USER MANUAL

Gaming Keyboard

KB-G8400

ENG

Gaming Keyboard

Congratulations on the purchase of Sven keyboard!

Please read this User Manual before using the unit and retain this User Manual in safe place

for future reference.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eorts to make this Manual more exact, some discrepancies may occur.

Theinformation of this Manual is given on “as is” terms. The author and the publisher do notbear

any liability to a person or an organization for loss or damages which have arisen fromtheinfor-

mation contained in the given Manual.

UNPACKING

 Unpack the device carefully. Make sure there are no accessories left in the box. Check up

thedevice for damage; if the product was damaged during transportation, address the ﬁrm

which carried out the delivery; if the product functions incorrectly, address the dealer at once.

 Shipping and transportation equipment is permitted only in the original container.

 Does not require special conditions for realization.

 Dispose of in accordance with regulations for the disposal of household and computer equipment.

 The date of manufacture of the product is indicated on the box.

APPLICATION

KB-G8400 keyboard is an input device. It is designed to enter information into the computer,

aswell as controll the operation of the computer.

PACKAGE CONTENTS

 Keyboard — 1 pc

 User Manual — 1 pc

 Warranty card — 1 pc

SPECIAL FEATURES

 Multifunctional software.

 Programmable buttons.

 12 multimedia (FN) keys.

 Keyboard brightness backlighting adjustment.

 Variable tilt angle.

 Durable braided cable.

SYSTEM REQUIREMENTS

 ОС Windows.

 Free USB port.

INSTALLATION

 Connect the keyboard to an available USB port of your PC.

 Installation of keyboard is automatic after its connection to USB port of PC.

ENG

KB-G8400

User Manual

DESCRIPTION OF QUICK ACCESS KEYS FUNCTION

Fn + F1 Start media player

Fn + F2 Volume down

Fn + F3 Volume up

Fn + F4 Mute/Unmute

Fn + F5 Stop playing

Fn + F6 Play previous track

Fn + F7 Play/Pause

Fn + F8 Play next track

Fn + F9 Start e-mail app

Fn + F10 Open homepage

Note. Press the shortcut keys while holding the Fn key.

INSTALLATION OF THE SOFTWARE

Software is hosted at SVEN ocial web-site www.sven.. Download and install the software. Soft-

ware extends features of keyboard, allows to conﬁgure backlight modes, re-assign keys andpro-

gram macros.



Fn + F11 Lock keyboard

Fn + F12 Start calculator

Fn + WIN WIN key lock

Fn + Increase backlight brightness level

Fn + Decrease backlight brightness level

Fn + W Switch WASD keys to arrows and back

Fn + Scroll

Lock

Change backlighting mode

Fn + “0–9“ Change backlighting mode

Fn + ҉ Turn ON/OFF backlighting

ENG

Gaming Keyboard



In the Fn function window: the keys F1–F12 are assigned withvalues among the functions, pre-

sented in the list. The functions allow to control media player, sound and a keyboard, as well

asopen dierent system programs.

Blocking functions Locking:

  — blocking keyboard

shortcuts;

  — blocking a Windows

key;

  — complete blocking

ofakeyboard.

List of commands, supported for program-

ming the functional buttons.

ENG

KB-G8400

User Manual



In order to re-assign (assign) new functions to the keys, it is necessary to click on a key withamouse.

A window will open, like on a screenshot below.

In a window on the left there are the following settings:

  — returns key assignment by default;

  — multimedia functions;

  — functions to adjust keyboard backlight;

  — assigns FN or Full-key Locked (keyboard blocking) function to a key;

  — disables a key;

  — macro command (it is necessary to programme the macros in advance);

  — assign any button from a keyboard.



In a Conﬁguration window (a button with three dots)

a user can save, load or delete a proﬁle. Inorder tore-

turn to default settings, press Reset.

ENG

Gaming Keyboard



Light menu helps conﬁgure the keyboard backlight

and includes the following operation modes:

  — turning o the backlight;

  — alternate turning on of the selected

colors. Number of indicating colors can be set by a user.

Flicker frequency is set by a user via a Frequency control;

  — the keyboard is lighted with a single set

color, no ickering. Backlight bright-ness is set by a user

via a Brightness control;

  — backlight is turned on when the keyboard

buttons are pressed. Lighting se-quence andnumber

ofcolors is set by a user. Duration andbrightness ofre-

sponse are set by Frequency andBrightness controls.

There is an option to set dierent visual backlight ef-

fects and change their settings;

 Neon — lighted alternately by all seven colors. Flick-

er frequency is set by a user via a Frequency control.

Smooth alternation of colors;

  — progressive wave eect. Flicker fre-

quency is set by a user via a Frequency control. Direc-

tion of the progressive backlight wave can be changed

using Direction (left/right) and Simmety (from the mid-

dle) options;

ENG

KB-G8400

User Manual

  — "comet tail" backlight mode. Lighting eects are conﬁgured the way described

above;

  — lighting eects in a wave form. Also there is an option to control brightness

andbacklight alternation frequency;

  — the backlight ashes in sectors, color of sectors is selected from the palette;

  — sectorial breathing mode with a frequency control option;

  — static backlight of the keyboard.

MACRO menu

Macro is a sequence of events, consisting of pressing and releasing keyboard keys, mouse but-

tons, as well as time intervals between the pressings.

Macros editor window is separated in two parts. Macro area contains a list of groups and names

of macros, Key in macro area shows a list of commands for the selected macro.

The right part contains additional options:

  — repeating a macro while the button is pressed;

  — macro is repeated in cycles at single pressing and releasing of a button,

theﬁrst pressing — start of macro entry, the second pressing — end of macro entry;

  — repeating a macro in cycles at single pressing of a button, number of cycles

can be changed in a right window.

ENG

Gaming Keyboard



In order to create a macro, it is necessary tohov-

er amouse cursor to a Macro window area, click

aright mouse button and select Add a new macro

group fromthe list. By default this creates a group

titled New, then in the same sequence it is nec-

essary tocreate a macro name Add a new macro

(bydefault, a new macro is titled New).



Macro commands are recorded after button is pressed, in a window Key in macro you will

see all the pressed buttons, button ﬁnishes the process of command entry.



In order to edit a macro, click withamouse on a row that you need to edit (the row will be high-

lighted in gray), press and select the required item from the context menu.

ENG

KB-G8400

User Manual





In order to assign a macro in Button menu, it is neces-

sary to click on a selected button, that you need to assign

amacro created earlier.

In an opened window select Macro. In Macro group ﬁeld

select a group of macros from the list. Then in Macro ﬁeld

select the necessary macro from the list.

All the settings can be saved using button, in order

tocancel and close an application press .

In order to save all the changes, press a green button,

and a red button in order to cancel.

Attention: the saved settings operate only withtherun-

ning software; if you close software, key-board will op-

erate by default.

TROUBLESHOOTING

Problem Solution

Кeyboard

isnotworking.

1. Disconnect keyboard from PC and check connector pins forpossible

damage. If there is no external damage found andconnector pins are OK,

connect keyboard to PC again.

2. We recommend to address the nearest authorized service center.

TECHNICAL SPECIFICATIONS

Parameter, measurement unit Value

Q-ty of keyboard keys, pcs 104

Q-ty of media keys, pcs 12 (Fn)

Keyboard layout Eng/Rus/Ukr

OS compatibiltty Windows

Interface USB

Dimensions (L x W x H), mm 460 × 170 × 35 (45)

Weight, g 680

Notes. Technical specications given in this table are supplemental information andcannotgive

occasion to claims. Technical specications are subject to change without notice due to im-

provement of SVEN production.

Technical support is on www.sven. .

RUS

Игровая клавиатура

Благодарим Вас за покупку клавиатуры TM SVEN!

Перед эксплуатацией устройства внимательно ознакомьтесь с настоящим Руководством

и сохраните его на весь период использования.



Данное Руководство и содержащаяся в нем информация защищены авторским правом.



Все торговые марки являются собственностью их законных владельцев.



Несмотря на приложенные усилия сделать Руководство более точным, возможны некото-

рые несоответствия. Информация данного Руководства предоставлена на условиях «как

есть». Автор и издатель не несут никакой ответственности перед лицом или организаци-

ей за ущерб или повреждения, произошедшие от информации, содержащейся в данном

Руководстве.



 Аккуратно распакуйте изделие, проследите за тем, чтобы внутри коробки не остались

какие-либо принадлежности. Проверьте устройство на предмет повреждений. Если изде-

лие повреждено при транспортировке, обратитесь в фирму, осуществляющую доставку;

если изделие не функционирует, сразу же обратитесь к продавцу.

 Перевозка и транспортировка оборудования допускается только в заводской упаковке.

 Не требует специальных условий для реализации.

 Утилизировать в соответствии с правилами утилизации бытовой и компьютерной тех-

ники.

 Дата изготовления продукта указана на коробке.



Клавиатура KB-G8400 это устройство ввода. Она предназначена для ввода (занесения) ин-

формации в комьютер, а также управления работой компьютера.



 Клавиатура — 1 шт.

 Руководство пользователя — 1 шт.

 Гарантийный талон — 1 шт.



 Многофункциональное программное обеспечение.

 Программируемые клавиши.

 12 мультимедиа (Fn) клавиш.

 Регулировка яркости подсветки клавиатуры.

 Изменяемый угол наклона.

 Прочный кабель в оплётке.



 ОС Windows.

 Свободный разъем USB.



 Подключите клавиатуру к свободному USB-порту компьютера.

 После подключения к USB-порту компьютер автоматически распознает устройство.
