Syscom Video INT100 Manuale utente
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
COMPLIANCE NOTICE OF FCC:
THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS
FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES.
THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A
COMMERCIAL ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN
RADIATE RADIO FREQUENCY ENERGY AND IF NOT INSTALLED AND USED IN
ACCORDANCE WITH THE INSTRUCTION MANUAL, MAY CAUSE HARMFUL
INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS EQUIPMENT
IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE, IN
WHICH CASE USERS WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT
THEIR OWN EXPENSE.
CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE
PARTY RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY
TO OPERATE THE EQUIPMENT.
THIS CLASS OF DIGITAL APPARATUS MEETS ALL REQUIREMENTS OF THE
CANADIAN INTERFERENCE-CAUSING EQUIPMENT REGULATIONS.
THE INFORMATION IN THIS MANUAL IS BELIEVED TO BE ACCURATE AS OF THE DATE OF
PUBLICATION. IDIS, CO., IS NOT RESPONSIBLE FOR ANY PROBLEMS RESULTING FROM THE
USE THEREOF. THE INFORMATION CONTAINED HEREIN IS SUBJECT TO CHANGE WITHOUT
NOTICE. REVISIONS OR NEW EDITIONS TO THIS PUBLICATION MAY BE ISSUED TO
INCORPORATE SUCH CHANGES.
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and maintenance (servicing)
instructions in the literature accompanying the appliance.
1. Read Instructions
All the safety and operating instructions should be read
before the appliance is operated.
2. Retain Instructions
The safety and operating instructions should be retained
for future reference.
3. Cleaning
Unplug this equipment from the wall outlet before
cleaning it. Do not use liquid aerosol cleaners. Use a damp
soft cloth for cleaning.
4. Attachments
Never add any attachments and/or equipment without the
approval of the manufacturer as such additions may result
in the risk of fire, electric shock or other personal injury.
5. Water and/or Moisture
Do not use this equipment near water or in contact with
water.
6. Accessories
Do not place this equipment on an unstable cart, stand or
table. The equipment may fall, causing serious injury to a
child or adult, and serious damage to the equipment. Wall
or shelf mounting should follow the manufacturer’s
instructions and a mounting kit approved by the
manufacturer should be used.
This equipment and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the equipment and cart combination to
overturn.
7. Ventilation
Slots and openings in the cabinet and the back or bottom
are provided for ventilation, to ensure reliable operation of
the equipment, and to protect it from overheating. These
openings must not be blocked or covered. Do not block
these openings or allow them to be blocked by placing the
equipment on a bed, sofa, rug, or bookcase. Ensure that
there is adequate ventilation and that the manufacturer’s
instructions have been adhered to.
8. Power Sources
This equipment should be operated only from the type of
power source indicated on the marking label. If you are
not sure of the type of power, please consult your
equipment dealer or local power company.
9. Power Cords
Do not allow anything to rest on the power cord. Do not
locate this equipment where the cord will be damaged by
persons walking on it.
10. Lightning
For added protection for this equipment during a lightning
storm or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will prevent
damage to the equipment due to lightning and power-line
surges.
11. Overloading
Do not overload wall outlets and extension cords as this
can result in the risk of fire or electric shock.
12. Objects and Liquids
Never push objects of any kind through openings of this
equipment as they may touch dangerous voltage points or
short-out parts that could result in a fire or electric shock.
Never spill liquid of any kind on the equipment.
13. Servicing
Do not attempt to service this equipment yourself. Refer
all servicing to qualified service personnel.
14. Damage Requiring Service
Unplug equipment from the wall outlet and refer servicing
to qualified service personnel under the following
conditions:
A. When the power-supply cord or the plug has been
damaged.
B. If liquid is spilled, or objects have fallen into the
equipment.
C. If the equipment has been exposed to rain or water.
D. If the equipment does not operate normally by
following the operating instructions, adjust only those
controls that are covered by the operating instructions as
an improper adjustment of other controls may result in
damage and will often require extensive work by a
qualified technician to restore the equipment to its normal
operation.
E. If the equipment has been dropped, or the cabinet
damaged.
F. When the equipment exhibits a distinct change in
performance, indicating a need for service.
15. Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer or that have the same characteristics as the
original part. Unauthorized substitutions may result in fire,
electric shock, or other hazards.
16. Safety Check
Upon completion of any service or repairs to this
equipment, ask the service technician to perform safety
checks to determine that the equipment is in proper
operating condition.
17. Field Installation
This installation should be made by a qualified service
person and should conform to all local codes.
IMPORTANT SAFEGUARDS
Product Information
Installation
1. Connection via LAN
2. Connection via Dial-up Modem
How to Use INT100
1. INTBase100 (INT100 Browser)
2. INT100 Administration Page
Appendixes
1. Technical Specifications
2. Troubleshooting
05
07
07
11
12
12
17
26
26
27
Table of Contents
Copyright 2001 IDIS Co., Ltd.
Any copy or reproduction of this manual is prohibited in any manner or form without the prior
written consent of IDIS Co., Ltd.
Notice
The information in this manual was current when published. The manufacturer reserves the right
to revise and improve its products. All specifications are therefore subject to change without
notice.
Important Information
Before proceeding, please read and observe all instructions and warnings contained in this
manual. Retain this manual with the original bill of sale for future reference and, if necessary,
warranty service.
INT100 User Manual
4
C
Intelligent Network Transmitter
5
With the Intelligent Network Transmitter 100 (INT100), IDIS provides an advanced solution for
retrieving video over computer networks, including the Internet. The INT100 grabs composite
video images from one video input, compresses them, and then transmits them over computer
networks or telephone lines at speeds up to 30 frames per second. In addition to video access, the
INT100 provides audio and alarm information from the remote site. There are one sensor input
and one alarm input.
The user can listen in on the remote site with the audio input. The INT100 is capable of remotely
controlling pan, tilt, zoom, and focusing cameras. All of the INT100 features are accessible
through Internet web browsers, allowing users to access and control their systems any time from
virtually anywhere.
1. Features
A) Monitor live video images transmitted in real-time
Remote monitoring up to 30fps live video images using IDIS's unique algorithm
Low network bandwidth requirement: 3KB per image typical
Three-levels of input resolution: 640x480, 320x240, 160x120
Four-levels of image compression
B) Simultaneous video and audio signal transmission
Monitor voices and background sounds via one audio input
C) Supports various network environments
Ethernet or Fast Ethernet interface for Internet
Modem interface for standard telephone lines
D) Easy software upgrades from anywhere
Upgrade software at remote sites using a web browser
E) E-mail transmission ensures important events are not missed
Video can be transmitted to assigned e-mail addresses whenever a sensor detects
an input signal
F) Additional convenient features
Remote multiplexer control through RS485 interface
Note: This function requires an additional software for each supported multiplexer model.
Autosensing for the video format (NTSC/PAL)
One digital sensor input and one alarm output
RS485 interface for Pan/Tilt/Zoom/Focus control
One video loop-through terminal
Each function can be set remotely using a web browser
G) Compatible with other IDIS products
Build a cost-effective, large-scale security system
Product Information
INT100 User Manual
6
2. System Configuration
3. System Components
INT100
Adapter (12VDC, 1A)
INTBase100 Installation Diskette for Modem Connection
MINIDIN-8/DB-9 Converter for Modem Connection
User Manual
4. Monitoring System Requirements
OS: Microsoft Windows 98
CPU: Intel Pentium II Celeron 266MHz or higher
RAM: 32MB or higher
VGA: AGP, Video RAM 4MB or higher
Web Browser: Internet Explorer 5.0 or higher version
Intelligent Network Transmitter
7
1. Connection via LAN
1.1 Cable
Connect LAN, a camera, and/or a sensor cable to the appropriate ports on the back panel.
1.2 Power
Connect the power cable to the appropriate port on the back panel. The INT100 has been booted
normally if POWER LED blinks once within 10 seconds.
1.3 PC Setup
Use a PC that can network with the INT100 without a router.
(From now on, this particular PC will be referred to as “PC.”)
Video Out
INT100 Back Panel
INT100 Front Panel
Network
Installation
I/O Port Power Jack
RS232 Reset
Audio In Video In
INT100 User Manual
8
1.4 Configuring PC Network
Under Start in Windows, go to Settings, Control Panel, and then Network Setting. In the
Configuration tab, select the TCP/IP and then click Properties. Modify your network configuration
as shown below. Make a note of the existing network configuration values since you will need to
restore them in Step 1.8.
Note: You may need to reboot after this step.
Example) IP Address: 192.168.1.150
(In fact, fourth address may be any value from 1 to 254, except 129.)
Subnet Mask: 255.255.255.0
Intelligent Network Transmitter
9
1.5 Verifying Network Setup
Under Start in Windows, go to Programs, then choose MS-DOS Prompt. Enter the ping command
(ping -t 192.168.1.129).
Note: By sending a packet to the specified address and waiting for a reply, the PING (Packet
Internet Groper) can determine whether a specific IP address is accessible.
If the ping utility returns “Reply from 192.168.1.129...,” it means that the address has been set and
communication is established.
If the ping utility continually returns “Request timed out,” go back to Step 1.2 and try again.
1.6 Administrator Configuration
Start your Web browser and enter “http://192.168.1.129/admin_login.html” in the
location/address field. The INT100 Administrator Login Page will appear. Enter a login ID and
password. The default ID is admin, and the password is 12345. Refer to the “INT100
Administration Page” section for details.
