Swann AMU Powercon Manuale utente
AMU Powercon
Version 6.20 and higher
A-96.250.331 / 230320
Operator’s Manual
© 2019, SWAN ANALYTISCHE INSTRUMENTE AG, Switzerland, all rights reserved
subject to change without notice.
Customer Support
SWAN and its representatives maintain a fully trained staff of technical specialists
around the world. For any technical question, contact your nearest
SWAN representative, or the manufacturer:
SWAN ANALYTISCHE INSTRUMENTE AG
Studbachstrasse 13
8340 Hinwil
Switzerland
Internet: www.swan.ch
E-mail: [email protected]
Document Status
Title: AMU Powercon Operator’s Manual
ID: A-96.250.331
Revision Issue
00 Sept. 2006 First Edition
01 March 2013 Update to FW release 5.30
02 July 2019 Update to FW release 6.20
AMU Powercon
A-96.250.331 / 230320 1
Table of Contents
1. Product Description. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.1. Description of the System . . . . . . . . . . . . . . . . . . . . . . . . 3
1.2. Single Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
1.2.1 AMU Powercon Transmitter . . . . . . . . . . . . . . . . . . . . . 6
1.2.2 Swansensor UP-Con1000 . . . . . . . . . . . . . . . . . . . . . . 8
1.2.3 Flow Cells . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2. Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.1. Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
2.2. Dimensions of the AMU Transmitter . . . . . . . . . . . . . . . . 11
2.3. Install the Flow Cell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2.4. Connecting Sample Inlet and Outlet . . . . . . . . . . . . . . . . 14
2.4.1 Swagelok Fitting Stainless Steel at Sample Inlet. . . . . 14
2.4.2 FEP Tube at Sample Outlet . . . . . . . . . . . . . . . . . . . . . 15
2.5. Install the Conductivity Sensor. . . . . . . . . . . . . . . . . . . . . 15
2.6. Installation of Cation Exchanger . . . . . . . . . . . . . . . . . . . 16
2.7. Electrical Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.8. Power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.9. Sensor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.10. Flow Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.11. Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
2.12. Relay Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.12.1 Alarm Relay . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.12.2 Relay 1 and 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
2.13. Signal Output 1 and 2 (current outputs). . . . . . . . . . . . . . 20
2.14. Interfaces . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.14.1 RS232 Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.14.2 Profibus (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
2.14.3 Modbus (optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
3. Instrument Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.1. Establish sample flow . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
3.2. Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4. Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.1. Keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.2. Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.3. Software Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.4. Changing Parameters and values . . . . . . . . . . . . . . . . . . 28
2A-96.250.331 / 230320
AMU Powercon
5. Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.1. Maintenance Schedule. . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.2. Stop of Operation for Maintenance . . . . . . . . . . . . . . . . . 29
5.3. Maintenance of the Sensor . . . . . . . . . . . . . . . . . . . . . . . 30
5.3.1 Remove the Sensor from the Flow Cell . . . . . . . . . . . . 30
5.3.2 Install the Sensor into the Flow Cell . . . . . . . . . . . . . . . 30
5.4. Changing the Ion Exchanger . . . . . . . . . . . . . . . . . . . . . . 31
5.5. Changing the inlet filter . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.6. Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
5.7. Longer Stop of Operation. . . . . . . . . . . . . . . . . . . . . . . . . 35
6. Error List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7. Program Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.1. Messages (Main Menu 1). . . . . . . . . . . . . . . . . . . . . . . . . 39
7.2. Diagnostics (Main Menu 2) . . . . . . . . . . . . . . . . . . . . . . . 40
7.3. Maintenance (Main Menu 3) . . . . . . . . . . . . . . . . . . . . . . 41
7.4. Operation (Main Menu 4) . . . . . . . . . . . . . . . . . . . . . . . . . 41
7.5. Installation (Main Menu 5) . . . . . . . . . . . . . . . . . . . . . . . . 42
8. Program List and Explanations . . . . . . . . . . . . . . . . . . 44
1 Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
2 Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
3 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
4 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
5 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
9. Material Safety Data sheets. . . . . . . . . . . . . . . . . . . . . . 59
9.1. Cation Exchanger Resin SWAN. . . . . . . . . . . . . . . . . . . . 59
10. Default Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
11. Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
12. Notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
AMU Powercon
Safety Instructions
A-96.250.331 / 230320 3
AMU Powercon–Operator’s Manual
This document describes the main steps for instrument setup, oper-
ation and maintenance.
1. Safety Instructions
General The instructions included in this section explain the potential risks
associated with instrument operation and provide important safety
practices designed to minimize these risks.
If you carefully follow the information contained in this section, you
can protect yourself from hazards and create a safer work environ-
ment.
More safety instructions are given throughout this manual, at the
respective locations where observation is most important.
Strictly follow all safety instructions in this publication.
Target
audience
Operator: Qualified person who uses the equipment for its intended
purpose.
Instrument operation requires thorough knowledge of applications,
instrument functions and software program as well as all applicable
safety rules and regulations.
OM Location The AMI Operator’s Manual shall be kept in proximity of the instru-
ment.
Qualification,
Training
To be qualified for instrument installation and operation, you must:
read and understand the instructions in this manual as well as
the Material Safety Data Sheets.
know the relevant safety rules and regulations.
4A-96.250.331 / 230320
AMU Powercon
Safety Instructions
1.1. Warning Notices
The symbols used for safety-related notices have the following sig-
nificance:
DANGER
Your life or physical wellbeing are in serious danger if such
warnings are ignored.
Follow the prevention instructions carefully.
WARNING
Severe injuries or damage to the equipment can occur if such
warnings are ignored.
Follow the prevention instructions carefully.
CAUTION
Damage to the equipment, minor injury, malfunctions or incor-
rect process can be the consequence if such warnings are ig-
nored.
Follow the prevention instructions carefully.
Mandatory
Signs
The importance of the mandatory signs in this manual.
Safety goggles
Safety gloves
AMU Powercon
Safety Instructions
A-96.250.331 / 230320 5
Warning Signs The importance of the warning signs in this manual.
1.2. General Safety Regulations
Legal
Requirements
The user is responsible for proper system operation. All precau-
tions must be followed to ensure safe operation of the instrument.
Spare Parts
and
Disposables
Use only official SWAN spare parts and disposables. If other parts
are used during the normal warranty period, the manufacturer’s
warranty is voided.
Modifications Modifications and instrument upgrades shall only be carried out by
an authorized Service Technician. SWAN will not accept responsi-
Electrical shock hazard
Corrosive
Harmful to health
Flammable
Warning general
Attention general
6A-96.250.331 / 230320
AMU Powercon
Safety Instructions
bility for any claim resulting from unauthorized modification or alter-
ation.
WARNING
Electrical Shock Hazard
If proper operation is no longer possible, the instrument must be
disconnected from all power lines, and measures must be taken
to prevent inadvertent operation.
To prevent from electrical shock, always make sure that
the ground wire is connected.
Service shall be performed by authorized personnel only.
Whenever electronic service is required, disconnect in-
strument power and power of devices connected to.
– relay 1,
– relay 2,
– alarm relay
WARNING
For safe instrument installation and operation you must read
and understand the instructions in this manual.
WARNING
Only SWAN trained and authorized personnel shall perform the
tasks described in this document.
Download
MSDS
The current Material Safety Data Sheets (MSDS) for the Reagents
listed below are available for downloading at www.swan.ch.
Product name: Cation Exchange Resin
Catalogue number: A-82.841.030 and A-82.841.031
AMU Powercon
Product Description
A-96.250.331 / 230320 3
1. Product Description
1.1. Description of the System
This instrument is applicable for the measurement of conductivity in
high purity water applications.
The AMU Powercon measures the specific (total) conductivity or
the acid (cation) conductivity of a sample. For the measurement of
the acid conductivity a cation exchanger bottle is necessary. The
transmitter can be used with a two-electrode conductivity sensor
with an integrated Pt1000 temperature sensor, e.g. Swansensor
UP-Con1000.
Application
Range
The conductivity is a parameter for the total quantity of ions present
in the solution. It can be used for the controlling of:
the condition of waters
water purification
water hardness
completeness of ion analysis
Special
Features
Many temperature compensation curves for specific conductivity
measurement:
none
Coefficient
Neutral salts
High-purity water
Strong acids
Strong bases
Ammonia, Eth. am.
Morpholine
Signal
Outputs
Two signal outputs programmable for measured values (freely scal-
able, linear, bilinear, log) or as continuous control output (control
parameters programmable).
Current loop: 0/4–20 mA
Maximal burden: 510 Ω
Relays Two potential-free contacts programmable as limit switches for
measuring values, controllers or timer for system cleaning with au-
tomatic hold function.
Maximum load: 100 mA/50 V
4A-96.250.331 / 230320
AMU Powercon
Product Description
Alarm Relay One potential free contact. Summary alarm indication for program-
mable alarm values and Instrument faults.
Available in two configurations:
Normally open*: Closed during normal operation, open in case of
error or power loss.
Normally closed: Open during normal operation, closed in case
of error or power loss
*Standard configuration. To order the version with normally closed
alarm relay, contact your dealer in advance.
Maximum load: 100 mA/50 V
Input One input for potential-free contact to freeze the measuring value
or to interrupt control in automated installations. Programmable as
HOLD or OFF function.
Communica-
tion interface
RS232 for logger download with HyperTerminal
RS485 with Fieldbus protocol Modbus or Profibus DP (optional)
Safety
Features
No data loss after power failure. All data is saved in non-volatile
memory.
Over voltage protection of in- and outputs.
Galvanic separation of measuring inputs and signal outputs.
Measuring
principle
When a voltage is set between two electrodes in an electrolyte
solution, the result is an electric field which exerts force on the
charged ions: the positively charged cations move towards the neg-
ative electrode (cathode) and the negatively charged anions to-
wards the positive electrode (anode). The ions, by way of capture
or release of electrons at the electrodes, are discharged and so a
current I flows through this cycle and the Ohms law V = I×R ap-
plies. From the total resistance R of the current loop, only the resis-
tance of the electrolyte solution, respectively its conductivity 1/R, is
of interest.
The cell constant of the sensor is determined by the manufacturer
and is printed on the sensor label. If the cell constant has been pro-
grammed in the transmitter, the instrument measures correctly.
Measuring unit is S/cm or S/m.
Specific
Conductivity
Conductivity from all ions in the sample, mainly the alkalization
agent. The contribution of impurities is masked by the alkalization
agent.
Cation Con-
ductivity (Acid
Conductivity):
The alkalization agent is removed in the cation column. All cationic
ions are exchanged with H+, all anionic impurities (ions with nega-
tive charge) pass through the column unchanged.
Indice
Altri manuali Swann Trasmettitore
