 - 80 mm in 7 steps

Cutting width 72 cm

Cutting height adjustment Central

CONTROLS

Electric starter Yes

Head light No

Gear lever Hand control

MEASURES & WEIGHT

Weight 161 kg

Gross weight 186 kg

Package size W*H*L 80 x 103 x 168 cm

Type of package Carton on wooden pallet

Units on pallet 1

Largest measures W*H*L 76 x 110 x 186 cm

SEAT

Type of seat Comfort seat

Seat adjustable horizontally Yes

OTHER FACTS

CE-mark Yes

EAN bar code 731 332 130 144 6

Other GS-mark
