Sundirect Tower500-Pro Istruzioni per l'installazione

Smart Wiﬁ Infrared Heater

Tower500-Pro/Tower1000-Pro

Installation & Operation Instructions

Version: SDUM-23003

Language

Page

P3-P10

P11-P18

Read the installation and operating instructions completely before

starting any installation works and save the instructions for later

use.

DESCRIPTION OF THE SYMBOLS

Before using this heater, please refer to the corresponding section in this

instruction manual.

In accordance with European directives applicable to this product

WARNING: In order to avoid the heater overheating, do not cover it.

The crossed-out wheeled bin symbol indicates that the item should be

disposed of separately from household waste. The item should be

handed in for recycling in accordance with local environmental

regulations for waste disposal. By separating a marked item from

household waste, you will help reduce the volume of waste sent to

incinerators or land-ﬁlls and minimize any potential negative impact on

human health and the environment.

1. Safety instructions

TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY:

1.1 Product related safety warnings

• Tower1000-Pro heaters operate at a surface temperature of around 95°C when in use.

• Prolonged contact may cause injuries or burns.

• Do NOTcover the heater with anything.Covering may cause overheating and can result in ﬁre.

• This heater is designed to be portable,please don’t mount them on the wall or ceiling.

• This heater can be easily operated using your smartphone, via the same WLAN, via a different

WLAN, or via a 3G or 4G mobile network. This makes it possible to operate your heater

remotely, without your direct supervision. However, please make sure that all safety precautions

stated in this manual must be taken even with remote operation.

1.2 Dangers for children and persons with limited abilities

• This appliance can be used by children aged from 8 years and above and persons with

reduced physical, sensory or mental capabilities or lack of experience and knowledge if

they have been given supervision or instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children shall not play with the appliance.

Cleaning and user maintenance shall not be made by children without supervision.

• Children of less than 3 years should be kept away unless continuously supervised.

• Children aged from 3 years and less than 8 years shall only switch on/off the appliance

provided that it has been placed or installed in its intended normal operating position and

they have been given supervision or instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children aged from 3 years and less than 8

years shall not plug in, regulate and clean the appliance or perform user maintenance

• CAUTION — Some parts of this product can become very hot and cause burns. Particular

attention has to be given where children and vulnerable people are present.

• If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or

similarly qualiﬁed persons in order to avoid a hazard.

• Do NOT operate the heater in small rooms when occupied by people not capable of

leaving the room by themselves. The surface of the heater can reach a surface temperature

of up to 80°C, keep out of reach of children and disabled persons.

• Keep away babies and children from all packaging material such as plastic bags to avoid

danger of suffocation.

• When moving the appliance on its rolls, please make sure to move it slowly to avoid the

risk of falling over. Sundirect will not be responsible for accidental damages caused by the

user.

• When positioning the heater, make sure to keep it out of reach of children.

1.3 Electric safety directions

• When installing, repairing or servicing the heater it must be turned off and disconnected

from power.Before installation please check if the heater is free of damages.

• If the heater or the power cord is damaged in any form do NOT use the heater and contact

your Sundirect dealer for repair or replacement. Repairs, maintenance or any changes must

be carried out by an authorized Sundirect dealer.

• DO NOTattempt to repair the heater by yourself,this will void your warranty.

• If the heater has been dropped do NOT operate it and contact your Sundirect dealer to

make sure it is free of anydamages.

• This heater is designed to operate at 220-240V, 50Hz AC. If your supply mains do not comply

with this, do NOT use theheater.

• The heater must not be located immediately below a socket-outlet

• WARNING: Do not use this heater in small rooms when they are occupied by persons not

capable of leaving the room on their own, unless constant supervision is provided.

2. How to care for your Sundirect heater

2.1 Cleaning

Always unplug your heater and let it cool down completely before cleaning. Never dip into water

and never splash water on it. Clean the heater with a soft damp cloth. For glass models use a soft

cloth and glass cleaner. Never use a wet cloth and make sure to dry the heater when clean with a

dry cloth. Do not use any abrasive materials, solvents or harsh cleaning sponges as this could cause

scratches or other irreparable damage. Before operating the heater again it must be completely dry.

2.2 Using/Working

Please note that the heater may discolor with use. This is due to airborne pollution and is not a fault.

Do not cover your heater with a picture foil and do not paint or print the heater yourself. This might

cause damage to the heating element and will void your warranty.

If you notice any noise, smells, visible changes or exceptionally high temperatures please

discontinue use and contact an authorized Sundirect dealer.

2.3 Repair

Repairs must be carried out by authorized Sundirect dealers or by Sundirect directly. If you attempt

to alter the product or to proceed with any repairs yourself it will void your warranty.

2.4 Positioning

This heater has a heating surface of 270 degrees, i.e. only the backside of the heater does not emit

heat. Please make sure the heater is facing room or objects you want to heat correctly.

3. Mounting

This heater is designed to be portable, please follow the procedure below to mount the

heater onto the feet.

Tower1000-pro

Tower500-pro

4. Operation:

4.1 General introduction of the smart control

This heater has an integrated WIFI control box with a touchscreen glass surface on top of the heater.

There is no other additional thermostat needed to control the heater. Once the heater has been

connected to the APP, the smartphone will take control and communicate with the control box. If

your home internet is not working, it is still possible to operate the heater via the control box

manually, once the heater is re-connected to the WIFI, the smart phone will take control again.

4.2 Control box and parts description:

1. Glass touchscreen

2. Front heating side

3. Feet

4. ON/OFF Switch

5. Temperature display

6. “+” button

7. “-” button

8. Timer button

9. Wiﬁ indicator

4.3 Manual Control via touch screen buttons

Activate the power switch, press and hold the “+” button for 3 seconds to turn on/off the heater via

touchscreen. Adjust your desired room temperature by pressing the “-” or “+” button.

If you would like to set up the timer, press the timer button and “00H” will appear on the screen and

you can set the timer by pressing “-” and “+” button to start the count-down timer.

Please notice that once the timer is set, the heater will automatically work under manual

mode.

4.4 Child lock

Press the “+” and “-” button together for 3 seconds to activate the child lock mode, the screen will

show “CL”. Press the “+” and “-” again to quit the child lock mode.

4.5 Open window detection

This heater has an open window detection function. By default, the function is off but you can

activate this function after connecting your heater to the APP. When the function is

on, the heater will monitor the heating system. in case there is a dramatic temperature decrease

in a short time period, ”OPE” will ﬂash on the screen. The system will shut off the heater

and after 30 minutes normal operation will start again. By pressing any button in between the heater

will go back to normal operation.

4.6 Temperature calibration

Power on the heater, press and hold the + button until the screen shows the temperature reading.

Press and hold the Timer button for 5 seconds to enter the temperature calibration and edit the

number by pressing the “+” or “-” button. (You can adjust between +5/-5 degrees).

4.7 Factory mode

If you have any issues during the operation (including wiﬁ connection), please try the factory mode

to reset your heater. Power on the heater and the temperature reading will display on the screen,

press and hold the “-” button for 5 seconds to reset the heater.

After the factory reset, the heater will clear all the previous temperature settings and operate under

manual mode.

4. 8 More functions of the APP

After connecting to the APP, you will be able to do more settings, including:

•Set up a heating mode and schedule

•Remotely operate your heater

•Constantly check the energy consumption of your heating system (Settings>>Energy Saving

Statistics)

•Disable the “Beep” noise

……

4.9 Control via APP

4.9.1 How to download the Sundirect Smart APP

Scan the QR code on the right side to start the procedure to download the

APP, or you can download the APP “Sundirect Smart” on APP Store or Google

play, open the APP and register with your phone number or Email address.

4.9.2 Connect to WIFI:

Step1: Turn on the power of the heater by pressing the Power Switch. The WIFI signal will start to

ﬂash rapidly. Open the APP on your smartphone and add your device. Choose “Add Device”, then

“Add Manually”, and then choose “Thermostat” to add the device.

Step2: Enter the WIFI password of your home network. Please make sure your home WIFI is working

and keep the heater and smartphone as close as possible to the WIFI router.

Please notice that this heater is only working with 2.4GHz WIFI networks, it doesn’t support 5GHz

networks currently. Also, make sure your internet router has enough capacity to add a new device.

Step3: Wait till the connection status shows 100% to ﬁnish the settings and the WIFI signal on the

control box will stop ﬂashing.

If the heater fails to connect, please power off the heater and power it back on again after a few

seconds to try. If you still have any difﬁculty with the wiﬁ connection, please try a different wiﬁ

connection mode, please refer to “WIFI reset” on point 4.10.

4.10 WIFI reset

This heater offers 2 types of wiﬁ connection modes: EZ mode and AP mode. When the wiﬁ signal

is ﬂashing rapidly, the heater is under the EZ mode, while under AP mode the wiﬁ signal will ﬂash

slowly. When you have any issues with one connection mode, try another connection mode.

You can swift between two connection modes by the below operation:

Turn on the heater, press and hold the “+” button for 3seconds until the screen shows “OFF”, press

and hold the “Timer” button for 5 seconds to reset the wiﬁ and meantime the Wiﬁ connection mode

will be changed.

4.11 Activate/deactivate WIFI function

Power on the heater, press and hold the “+” button for 3 seconds until screen shows “OFF”, press

and hold the “-” button for 10 seconds to deactivate the WIFI function of this heater and the WIFI

sign on the screen will disappear, press and hold “-” button for 5 seconds to activate it on again.

5. Technical Speciﬁcations

6. Warranty

Sundirect offers a 5 year manufacturing warranty on this heater.

You can ﬁnd the serial number on the back side of the heater as well as the last page of this user

manual. Please always keep this manual in case of future warranty claims.

Within the warranty period from date of purchase, Sundirect will repair or replace your heater where

the fault is due to defects in workmanship or materials. Please contact your local Sundirect dealer in

the event of a warranty claim and return the heater together with proof of purchase.

The warranty covers the repair or replacement of the heater only and Sundirect shall not be liable

for any other occurring costs such as installation cost or any other consequential losses however

incurred. Please note that tampering with or opening the heater in any way will void your warranty.

The removal of the serial number on the back of the heater will also void this warranty. All labels on

the back of the heater shall not be removed.

Any damages to the heater caused by the user are not covered by this warranty. This includes

scratches on the surface or the frame. Sundirect is not responsible for any damages, losses or

injuries due to ingress of water or moisture, accidental damage, mishandling, external impact,

repairs or adjustment by unauthorized persons or failure to follow the correct safety, maintenance

and installation precautions stated in this manual.

Model

Power

Voltage

Size

Mounting

IP rate

Tower500-Pro

500W

220-240V~50HZ

34*34*85cm

Portable

IP44

Tower1000-Pro

1000W

220-240V~50HZ

34*34*125cm

Portable

IP44

Questo manuale è adatto per i seguenti modelli

Indice

Lingue:

Altri manuali Sundirect Stufa

Sundirect

Sundirect Tower1000-Pro Istruzioni per l'installazione

Sundirect

Sundirect SC-Plus Istruzioni per l'installazione

Sundirect

Sundirect PE-Plus Istruzioni per l'installazione

Sundirect

Sundirect IC Series Manuale utente

Sundirect

Sundirect TH600-PRO Istruzioni per l'installazione

Sundirect

Sundirect BC004 Manuale utente

Sundirect

Sundirect Tower1000-Pro Istruzioni per l'installazione

Sundirect

Sundirect TH400 Istruzioni per l'installazione

Sundirect

Sundirect OC2500-Pro Istruzioni per l'installazione

Sundirect

Sundirect OC2000 Istruzioni per l'installazione

Sundirect

Sundirect Hybrid750-Pro Istruzioni per l'installazione

Sundirect

Sundirect PE380-Plus Istruzioni per l'installazione

Sundirect

Sundirect Hybrid500-Pro Istruzioni per l'installazione

Sundirect

Sundirect Stone600-Pro Istruzioni per l'installazione

Sundirect

Sundirect Footwarmer220-Pro Istruzioni per l'installazione

Sundirect

Sundirect TH400 Istruzioni per l'installazione

Sundirect

Sundirect Hybrid500-Pro Istruzioni per l'installazione

Manuali Stufa popolari di altre marche

oventrop

oventrop Regucor Series Manuale utente

Blaze King

Blaze King CLARITY CL2118.IPI.1 Manuale utente

ELMEKO

ELMEKO ML 150 Manuale utente

BN Thermic

BN Thermic 830T Manuale utente

KING

KING K Series Guida

Empire Comfort Systems

Empire Comfort Systems RH-50-5 Guida rapida

Well Straler

Well Straler RC-16B Manuale utente

EUROM

EUROM 333299 Manuale utente

Heylo

Heylo K 170 Manuale utente

Eterna

Eterna TR70W Manuale utente

Clarke

Clarke GRH15 Manuale di istruzioni

IRSAP

IRSAP The Radiator Company Ovali Manuale utente

Empire Heating Systems

Empire Heating Systems WCC65 Manuale utente

Wetekom

Wetekom 92 86 43 Manuale utente

Desa

Desa SPC170-F Manuale utente

Watlow

Watlow Watrod Electric Tubular Heaters Manuale utente

Haverland

Haverland ECO-DRY GPS Series Manuale elenco delle parti

Stelpro

Stelpro ASILVC2060 Series Manuale utente
