OPERATION

MANUAL

SVEN 240

Multimedia Speaker System 2.0

CONTENTS

1. DESCRIPTION .......................................................................................

2. SAFETY PRECAUTIONS ............................................................................

3. PACKAGE CONTENTS ..............................................................................

4. SPECIAL FEATURES .................................................................................

5. LOCATING .............................................................................................

6. CONTROL PANEL ...........................................................................

7. INSTALLATION AND OPERATION GUIDE .......................................................

8. TROUBLE SHOOTING .............................................................................

9. TECHNICAL SPECIFICATION .....................................................................

ENG

Operation Manual sven 240

Technical support is on www.sven.

Congratulations on your purchase of the Sven speaker system!

Please read this operation manual before using the unit and retain this operation manual in safe place

for future reference.

TRADEMARKS

All trademarks are the property of their legal holders.

NOTICE OF RESPONSIBILITY RESTRICTION

Despite the exerted eorts to make this manual more exact, some discrepancies may occur. The

information of this manual is given on «as is» terms. The author and the publisher do not bear any

liability to a person or an organization for loss or damages which have arisen from the information,

contained in the given manual.

UNPACKING

Unpack the device carefully. Make sure there are no accessories left in the box. Check up the

device for damages; if the product was damaged during transportation, address the rm which

carried out the delivery; if the product functions incorrectly, address the dealer at once.

ATTENTION!

Do not switch on the speaker system immediately after you bring it into a room from environment

with negative temperature! After unpacking, the speaker system should be kept in conditions of

room temperature for at least 4 hours.

ENG

Multimedia Speaker System 2.0

Caution! High voltage inside! To avoid the risk of electric shock

do not open or touch elements inside.

1. DESCRIPTION

Sven 240 Multimedia Speaker System 2.0 (MSS) is designed to play music and sound games,

movies, etc. The MSS has a built-in USB cable, due to which it can be connected to a PC or a

laptop. The speaker with a volume control knob is named the active one.

2. SAFETY PRECAUTIONS

•To avoid electric shock, do not open the MSS and do not perform repairs by yourself.

•Do not allow circuit of wires (including grounded ones) between the speakers, power amplier or

ground, for it causes damage of power amplier output stage.

•Do not put foreign objects inside the holes of the MSS. Make sure that needles, hair pins, coins,

insects etc. do not get inside.

•Protect the MSS from high humidity, water and dust. Do not locate it in areas with high level of

humidity and dust.

•Protect the MSS from heating: do not locate it near a heat source or expose to direct sunlight.

•Do not use gasoline, alcohol or other solvents when cleaning, since they may damage the

paint-coated surface of the MSS. Clean it with dry soft cloth only.

•If the MSS does not operate, unplug it and address your dealer.

3. PACKAGE CONTENTS

•Speaker system — 1 pc

•Operation manual — 1 pc

• Warranty card — 1 pc

4. SPECIAL FEATURES

•Easy connection to various audio devices

•Modern design

•Volume control

•Original stands

•USB power supply

•Wall-mountable

•Case material – ABS plastic

5. LOCATING

• Place the speakers symmetrically to the listener.

CONTROL PANEL

aVOLUME: Volume control wheel

ENG

Operation Manual sven 240

8. TROUBLE SHOOTING

Problem

No sound or there is

too quiet sound of

speakers.

Distortion of sound.

Cause

Volume level is set at minimum value.

Large amplitude of the input signal.

Solution

Adjust volume control knob.

Turn down the source volume

and MSS volume.

If none of the above methods can solve the problem, please seek professional advice at your

nearest service center. Never attempt to repair the product yourself.

Fig. 1. Connection diagram

7. INSTALLATION AND OPERATION

Sven 240 Multimedia Speaker System can be connected to a PC or a laptop (see Fig. 1 below).

• Before connecting, make sure that the MSS is unplugged.

• Connect the USB cable built into the active speaker to a

USB port of your PC or laptop, as shown in Fig.1.

• Set volume level to the minimum by turning VOLUME wheel a. Turn on your PC or laptop.

• Adjust the volume level by means of Windows utilities or by turning VOLUME wheel a.

Notes:

• Power and audio signal are both supplied via the built-in USB cable.

•After using the MSS, mind to disconnect the USB cable from the PC USB port.

Parameter, measurement unit

Output power (RMS), W

Frequency range, Hz

Speaker size, mm

Voltage supply, V/Hz

Dimensions (one satellite) (W × H × D), mm

Weight, kg

Value

4 (2 × 4)

100 – 20 000

Ø 45

~ 220/50

100 × 225 × 100

0.55

9. TECHNICAL SPECIFICATION

Notes:

• Technical specication given in this table is supplemental information and cannot give

occasion to claims.

• Technical specication is subject to change without notice due to improvement of SVEN

production.

ENG

Multimedia Speaker System 2.0

SVEN 240

Multimedia Speaker System 2.0

:

SVEN 240

  :  «»,

111024, , . , . , . 65, . 1.

   :  «-»,

105082, . , .  , . 75, . 5.

    

     www.sven.

 : 12 .

 : 2 

   « 

», 48310, , ,

, 15.   .

:

SVEN 240

/  :  « ».

 , . -,

.  , 31.

,    

   .    .

    

     www.sven.

 : 12 .

 : 2 

 /  .

   .    .

   « 

», 48310, , , , 15.

  .

  : «GREENWAVE INDUSTRIAL LTD»,

4210, Oce Tower, Convention Plaza,

1 Harbour Road, Wanchai, Hong Kong, China

Produced under the control of Oy Sven Scandinavia Ltd.

15, Kotolahdentie, KOTKA, Finland, 48310.

Made in China.

® Registered Trademark of Oy SVEN

Scandinavia Ltd. Finland.
