Sunricher SR-GW-ZG Manuale utente

ZigBee Smart Hub

Important: Read All Instructions Prior to Installation

Radio protocol ZigBee 3.0

Operation Frequency 2.4GHz

Operating temperature -20°C~50°C

Relative humidity 8% to 80%

Dimensions 94x94x29.5mm

• Free APP is available for IOS or Android smart phones or tablets.

• Supports group, scene, and automation.

• Supports up to 150 zigbee devices.

• Cloud control enabled, supports voice control through Amazon Alexa and Google Assistant.

• Supports firmware OTA update for the smart hub and Zigbee devices

• Waterproof grade: IP20.

• This ZigBee smart hub works with: Zigbee light devices, sensors, heaters, plugs, remotes, GP switches etc.

Product Data

• DO NOT install with power applied to device.

• DO NOT expose the device to moisture.

Safety & Warnings

Power Supply 5VDC/2A

Function Introduction

The Zigbee Smart Hub is the brain of a Zigbee ecosystem. It can be connected with an Ethernet network, and supports

interaction and connection with Zigbee accessories through Azoula Smart app via ZigBee 3.0 wireless protocol.

Power Adapter lnterface LAN Cable lnterface

Zigbee Network

Manual Open Button

LAN indicator Power indicator

Running indicator

WAN indicator

Reset Button

Reboot Button

Product Features

Connect the Smart Hub to power

Connect the power adapter to the Smart Hub and plug it to mains socket.

Download and Install App

Download “Azoula Smart” app from App Store or Google Play or scan the QR codes below. Follow the direction in the

app to connect your devices properly.

iOS QR Code Android QR Code

Connect the Smart Hub to network

Connect Smart Hub's LAN port to a router with network cable. Make sure the cell phone for control connects to the same

network.

Home Automation Discover

Azoula's Home

Discover Home

Explore the possibilities and see how easy it

is to add accessories to your home.

Learn More

Accessories

Add or Scan

Accessory

Add or Sc an Acces sory

Add Roo m

Add Peo ple

Add New H ome

Indicator Lights State

Running indicator: ﬂashing blue 6 times rapidly The smart hub is reset to factory default or

manually enter adding device mode

LAN indicator Power indicator

Running indicator

WAN indicator

State

LAN indicator: solid blue

LAN indicator: ﬂashing blue slowly

Power indicator: solid red

WAN indicator: solid blue

WAN indicator: ﬂashing blue slowly

Connected to a router

Not connected to a router

Power connected

Connected to Internet

Not connected to Internet

Reset to Factory Default

Press and hold the reset button for over 5 seconds until the running indicator ﬂashing blue 6 times rapidly.

Reboot

Short press the reboot button to reset power of the smart hub, all indicators will turn off, then the gateway will restart.

Product Dimensions

94.00 mm

29.50 mm

Add & Control Zigbee Devices

Follow the direction in the “Azoula Smart” app to connect your gateway, then add and control Zigbee devices.
