SunSynk SUNSYNK-3.6K-SG01/03LP1 Guida utente

HYBRID PARITY

(SUPER) INVERTER

INSTALLER MANUAL

SUNSYNK-3.6K-SG01/03LP1, SUNSYNK-3.6K-SG02LP1, SUNSYNK-5K-SG01/03LP1, SUNSYNK-5K-

SG02LP1, SUNSYNK-8K-SG01LP1, SUNSYNK-8K-SG02LP1

Global Tech China Ltd, 3 Floor, Wai Yip Industrial Building.

171 Wai Yip Street, Kwun Tong, Kowloon, Hong Kong.

Tel: +852 2884 4318 Fax: +8522884 4816

www.sunsynk.com / sales@globaltech-china.com

www.globaltechhk.com

Version

.0 (0

8/04

/2021)

All these models fall into two cabinet / PCB types 3.6kW / 5.5kW (Small) and 8.8kW

(Large):

5.5kW Type:

SUNSYNK-3.6K-SG01/03LP1

SUNSYNK-3.6K-SG02LP1

SUNSYNK-5K-SG01/03LP1

SUNSYNK-5K-SG02LP1

8.8kW Type

SUNSYNK-8K-SG01LP1

SUNSYNK-8K-SG02LP1

INDEX

1. SAFETY 5

1.1. G

ENERAL

AFETY

NFORMATION

1.2. S

YMBOLS

1.3. S

AFETY

NSTRUCTIONS

1.4. D

ISPOSAL

EMARKS

2. PRODUCT INTRODUCTION 7

2.1. S

YSTEM

VERVIEW

3. TECHNICAL SPECIFICATIONS 9

3.1. S

YSTEM

IAGRAM

4. INSTALLATION 15

4.1. S

ELECTING THE

OUNTING

REA

4.2. M

OUNTING THE

NVERTER

4.3. B

ATTERY

ONNECTION

4.4. C

ONNECTING A

ITHIUM

ATTERY

4.5. B

ATTERY

EMPERATURE

ONNECTION

4.6. C

ONNECTING THE

AC 22

4.7. I

NSTALLING THE

OIL

4.8. E

ARTH

ONNECTION

(MANDATORY) 26

4.9. C

ONNECTING THE

PV 27

4.9.1. PV

ODULE

ELECTION

4.9.2. PV

ODULE

IRING

5. OPERATION 31

5.1. D

ISPLAY

5.2. S

WITCHING

ON/OFF 32

5.3. H

OME

AGE

5.4. S

TATUS

AGE

5.5. S

YSTEM

LOW

AGE

5.6. S

ETUP

AGE

5.7. S

IME

LOCK

) 36

5.8. S

OMPANY

AME

EEPER

UTO DIM

5.9. F

ACTORY

ESET AND

OCK

ODE

5.10. B

ATTERY

ETUP

AGE

5.11. G

ENERATOR AND

ATTERY

AGE

5.12. B

ATTERY

ISCHARGE

AGE

5.13. S

ETTING

P A

ITHIUM

ATTERY

5.14. P

ROGRAM

HARGE

ISCHARGE

IMES

AGE

5.15. G

RID

UPPLY

OLTAGE AND

REQUENCY

–

RID

UPPLY

AGE

5.15.1. R

EACTIVE POWER SETTING

(QV) 50

5.15.2. A

CTIVE POWER SETTING

(VW): 51

5.15.3. V

OLT

ARIABLE

ODE

OLT

VAR

VV) 51

5.16. A

DVANCED

ETTINGS FOR

ARALLELING

NVERTERS

5.17. S

OLAR

OWER

ENERATED

5.18. G

RID

OWER

5.19. A

DVANCED

ETTINGS FOR

IND

URBINE

5.20. A

DVANCED

ETTINGS FOR

UXILIARY

OAD

5.21. A

DVANCED

ETTINGS FOR

EAK

OWER

HAVING

5.22. F

AULT

ODES

6. COMMISSIONING 65

6.1. S

TARTUP

HUTDOWN

ROCEDURE

6.2. I

NFORMATION FOR

OMMISSIONING THE

NVERTER

6.3. GDFI

AULT

7. MAINTENANCE 67

APPENDIX A 67

APPENDIX B 68

APPENDIX C 68

APPENDIX D 68

APPENDIX E 68

Page | 5

1. SAFETY

1.1. General Safety Information



This device should only be used in accordance o instructions within this manual and

in compliance with local, regional and national laws and regulations. Only allow this

device to be installed, operated, maintained, repaired by other persons who have also

read and understood this manual. Ensure the manual is included with this device

should it be passed to a third party.



DO NOT allow minors, untrained personnel, or person(s) suffering from a physical or

mental impairment that would affect their ability to follow this manual, install, maintain

or repair this device.



Any untrained personnel who might get near this device while it is in operation MUST

be informed that it is dangerous and instructed carefully on how to avoid injury.

1.2. Symbols

This symbol indicates information that if ignored, could result in personal

injury or even death due to incorrect handling.

This symbol indicates information that if ignored, could result in personal

injury or physical damage due to incorrect handling.

Indicates information that is considered important, but not hazard-related.

WARNING

CAUTION

NOTICE

SAFETY

Page | 6

1.3. Safety Instructions



Be sure to read this manual thoroughly before installation.



Do not attempt to install the inverter by yourself. Installation work must be carried out

in compliance with national wiring standards and by suitably qualified personnel only.

Do not turn on the power until all installation work is complete.



Do not disassemble the inverter. If you need repair or maintenance, contact a

professional service centre.



Always use an individual power supply line protected by a circuit breaker and operating

on all wires with a distance between contacts of at least 3mm for this unit.



The unit must be correctly grounded and the supply line must be equipped with a

suitable breaker and RCD to protect people.



Disconnect all wires/cables before performing any maintenance or cleaning to reduce

the risk of electrical shock.



The unit is not explosion-proof, so it should not be installed in an explosive

atmosphere.



Never touch electrical components immediately after the power supply has been

turned off since the system can still have residual energy, so electric shock may occur.

Therefore, after turning off the power, always wait 5 minutes before touching electrical

components.



This unit contains no user-serviceable parts. Always consult an authorised contractor

for repairs.

1.4. Disposal Remarks

DO NOT dispose this product with domestic waste!

Electrical devices should be disposed of in accordance with regional directives on

electronic and/ or electronic-waste disposal. In case of further questions, please consult

your supplier. In some cases, the supplier can take care of proper disposal.

HIGH LIFE RISK DUE TO FIRE OR ELECTROCUTION.

The Sunsynk Single-Phase Hybrid Inverter can only be installed by a qualified

licensed electrical contractor. This is not a DIY product.

WARNING

Page | 7

2. PRODUCT INTRODUCTION

The Sunsynk Single-Phase Hybrid Inverter is a highly efficient power management tool

that allows the user to hit those ‘parity’ targets by managing power-flow from multiple

sources such as solar, mains power (grid) and generators, and then effectively storing and

releasing power as and when utilities require.

2.1. System Overview

INTERACTIVE



Easy and simple to understand display



Supporting Wi-Fi or GSM monitoring



Visual power flow screen



Smart settable 3-stage MPPT charging for optimized battery performance



Auxiliary load function



Parallel / multi invert function grid-tied and off-grid

COMPATIBLE



Compatible with main electrical grid voltages or power generators



Compatible with wind turbines



220V single phase, pure sinewave inverter



Self-consumption and feed-in to the grid



Auto restart while AC is recovering



Auto earth bond feature (Via a relay)

1. PV isolator

2. Power ON/OFF

3. Battery input connectors

4. I/O Ports

5. MPPT 1 and MPPT 2 inputs

6. Battery cable compression gland

7. Inverter LED indicators

8. LCD display

9. Function buttons

10. RS485 port

11. CAN bus port

12. Generator / Aux IN/OUT

13. On-grid inverter

14. Load off-grid inverter

15. Ground connection

16. Data logger

PRODUCT INTRODUCTION

Page | 8

CONFIGURABLE



Fully programmable controller



Programmable supply priority for battery or grid



Programmable multiple operation modes: on-grid/off-grid & UPS



Configurable battery charging - current/voltage based on applications by LCD setting



Configurable AC / solar / generator charger priority by LCD setting

SECURE



Overload/over-temperature/short-circuit protection



Smart battery charger design for optimized battery protection



Limiting function installed to prevent excess power overflow to grid

APPLICATIONS



Marine (vessel power management)



Power shedding (home/office/factory)



UPS (fuel-saving systems)



Remote locations with solar and wind generators



Building sites



Military locations



Telecommunication

Page | 9

3. TECHNICAL SPECIFICATIONS

 SUNSYNK-3.6K-SG01/03LP1

Model SUNSYNK-3.6K-SG01/03LP1

Battery Input Data

Battery Type Lead-acid or Lithium-ion

Battery Voltage Range 40~60V

Max. Charging Current 90A

Max. Discharging Current 90A

Charging Curve 3 Stages/Equalisation

External Temperature Sensor Optional

Charging Strategy for Li-Ion Battery Self-Adaptation to BMS

PV String Input Data

Max. DC Input Power 4680W

PV Input Voltage 370V (100V~500V)

MPPT Range 125~425V

Full Load DC Voltage Range 240~425V

Start-up Voltage 150V

PV Input Current 11A

No. of MPPT Trackers 2

No. of Strings Per MPPT Tracker 1+1

AC Output Data

Rated AC Output and UPS Power 3600W

Max. AC Power 3960W

Peak Power (off-grid) 2 times of rated power, 10 S

AC Output Rated Current 15.7A

Max AC Output Current 18A

Max Continuous AC Passthrough 35A

Power Factor 0.8 leading to 0.8 lagging

Output Frequency and Voltage 50/60Hz; 220/230/240Vac (single phase)

Grid Type Single Phase

Current Harmonic Distortion THD<3% (Linear load<1.5%)

Efficiency

Max. Efficiency 97.60%

MPPT Efficiency 96.50%

Euro Efficiency 99.90%

Protection

PV Input Lightning Protection Integrated

Anti-islanding Protection Integrated

PV String Input Reverse Polarity

Protection Integrated

Insulation Resistor Detection Integrated

Residual Current Monitoring Unit Integrated

Output Over Current Protection Integrated

Output Shorted Protection Integrated

Output Over Voltage Protection Integrated

Certifications and Standards

Grid Regulation

VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116,

IEC61727,

RD1699:2011, XP C15-712-3:2019-05

Safety Regulation IEC62109-1, IEC62109-2

EMC EN61000-6-1, EN61000-6-3

General Data

TECHNICAL SPECIFICATIONS

Page | 10

Operating Temperature Range -25~60°C, >45°C Derating

Cooling Natural Cooling

Noise <30dB

Communication with BMS RS485; CAN

Weight 20.5kg

Size (Length x Width x Height) 580 x 330 x 208 mm

Protection Degree IP65

Warranty 5 years

 SUNSYNK-3.6K-SG02LP1

Model SUNSYNK-3.6K-SG02LP1

Battery Input Data

Battery Type Lead-acid or Lithium-ion

Battery Voltage Range (V) 40~60V

Max. Charging Current (A) 90A

Max. Discharging Current (A) 90A

Charging Curve 3 Stages/Equalisation

External Temperature Sensor Optional

Charging Strategy for Li-Ion Battery Self-Adaptation to BMS

PV String Input Data

Max. DC Input Power (W) 7000W

Voc Max. (V) 500V

MPPT Range (V) 125~425V

Full Load DC Voltage Range (V) 240~425V

Start-up Voltage (V) 150V

PV Input Current (A) 11A+11A

No. of MPPT Trackers 2

No. of Strings Per MPPT Tracker 1+1

AC Output Data

Rated AC Output and UPS Power (W) 3600W

Max. AC Power (W) 3960W

Peak Power (off-grid) 2 times of rated power, 10 S

AC Output Rated Current (A) 15.7A

Max AC Output Current (A) 18A

Max Continuous AC Passthrough (A) 35A

Power Factor 0.8 leading to 0.8 lagging

Output Frequency and Voltage 50/60Hz; 220/230/240Vac (single phase)

Grid Type Single Phase

Current Harmonic Distortion THD<3% (Linear load<1.5%)

Efficiency

Max. Efficiency 97.60%

MPPT Efficiency 96.50%

Euro Efficiency 99.90%

Protection

PV Input Lightning Protection Integrated

Anti-islanding Protection Integrated

PV String Input Reverse Polarity

Protection Integrated

Insulation Resistor Detection Integrated

Residual Current Monitoring Unit Integrated

Output Over Current Protection Integrated

Output Shorted Protection Integrated

Output Over Voltage Protection Integrated

Certifications and Standards

Grid Regulation VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116,

IEC61727,

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali SunSynk Invertitore

SunSynk

SunSynk 8K-SG04LP3 Guida utente

SunSynk

SunSynk SUNSYNK-3K-SG04LP1 Guida utente

SunSynk

SunSynk Hybrid Parity Inverter Manuale utente

SunSynk

SunSynk ECCO SUN-3.6K-SG05LP1-EU Manuale utente

SunSynk

SunSynk SUN-25K-SG01HP3-EU-BM2 Guida utente

SunSynk

SunSynk FSPKL2N Manuale utente

SunSynk

SunSynk SUN-8K-SG04LP3 Guida utente

SunSynk

SunSynk SUNSYNK MAX Manuale utente

SunSynk

SunSynk Hybrid Inverter with a Generator Manuale di istruzioni

SunSynk

SunSynk SUNSYNK-25K-SG01HP3-EU-BM2 Manuale utente

SunSynk

SunSynk ECCO SUN-3K-SG04LP1-24-EU Manuale utente

SunSynk

SunSynk SUN-8K-SG04LP3 Guida utente

SunSynk

SunSynk SYNK-3.6K-SG04LP1 Manuale utente

SunSynk

SunSynk SUNSYNK-3.6K-SG01LP1 Manuale utente

SunSynk

SunSynk SUN-8.0 Manuale utente

SunSynk

SunSynk SUNSYNK-6K-SG02LP1 Guida utente

SunSynk

SunSynk SUNSYNK-8K-SG01LP1 Manuale utente

SunSynk

SunSynk SYNK-8K-SG04LP3 Guida utente

SunSynk

SunSynk SUN-8K-SG04LP3 Manuale utente

SunSynk

SunSynk Life3.5Hyb02 Guida utente

SunSynk

SunSynk LIFELYNK ALL-IN-ONE Guida utente

SunSynk

SunSynk SUN-25K-SG01HP3-EU-BM2 Guida utente

SunSynk

SunSynk Power Bank 1000 Manuale utente

SunSynk

SunSynk ECCO SUN-3K-SG04LP1-24-EU Manuale utente

Manuali Invertitore popolari di altre marche

Fourgroup

Fourgroup Easy Manuale utente

Velleman

Velleman PI300M Manuale utente

Sungrow

Sungrow SG350HX-US Manuale utente

WilTec

WilTec 61897 Manuale utente

SMA

SMA SUNNY BOY STORAGE 2.5 Manuale utente

Simplicity

Simplicity LANDLORD 316 Manuale utente

Santak

Santak SMAX 3000 Manuale utente

ATON

ATON RA.Store-3 Manuale utente

ZIEHL-ABEGG

ZIEHL-ABEGG FXET4AMQ Manuale utente

Tektronix

Tektronix CFG250 Manuale utente

Champion

Champion 200989 Manuale utente

Vanner

Vanner 20-500 Series Manuale utente

GE GEP Manuale utente

Astrel Group

Astrel Group Power Reducer Guida rapida

MULTIQUIP

MULTIQUIP GDP-5H Guida

GoWISE

GoWISE PS1007 Manuale utente

Promate

Promate PM13500D ES Manuale utente

Mastervolt

Mastervolt WHISPER 3.5M3000 RPM Manuale utente
