SUBARU OF AMERICA PAGE
1/4
DATE
07/08/23
ISSUE
00
PART NUMBER
H621SFG000
IMPREZA
PART NUMBER: H621SFG000 (UF-909U-01)
DESCRIPTION: SIRIUS-SATELLITE RADIO KIT
INSTALLATION
INSTRUCTIONS
: Remove
: Install
: Disconnect
: Connect
: Location of Clip or Screw
: Tightening Torque
: Loosen
: Discard
: Reuse
T
A B C
D E F
H I J
MEANING of Characters:
TOOLS REQUIRED:
KIT CONTENTS:
1 X 1 X 1 X
1 X
1 X
1 X
5 X 4 X 2 X
284-1040-01
Nylon trim
removal tool
K
7 X
G
A
D
J
C
EIH
FKA
SUBARU OF AMERICA PAGE
2/4
DATE
07/08/23
ISSUE
00
PART NUMBER
H621SFG000
1 2
3 4
5 6
Ignition switch should be off when
disconnecting negative battery terminal.
NOTE
IMPREZA
Starting from bottom, pry carefully along edges.
NOTE
A
F
E
30mm
SUBARU OF AMERICA PAGE
3/4
DATE
07/08/23
ISSUE
00
PART NUMBER
H621SFG000
7 8
9
11
IMPREZA
300 mm200 mm 300 mm
I
BI
10
12
SUBARU OF AMERICA PAGE
4/4
DATE
07/08/23
ISSUE
00
PART NUMBER
H621SFG000
IMPREZA
14
I
G
13
Reassembly: 21
Torque value 7.5N-m (5.5 ft-lb)
NOTE
