Studio Logic Numa nano Manuale utente

Instruction Manual

English

NUMA by Studiologic®

Safety Instructions

Important Safety Instructions

DANGER! High Voltage

Risk of electric shock

Do not open chassis. No user serviceable parts inside.

Refer service to qualied service sta only.

Mains

Only use the proper adapter (click-on) for main power supply.

Humidity:

To reduce the risk of re or electric shock do not expose this device to

rain or moisture. Never place containers with liquid on the unit. Do

not use this product near water, e. g. swimming pool, bathtub or wet

basement.

If this device is moved from a cold place to a warm room condensation

can occur inside the unit. To avoid damage please allow the unit to

reach room temperature before switching on.

Installation

Always use a stable rack to place the keyboard on.

Take care of size and weight.

Cleaning / Maintenance

Never use any aggressive detergent. Surface may become stained.

We recommend a slightly moist micro-ber-cloth.

Only use accessories that are speciﬁed by the manufacturer. Follow

the instructions in the manual. Warranty void if unauthorized work

is executed to the NUMA.

Read the entire manual. There you ﬁnd all the information needed

for using this device.

instruction manual

English

instruction manual

NUMA by Studiologic®

Editing is handled by the Easy Control System with a backlit

LCD display and touch-sensitive pads. Play Mode gives you

direct access to the most important parameters - perfect for

quick changes on stage.

Edit Mode oers more detailed changes to all parameters

that can be saved in 65 patches (presets).

What‘s really unique about the NUMA is the so called You-

Play Mode, which allows you to create your own velocity

curves and save them to 15 presets. These customized

curves are available to every patch then.

Due to the integrated USB connection, the NUMA can com-

municate with a computer. It oers two modes of operation:

With USB MIDI the NUMA is recognized as a„USB-Audio-

Device“ by the computer. More interesting is the USB Virtual

Com mode, enabling the computer to edit and store presets.

Even an update of the NUMA operating system is possible.

1 x MIDI Out (DIN 5-pin)

2 x Pedal (TS-Jack)

1 x USB

1 x Power Supply (9V– / 500 mA)

NUMA Nano keyboard

External power supply

PS -100 Sustain pedal

Perspex music stand

User manual

Overview

Easy Control System

Play Mode

Edit Mode

YouPlay Mode

Interactive NUMA

USB <> Computer

Connections

Scope of supply

instruction manual

English

NUMA by Studiologic®

Edit Mode

In Edit Mode you can make very detailed changes and create

new patches.

These are the single parameters, available for each zone:

Midi

Selecting the right MIDI-Channel (1-16)

Program Change

Assigning the sounds of external Sound modules

Key Range

Adjusting the Zone-Area (A0 - C8)

Volume

Setting up the volume(s) (0-127)

Transpose

Adjusting the pitch (-24 bis +24)

Play Mode

Selecting the basic mode

Shapes

Setting up the dynamics envelope

Wheel Control

Choosing the operation of the modulation-wheel (free)

Aftertouch Control

Setting up the Aftertouch details

Control Jack 1

Choosing the operation of Control Jack 1

Control Jack 2

Choosing the operation of Control Jack 2

Store

How to save changes and creating a new patch

Patch Name

How to edit the patch name

System

Displays the system wide settings:

Software Version, LCD-Contrast, sensitivity and speed of

the Virtual Dial.

Edit Mode

is activated by touching both pads 34 simultaniously. The

display now shows Edit, the respective parameter and the

patch name.

Selecting pages is handled by the pads34 , navigation on a

single site is with touching 5 6 , choosing the zones is with

the 4 Control Keys, parameter changes are done with the

Virtual Dial.

All following examples and images are based on factory

patch F04.

Touching both 34 gets you out of the Edit Mode again -

don‘t forget to save your changes!

•

Edit Mode Overview

Page 8

Page 9

Page 10

Page 11

Page 12

instruction manual

English

instruction manual

NUMA by Studiologic® 5

Operation of the NUMA Nano is done with 4 touch-sensitive pads,

a virtual dial and the LCD display.

While in Play ore Edit Mode, these pads select the single

pages for dierent parameters.

Touching both simultaneously activates the Edit Mode.

Selecting a patch in Play Mode is done with these two pads.

In Edit Mode they select the sub-pages.

Control Keys 1-4 activate the corresponding parameter

above the pad. For example Zone, Reset, Store, No or Yes.

Touching both u+v

simultaneously activates the YouPlay

Mode. The combination of w+x

initializes a reset of all MIDI

data.

The Virtual Dial selects the patches in Play Mode and changes

the selected parameter in Edit Mode.

Operation

u v w x

Control Keys

Virtual

Dial

Navigation

left

Navigation

right

Navigation

down

Image 1

Control Elements

Navigation

5 6

Control Keys

u v w x

Virtual Dial

instruction manual

English

NUMA by Studiologic®

After power-up (Image 2) the NUMA Nano automatically loads a

patch in Play Mode. This patch is the last one used in a saved

Edit-Mode (page 13).

Play-Mode: Possible changes

Loading Patches

Using the pads 5 6 (Image 3a) or the Virtual Dial ¢

(Image 3b) you can select single Patches. The sequence is in

numerical order, Factory-Patches (F01 up to F05) are followed

by User-Patches (001 up to 064). Only already used patches

are displayed. This prevents you from searching through not

used patches.

Note: Patches are immediately active, no need for an extra

conrmation!

Factory-Patches cannot be erased.

Zones On/O

Control Keys u-xcan be used for direct access to Zone On/

O. The corresponding state is illustrated through an active

(on) or cancelled (o) loudspeaker.

Image 4 shows:

Play Mode

Factory-Patch F04

Zone 2 o

Zone 3 o

Quick-Edit of Patches (Live-Edit)

The arrow pads 34 give you access to the basic parameters

of a patch and the particular zones.

The following parameters can be changed:

Patch Midi

Choosing the MIDI-Channel (1-16)

Patch Program

Choosing the Program (0-127)

Patch Volume

Adjusting the volume (0-127)

Patch Transpose

Adjusting the pitch (-24 bis +24)

All settings are separate for each zone and are only eective

for the active patch.

Note: Changes made in Play-Mode are not saved!

Permanent changes can only be made in Edit Mode.

•

Play Mode

Image 2

Image 3a

Image 3b

instruction manual

English

instruction manual

NUMA by Studiologic® 7

Example:

Choose patch F04 with the pads 5 6 . Try to switch the

respective zone on and o, using the Control Keys u-x.

At last, leave On Zone 1 and 4 (Image 4).

Now touch pad 4 :

The display changes the upper row to Patch Midi, the line

above the zones shows the respective MIDI channel.

Now touch pad xtwo times.

The display (Image 5) shows Patch Volume in the upper

row. Now you can change the volume of all zones with the

Virtual Dial ¢.

If you want to change the volume of zone 4 only, then you

have to select it with pad x rst. The display now pictures

Zone Volume and zone 4 gets activated (Image 6). Volume of

zone 4 can be changed with the Virtual Dial ¢ . Deselecting

zone 4 results in changes to all zones at once.

This procedure is the same for all other parameters. Feel free

to try dierent setups (Image 7-8).

Note: Do not forget that changing the patch-preset resets all

currently made settings!

How to store changes >> Page 12

To get out of the Live-Edit-Mode -

just touch one of the pads 5 6 .

Play Mode Example

Image 4

Image 5

Image 6

Image 7

Image 8

instruction manual

English

NUMA by Studiologic® 9

Midi

This is where you can setup the right MIDI-Channel for every

zone. Range is from 1 to 16. If you choose„0“, the zone gets

inactive and won‘t be displayed on other pages (Image 9).

Program Change

Assigning the preset of an external sound generator to a

Numa zone is done with the parameters Program Change,

LSB Bank Select und MSB Bank select.

Three sub-pages (Image 10-11-12) can be selected with pads

5 6 and displayed in the top row. Values are„O“ and „0“ up

to„127“.

Please check the manual of your external sound-module to

nd out which sound is on which preset.

Key Range

It´s very easy to split the Numa keyboard into 4 separate

Zones. Choose one zone with the corresponding Control Key

u-x. Now press the rst and the last key of the desired

Range - done.

The display gives you a feedback of your selection (Image 13).

Range is from A0 up to C8.

Edit Mode Part 1

Image 9

Image 10

Image 11

Image 12

Image 13

instruction manual

English

instruction manual

NUMA by Studiologic®

Edit Mode Part 2

Volume

On this page you can adjust the Volume of each zone. The

range is „0“ up to „127“ (Image 14).

Note: Changing one parameter for all zones, at the same

time, is not possible in Edit Mode.

Transpose/Octave:

Transpose (Image 15) for changing the pitch for ± 2 octaves

octave steps.

Selecting a sub-page is handled via the pads .

Note: Both parameters can be combinedbut, the maximum

change is ± 2 Octaves.

Play Mode

This mode enables you to assign an individual dynamic to

each zone: Dynamic, Organ.

Shapes

PlayModes

(Image 17):

Dynamic

Three factory presets (Soft, Medium, Hard) and

15 User-Presets are possible.

Organ

Only one setting without dynamic.

How to create your own dynamic curves is explained on

page 14.

•

Image 14

Image 15

Image 16

Image 17

instruction manual

English

NUMA by Studiologic® 11

Edit Mode Part 3

Wheel Control/Polarity

This page for the Modulation-Wheel is divided in two

sections: Wheel Control and Polarity (Image 18-19). The

selection is handled via the two pads 5 6 , and - as always -

via the Virtual Dial ¢ .

Wheel Control enables the following parameters:

O

Modulation wheel is out of operation

Pitch

Make pitch changes with the modulation wheel

C#0-C#127

Moving the wheel generates a control change command

from 0 up to 127

The Polarity parameter denes the direction of the changes.

Pol.+ for an upward change, or Pol.- for a downward change.

Note: Any changes will take place only after a full movement

of the Modulation-Wheel.

Aftertouch Control / Polarity

Again you can nd two settings here for Aftertouch control

(Image 20) :

O

No Aftertouch at all

AFT

This activates the standard aftertoch of the external

sound module.

C#0-C#127

The changing parameter can be assigned to a control

change command.

The direction of the change is controlled with Aftertouch

Polarity (Image 21).

Note:The Aftertouch function is monophon.

•

Image 21

Image 20

Image 19

Image 18

Indice

Altri manuali Studio Logic Tastiera elettronica

Studio Logic

Studio Logic VMK-149 Manuale utente

Studio Logic

Studio Logic TMK-88 Manuale utente

Studio Logic

Studio Logic numacompact Manuale utente

Studio Logic

Studio Logic Numa Compact 2 Manuale utente

Studio Logic

Studio Logic SL88IGRAND Manuale utente

Studio Logic

Studio Logic TMK-49 Manuale utente

Studio Logic

Studio Logic SL-990 PRO Manuale utente

Studio Logic

Studio Logic PLS-49 Manuale utente

Studio Logic

Studio Logic VMK-88 plus Manuale utente

Studio Logic

Studio Logic acuna88 Manuale utente

Studio Logic

Studio Logic SL-990 Manuale utente

Studio Logic

Studio Logic SL-760 Manuale utente

Studio Logic

Studio Logic TMK-61 Manuale utente

Studio Logic

Studio Logic CMK-149 Manuale utente

Studio Logic

Studio Logic VMK-88 plus Manuale utente

Studio Logic

Studio Logic SL-880 Manuale utente

Studio Logic

Studio Logic MP-113 Manuale utente

Studio Logic

Studio Logic numaorgan2 Manuale utente

Studio Logic

Studio Logic SL-161 Manuale utente

Studio Logic

Studio Logic NUMACOMPACT 2 Manuale utente

Studio Logic

Studio Logic CMS-161 Manuale utente

Studio Logic

Studio Logic SL-1100 Manuale utente

Studio Logic

Studio Logic SL-2001 Manuale utente

Studio Logic

Studio Logic SL-161 Manuale utente

Manuali Tastiera elettronica popolari di altre marche

Casio

Casio LK-50 Guida alla configurazione

Casio

Casio VZ-1 Guida alla risoluzione dei problemi

Casio

Casio Privia PX-100 Manuale utente

Yamaha

Yamaha PortaTone PSR-225GM Manuale utente

Behringer

Behringer U-CONTROL UMX49 Manuale utente

Yamaha

Yamaha Portatone X2500 Manuale utente

Yamaha

Yamaha Portatone PSR-100 Manuale utente

Casio

Casio WK-1600 Manuale utente

Keith McMillen Instruments

Keith McMillen Instruments K-Board Pro 4 Scheda tecnica

Yamaha

Yamaha PortaSound PCS-30 Manuale utente

Roland

Roland Juno-6 Manuale utente

McGrey

McGrey 6170 Manuale utente

Yamaha

Yamaha PortaTone PSR-41 Manuale utente

HDC

HDC Kurzweil KP300X Manuale utente

Casio

Casio Celviano AP-45 Manuale utente

Akai

Akai MPK88 Manuale utente

Waldorf

Waldorf IRIDIUM Manuale utente

Yamaha

Yamaha NP-30 Istruzioni per il montaggio
