680 SERIES OWNER’S MANUAL

P.N.:6530-681B Rev. B

Attention New Spa Owner!

Congratulations on the purchase of your new Sundance®680 Series spa! The

following is a list of automated functions and maintenance recommendations

for your new spa. Automated functions have been listed below in an attempt to

suppress any operational concerns you may have during startup and the rst 24

hours of ownership! Maintenance recommendations are listed in an attempt to

stress their importance in protecting your new spa.

Automated Operations

Approximately two minutes after power is applied to the spa, the rst ltration/heating

cycle turns on pump 1. With two pump models, an automatic ve minute “blow-out”

function also activates pump 2 for a period of ve minutes to ush all lines. Then, after

ve minutes, pump 2 turns off and pump 1 continues to operate for the duration of the

cycle.

Note: This function only occurs during the rst ltration/heating cycle each day.

Maintain Healthy Spa Water

Always maintain your spa’s water chemistry within the following parameters:

with CLEARRAY® without CLEARRAY®

pH 7.4-7.6 7.4-7.6

Free chlorine no less than 1.0 ppm 3.0-4.0 ppm

Free Bromine no less than 2.0 ppm 2.0-4.0 ppm

Total Alkalinity 100-150 ppm 100-150 ppm

Calcium Hardness 150-250 ppm 150-250 ppm

IMPORTANT: CLEARRAY® Water Purication System is factory installed. If the

CLEARRAY® system is altered or is not operating efciently then follow the “without

CLEARRAY®” water chemistry parameters as dened by the Association of Pool

and Spa Professionals. CLEARRAY® requires an annual bulb replacement to

properly sanitize your water.

!TO DECREASE RISK OF INFECTION OR DISEASE! Always maintain

your spa lter as outlined below to ensure healthy spa water. Refer to page 34 for

additional information.

Required Filter Maintenance

Your new spa is equipped with an advanced water ltration system that provides

unsurpassed water quality! To ensure maximum water quality at all times, you

should clean and reuse both lter cartridges every month or as needed. See page

34 for detailed lter cleaning/replacement instructions.

Required Water Maintenance

!TO DECREASE RISK OF INFECTION OR DISEASE! You should replace

the spa’s water every 3 months. The frequency depends on a number of variables

including frequency of use, number of users, and attention paid to water quality

maintenance. You will know it is time for a change when you cannot control sudsing

and/or you can no longer get the normal feel or sparkle to the water, even though

the key water balance measurements are all within the proper parameters. See

pages 39-40 for additional information.

680 SERIES

Table of Contents

1.0 Important Spa Owner Information............................................ 1

2.0 FCC Notice.................................................................................. 1

3.0 Important Safety Instructions for all Spa Owners .................. 2

3.1 Entrapment Risk .......................................................................... 6

3.2 Hyperthermia ............................................................................... 7

3.3 Important CSA Safety Instructions (Canada only) ....................... 8

3.4 General Electrical Safety Instructions.......................................... 8

4.0 Choosing A Location ................................................................. 9

4.1 Outdoor Location ....................................................................... 10

4.2 Indoor Location...........................................................................11

5.0 Power Requirements ............................................................... 12

5.1 North American 60 Hz Power Options....................................... 12

5.2 Export 50 Hz Power Options ..................................................... 13

6.0 Electrical Wiring Instructions ................................................. 14

7.0 Spa Fill Up Procedure.............................................................. 18

8.0 Control Functions.................................................................... 23

8.1 Control Panel............................................................................. 23

8.2 General Spa Features And Controls (McKinley and Ramona) .. 24

8.3 General Spa Features And Controls (Edison and Peyton) ........ 25

9.0 Operating Instructions ............................................................ 26

9.1 Setting Water Temperature........................................................ 26

9.2 Activate Pumps.......................................................................... 27

9.3 SunGlow™ Light Operation (Denali and Tacoma Models) ........ 27

9.4 Multi-Colored LED Light System Operation (Edison,

McKinley, Peyton and Ramona Models).................................... 28

9.5 Adjusting Individual Jet Flow ..................................................... 29

9.6 Selecting Desired Massage Action............................................ 29

9.7 Air Controls................................................................................ 29

9.8 Optional BLUEWAVE® Spa Stereo System.............................. 29

10.0 Automatic Filtration Cycles .................................................... 30

10.1 Standard Filtration/Heating Modes (F1-F3) ............................... 30

10.2 Economy Filtration/Heating Modes (F4-F6)............................... 30

10.3 Lock Modes (L1-L3)................................................................... 30

680 SERIES

10.4 Selecting The Filtration/Heating Mode ...................................... 30

10.5 Filtration Modes ......................................................................... 31

10.6 Programming the CLEARRAY (Ultraviolet)

Water Purication System ......................................................... 32

11.0 Spa Maintenance...................................................................... 34

11.1 Cleaning The Filter .................................................................... 34

11.2 Draining and Relling ................................................................ 35

11.3 Pillow Care (All Models Except Denali) ..................................... 36

11.4 Cleaning The Spa Interior.......................................................... 36

11.5 Maintaining The Cover .............................................................. 36

11.6 Maintaining The Synthetic Cabinet............................................ 37

11.7 Winterizing................................................................................. 37

11.8 Restarting Your Spa in Cold Weather........................................ 38

12.0 Water Quality Maintenance ..................................................... 39

12.1 pH Control ................................................................................. 39

12.2 Sanitizing ................................................................................... 39

12.3 CLEARRAY® Water Purication System .................................. 40

12.4 CLEARRAY® Bulb Replacement and

Quartz Tube Maintenance ......................................................... 41

13.0 Error Conditions/Error Messages .......................................... 44

13.1 Panel Displays SN1................................................................... 44

13.2 Panel Displays SN2................................................................... 44

13.3 Panel Flashes FL1 or FL2 ......................................................... 44

13.4 Panel Displays COL................................................................... 44

13.5 Panel Displays ICE.................................................................... 44

13.6 Panel Displays OH .................................................................... 45

13.7 Panel Displays - - - .................................................................... 45

13.8 Panel Displays BLB ................................................................... 45

14.0 Troubleshooting Procedures .................................................. 45

14.1 None of the Components Operate (e.g. Pump, Light)............... 45

14.2 Pump Does Not Operate but Light Does ................................... 46

14.3 Poor Jet Action .......................................................................... 46

14.4 Water is Too Hot ........................................................................ 46

14.5 No Heat ..................................................................................... 46

15.0 North American Denali/Tacoma Convertible

Circuit Diagram (60 Hz) ........................................................... 47

16.0 North American Edison, McKinley, Peyton and

Ramona Circuit Diagram (60 Hz) ............................................ 48

680 SERIES

17.0 Export Denali/Tacoma Circuit Diagram (50 Hz)..................... 49

18.0 Export Edison, McKinley, Peyton and Ramona

Circuit Diagram (50 Hz) ........................................................... 50

19.0 Optional BLUEWAVE® Spa Stereo System........................... 51

19.1 Electronic Device Connections and Functions .......................... 52

19.2 Stereo Cautions......................................................................... 52

......

Page 1

680 SERIES

1.0 Important Spa Owner Information

Your Sundance®680 Series spa is constructed to the highest standards

and is capable of providing many years of trouble-free use. However,

because heat retentive materials are utilized to insulate the spa for

efcient operation, an uncovered spa surface and wall ttings directly

exposed to sunlight and high temperatures for an extended period

are subject to permanent damage or discoloration. Damage caused

by exposing the spa to this abuse is not covered under warranty.

We recommend that you always keep the spa full of water when it is

exposed to direct sunlight and that you keep the Sundance premium

insulating cover in place at all times when the spa is not in use. Read

and carefully follow the requirements for your spa’s support base found

in Section 4.0 titled, “Choosing a Location” (page 9).

Sundance constantly strives to offer the finest spas available,

therefore modifications and enhancements may be made which

affect the specifications, illustrations and/or instructions contained

herein.

2.0 FCC Notice

This equipment has been tested and found to comply with the limits for

a Class B Digital Device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy and, if not installed and used

in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference

will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following

measures:

1. Rearrange or relocate the receiving antenna.

2. Increase the separation between the equipment and receiver

3. Connect the equipment into an outlet on a circuit different from the

circuit connected.

4. Consult the dealer or an experienced radio/TV technician for help.

Changes or modications not expressly approved by the party

responsible for FCC compliance could void the user’s authority to

operate this equipment.

Page 2

680 SERIES

3.0 Important Safety Instructions for all Spa Owners

READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY!

This spa was manufactured to meet the standards and specications

outlined in the “Virginia Graeme Baker Pool and Spa Safety Act” (VGB

Safety Act). When installing and using this spa, basic safety precautions

should always be followed, including:

1. !DANGER: RISK OF SEVERE INJURY OR DROWNING!

• Extreme caution must be exercised to prevent unauthorized access

by children.

• To avoid accidents, ensure that children do not use this spa unless

supervised at all times. Adult supervision is a critical safety factor in

preventing children from drowning.

• Use the straps and clip tie downs to secure the spa cover when not

in use. This will help discourage unsupervised children from entering

the spa. Keep the spa cover secure in high-wind conditions.

• There is no representation that the cover, clip tie-downs, or actual

locks will prevent access to the spa.

2. !DANGER: RISK OF SEVERE INJURY OR DROWNING!

• Keep hair, loose articles of clothing or hanging jewelry away from suction

ttings, rotating jets or other moving components to avoid entrapment

that could lead to drowning or severe injury.

• Never use the spa unless all suction guards, lter, lter lid, or skimmer

assembly are installed to prevent body and/or hair entrapment.

• Never operate or use the spa if the lter, lter lid, or skimmer assembly

are broken or any part of the skimmer assembly is missing. Please

contact your dealer or nearest service center for service.

• The suction ttings and suction covers in this spa are sized to match the

specic water ow created by the pump(s). If it is necessary to replace

the suction ttings, suction covers or pump(s), be sure that the ow rates

are compatible and are in compliance with the VGB Safety Act.

• Never replace a suction tting or suction cover with one rated less

than the ow rate marked on the original suction tting. Using improper

suction ttings or suction covers can create a body or hair suction

entrapment hazard that may lead to drowning or severe injury.

3. !DANGER: RISK OF SEVERE INJURY FROM ELECTRIC

SHOCK OR DEATH FROM ELECTROCUTION!

• Install the spa at least 5 feet (1.5m), from all metal surfaces. As an

alternative, a spa may be installed within 5 feet of metal surfaces

if each metal surface is permanently connected (bonded) by a

minimum No. 8 AWG (8.4 mm²) solid copper conductor attached

to the wire connector on the grounding lug, inside the equipment

compartment on the equipment box.

Page 3

680 SERIES

• A grounding wire connector is provided on this unit to connect a

minimum No. 8 AWG (8.4 mm²) solid copper conductor between

this unit and any metal equipment, metal enclosures of electrical

equipment, metal water pipe, or conduit within 5 feet (1.5m) of the

unit.

• Never permit any electrical appliance, such as a light, telephone,

radio, television, etc. within 5 feet (1.5m) of a spa unless such

appliances are built-in by the manufacturer.

• Never bring any electrical appliances into or near the spa.

• Never operate any electrical appliances from inside the spa or when

you are wet.

• The electrical supply for this product must include a suitably rated

switch or circuit breaker to open all ungrounded supply conductors

to comply with section 422-20 of the National Electrical Code/USA,

ANSI/NFPA 70. The disconnecting means must be readily accessible

and visible to the spa occupant but installed at least 5 feet (1.5m),

from the spa.

• The electrical circuit supplied for the hot tub must include a suitable

ground fault circuit interrupter (GFCI) as required by NEC Article

680-42.

4. !WARNING: RISK OF SEVERE INJURY OR DEATH!

• Extreme caution must be exercised to prevent diving or jumping

into the spa or slipping and falling, which could result in

unconsciousness, drowning, or serious injury. Remember that wet

surfaces can be very slippery.

• Never stand, walk or sit on the top railing of the spa.

5. !WARNING: RISK OF HYPERTHERMIA (OVER-HEATING)

CAUSING SEVERE INJURY, BURNS, WELTS OR DEATH!

• Water temperature in excess of 104°F (40°C) may be injurious to

your health.

• Refer to Section 3.2 Hyperthermia for specic causes and symptoms

of this condition.

• The water in the spa should never exceed 104°F (40°C). Water

temperatures between 100°F (38°C) and 104°F (40°C) are

considered safe for a healthy adult.

• Lower water temperatures are recommended for young children

(children are especially sensitive to hot water) and when spa use

may exceed 10 minutes.

• The Consumer Products Safety Commission/USA has stated that the

water temperature in a spa should not exceed 104°F (40°C).

• Always test the spa water temperature before entering the spa.

The user should measure the water temperature with an accurate

thermometer since the tolerance of water temperature-regulating

devices may vary as much as +/- 5°F (2°C).

Page 4

680 SERIES

6. !WARNING: RISK OF SEVERE INJURY OR DEATH!

• Since excessive water temperatures have a high potential for

causing fetal damage during the early months of pregnancy, if

pregnant or possibly pregnant, consult your physician before using a

spa.

• Pregnant or possibly pregnant women should limit spa water

temperatures to 100°F (38°C).

• Persons suffering from obesity or a medical history of heart disease,

low or high blood pressure, circulatory system problems, diabetes,

infectious diseases or immune deciency syndromes should consult

a physician before using a spa.

• If you experience breathing difculties in association with using or

operating your spa, discontinue use and consult your physician.

• Persons using medication should consult a physician before using

a spa since some medication may induce drowsiness, while other

medication may affect heart rate, blood pressure, and circulation.

• Persons suffering from any condition requiring medical treatment, the

elderly, or infants should consult with a physician before using a spa.

• The use of alcohol, drugs, or medication before or during spa use

may lead to unconsciousness with the possibility of drowning.

7. !WARNING: RISK OF SEVERE INJURY OR DEATH!

• Prolonged immersion in a spa may be injurious to your health.

• Observe a reasonable time limit when using the spa. Exposures

at higher temperatures can cause high body temperature (over-

heating). Symptoms may include dizziness, nausea, fainting,

drowsiness, and reduced awareness. These effects could possibly

result in drowning or serious injury.

• Never use a spa immediately following strenuous exercise. Enter

and exit the spa slowly. Wet surfaces can be slippery.

8. !WARNING: TO DECREASE RISK OF INFECTION OR

DISEASE!

• To reduce the risk of contracting a waterborne

illness (e.g. an infec-

tion, bacteria or virus) and/or respiratory ailments

, maintain water

chemistry within the parameters listed on the inside cover of this

manual and consult with a licensed engineer regarding proper venti-

lation if installed indoors or in an enclosed area.

• People with infectious diseases should not use a spa to avoid water

contamination, which could result in spreading infections to others.

• Always shower before and after using your spa. Maintain water

chemistry in accordance with manufacturer’s instructions. Failure

to do so may result in contracting a waterborne

illness (e.g. an

infection, bacteria or virus).

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali Sundance Spas Vasca idromassaggio

Sundance Spas

Sundance Spas 680 Series Manuale utente

Sundance Spas

Sundance Spas ALTAMAR 880 Manuale d'uso e manutenzione

Sundance Spas

Sundance Spas 880 Series Manuale utente

Sundance Spas

Sundance Spas Altamar 880 series Manuale utente

Sundance Spas

Sundance Spas 850Export Series Istruzioni operative

Sundance Spas

Sundance Spas CAMDEN 780 Manuale utente

Sundance Spas

Sundance Spas Altmar Manuale utente

Sundance Spas

Sundance Spas 780 series Manuale utente

Sundance Spas

Sundance Spas Spas 680 Series Manuale utente

Sundance Spas

Sundance Spas 880 Series Manuale utente

Sundance Spas

Sundance Spas Maxxus Istruzioni operative

Sundance Spas

Sundance Spas CAMDEN 780 Manuale utente

Sundance Spas

Sundance Spas 680 Series Manuale utente

Sundance Spas

Sundance Spas maxxus 880 Series Manuale utente

Sundance Spas

Sundance Spas Maxxus Manuale utente

Sundance Spas

Sundance Spas 400 series Istruzioni per l'installazione

Sundance Spas

Sundance Spas Export 680 Series Manuale utente

Sundance Spas

Sundance Spas Burlington Manuale utente

Sundance Spas

Sundance Spas CONSTANCE 6530-512X Manuale utente

Sundance Spas

Sundance Spas Solo Istruzioni operative

Sundance Spas

Sundance Spas Portofino Series Istruzioni per l'installazione

Sundance Spas

Sundance Spas 880 Series Manuale utente

Sundance Spas

Sundance Spas Marin 880 Manuale utente

Sundance Spas

Sundance Spas 850 Series Manuale utente

Manuali Vasca idromassaggio popolari di altre marche

Bestway

Bestway Lay-Z-Spa 54189 Manuale utente

Jacuzzi

Jacuzzi ARGA ARG101C0110 Manuale elenco delle parti

Morphy Richards

Morphy Richards Essentials PC4006 Manuale utente

Softub

Softub PRESTIGE Manuale utente

JNJ SPAS

JNJ SPAS SPA-318 Manuale di installazione

KIRAMI

KIRAMI Comfort Family Manuale utente

QCA Spa

QCA Spa VS501 PAK (VL260 TOPSIDE) Manuale utente

HoMedics

HoMedics FB-655HJ-GB Manuale utente

Everyday Hot Tubs

Everyday Hot Tubs 530 Manuale utente

anko

anko SS-601A Manuale utente

Jacuzzi

Jacuzzi Duetta 6042 Manuale utente

Pooli

Pooli OS030979B Manuale utente

Jacuzzi

Jacuzzi alimia Manuale utente

ab Solares Smart Spa Manuale utente

CalderaSpas

CalderaSpas CalderaSpas Utopia Series Manuale utente

Outsunny

Outsunny 848-047V70 Manuale utente

Aquatic

Aquatic INFINITY 1 Manuale utente

Master Spas

Master Spas MP Force Manuale utente
