Summit CT66BI series Manuale utente

CT66BI 33.25" x 23.63" x 23.5" (H x W x D)

Built-in undercounter refrigerator-freezer with dual

evaporator and cycle defrost

Highlights:

Flexible design for built-in or free-standing use

Slim 24" width fits easily into narrow spaces

Ice cream stays frozen in zero degree freezer

Energy efficient design featuring dual evaporator system

Built-in capability Make the best use of space by installing your refrigerator under the counter and flush with other cabinets

Cycle defrost Combines an automatic defrosting refrigerator with a manual defrosting freezer to save energy but protect

food

Zero degree freezer Keep ice cream frozen and freezer burn-free in a freezer that reaches and maintains zero degrees

Thin-line design Our unique 24" wide models offer full capacity in a slim fit

Adjustable

thermostat Control your food's temperature with ease and accuracy

Interior light Automatically illuminates when you open the door

Adjustable shelves Rearrange your refrigerator space to accommodate all shapes and sizes or remove shelves for a simple

clean-up

Fruit and vegetable

crisper Get the longest life and best taste out of produce by storing it in a convenient slide drawer

Door storage Store large bottles right on the door for easy access

Dual evaporator SUMMIT's unique and efficient design separately cools the refrigerator while maintaining zero degrees in the

freezer with two evaporators

Specifications:

Height 33.25 up to 34.5"

Width 23.63"

Depth 23.5"

Capacity 5.1 cu.ft.

Ext Depth with Handle 24.63"

Interior Height 1 19.5"

Interior Width 1 20.5"

Interior Depth 1 17.0"

Interior Height 2 5.0"

Interior Width 2 19.0"

Interior Depth 2 11.5"

Comp Step Height 7.0"

Comp Step Width 20.5"

Comp Step Depth 5.0"

Height Adjustable true

Shipping Weight 104.0 lbs.

Amps 1.3

Canadian Electrical Safety ULC

US Electrical Safety UL

Energy Usage/Year 434.0 kWh/year

Voltage/Frequency 115 V AC/60 Hz

Door Swing RHD

Reversible Yes

Crisper Quantity 1

Shelf Quantity 3

Adjustable Shelf true

Shelf Type Wire

Crisper Cover Type Glass

Crisper Finish Transparent

Full Door Shelf Quantity 3

Defrost Type Cycle

Height to Hinge Cap 34.75"

Depth with door at 90° 45.75"

Condensor Location Rear of Unit

Light true

Fan Type Exterior

Thermostat Type Dial

Freon Type R134a

High Side PSI 285.0

Level Legs Quantity 4

Low Side PSI 70.0

Freon Oz 2.6

Parts/Labor Warranty 1Year

Compressor Warranty 5Years
