System Q NiteDevil 24C Manuale utente

NiteDevil 24C Camera

SEE702

2MP Eyeball 2.8mm Built In Mic

Instruction Manual

NiteDevil.com

xSEE702

NiteDevil.com

Table of Contents

Part 1 Introduction 1

1 SEE702 ............................................................................................................................ 1

Part 2 Tools & Handy Extras 1

Part 3 Connections 2

Part 4 4-In-1 Technology 2

Part 5 OSD Menu 3

1 2MP OSD Menu ............................................................................................................... 4

2 Key Menu Settings .......................................................................................................... 5

Part 6 Audio Over COAX 6

Part 7 Troubleshooting 7

1 Camera Rebooting / Turning Off ..................................................................................... 7

2 Poor Quality Images ....................................................................................................... 7

3 Image isBlack & White .................................................................................................. 7

4 NCD / No Image Displayed on Recorder ......................................................................... 7

Part 8 General Maintenance 8

Part 9 Specification 9

1 SEE702 ............................................................................................................................ 9

Part 10 Conditions 10

1 General Company Disclaimer ....................................................................................... 10

2 WEEE Declaration ......................................................................................................... 10

3 Copyright ...................................................................................................................... 10

Index 11

Introduction

NiteDevil.com

Introduction

1.1 SEE702

The all new NiteDevil® 24C can stay in fullcolour around the clock using the minimalamount of

naturallight to produce superb fullcolour images. It really is a game changer inperformance and

should be used as a part of any CCTV systemrequiring fullcolour images in key areas around

entrances etc.

With built in dualIR and white light you can choose how the camera best works in your install.

Using white light to give visualwarning or using IR illumination to get a more discreet set up.

A built in microphone means you can see and hear what's happening, recording the audio &

video on your ZIP SUPA-S DVR for the best possible CCTV evidence.

Tools & Handy Extras

Screwdriver

Drill

12V DC PSU

Drillbits

BNC Crimp Tool& BNCs

RG59 Coax Cable

DigitalMulti-Meter

LCD400K - CCTV Test monitor

31/03/2022

xSEE702

2NiteDevil.com

Connections

The camera has a 2.1mmsocket which requires 12V DC, use a regulated power supplyrated

above the current draw ofthe camera.

The camera is polarity sensitive so connections must be correctly made.

The camera has a standard BNC connector for video output, the output can be changed to

AHD, CVI or CVBS if required in the menu

4-In-1 Technology

Selectable HD-TVI, HD-CVI, AHD and CVBS (Analogue) Output. As default the camera is

set to HD-TVI, however the output can be changed to AHD, CVI or CVBS ifrequired.

This output can be changed with in the menu camera. Please note the "Mode” in the menu of the

DVR won’t change the format, as the menuoverrides the output.

See OSD Menu for accessing and changing the video format.

OSD Menu

NiteDevil.com

OSD Menu

Access to the camera menu is by Coaxitron. For the ZIP DVRs, ZIP Coaxitron is set as

default.

To access the Cameras Menu via coaxitron:-

1. Click on the image in Live view

2. Click on the PTZ button at the bottomofthe screen

3. Click on the IRIS + / centre button to display the menu

Use the directionalarrows to move up and

down through the menu.

Use the directionalarrows left and right to

change the option.

Use IRIS + to select & enter that menuoption.

31/03/2022

xSEE702

4NiteDevil.com

5.1 2MP OSD Menu

Format

2M25 / 2M30 / PAL

Video Mode

TVI / AHD / CVI / CVBS

Language

English / Spanish / French/ Chinese

Exposure

Exposure Mode

Global / BLC / HLC / DWDR

AGC

High / Middle / Low

Back

Exit

Save – Exit

Volume

0 – 9 (9 Default - NOT USED)

Day & Night

Mode

Ext / Color / B/W

Dim

0 – 3 (3 Default)

Back

Exit

Save – Exit

Video Settings

AWB

Auto

Brightness

1 -9 (5 Default)

Contrast

1 -9 (5 Default)

Sharpness

1 -9 (5 Default)

Saturation

1 -9 (5 Default)

Mirror

Default / Mirror / Flip / Rotate

Back

Exit

Save – Exit

Reset

Exit

Save – Exit

OSD Menu

NiteDevil.com

5.2 Key Menu Settings

Exposure Mode - AUTO / GLOBE / GLOBAL sets the required shutter speed for the current

light level. The shutter speed willautomatically detect the required lengthoftime to keep the

digitalsensor exposed to light. FLK optionsets the shutter speed to stop synchronisation with

lighting so that pulsing effect is minimised.

White Balance - Colour adjustment of the camera to be set up so objects appear a natural

colour. ATW / PRO (Automatic trackingwhite balance) continually tracks and adjusts the white

balance, making it suitable for use in cameras in which the image content and lighting are subject

to changes.

Day & Night - The camera canbe set to colour or B&W mode or have it automaticallyswitch

Externalis set as default, the switch betweencolour and black & white is controlled by an

externaltrigger In this a light dependent resistor.

DNR (Noice Reduction) - Noise Reduction is the process ofremovingnoise fromthe video

signalby applying a digitalfilter. 2D noise reduction reduces noise in the foreground ofthe image

where as 3D noise reduction reduces noise in both the foreground and the background ofthe

image.

D-WDR - Digitally adjusts the exposure in areas ofthe frame to maintain optimum levels in both

the dark and bright areas ofan image.

NOTE - Some models may not have D-WDR function.

Reset - Defaults the camera to factory settings. This setting helps when fault finding issues with

the camera to ensure allsettings are defaulted.

31/03/2022

xSEE702

6NiteDevil.com

Audio Over COAX

As of writing this (March 2022), the Audio over COAX (CoaxialAudio) is compatible withthe ZIP

SUPA-S range ofrecorders.

*Note the standard SUPA recorders are not compatible with Audio over COAX.

To enable, in the menu on the SUPA-S go to System > General > Audio Input Type

Select Coaxial Audio

Select Apply

Troubleshooting

NiteDevil.com

Troubleshooting

7.1 Camera Rebooting / Turning Off

A. Check the voltage to the camera (under load) using a digitalmulti-meter, ifbelow 10.8V then

move the power supply closer to the camera.

B. For 12V DC cameras, only use regulated power supply rated above the current consumption,

so that the camera is always receiving the correct supplywhichis rated above the current

consumption.

C. Use thicker gauge copper cablingto reduce the voltage drop to the camera, using thicker

cable willreduce the resistance betweenthe camera and the power supply and therefore reduce

the voltage dropped along the cable.

7.2 Poor Quality Images

A. Check the video format the DVR (digitalvideo recorder), thenset the camera to the relevant

video format – see the 4-In-1 Technology

B. Ifset to CVBS, thenthis is a low quality video output for legacy systems (analogue - CVBS),

when usinga 2 MegaPixelDVR or above then use another video format, like HD-TVI.

C. Reset the camera menuvia Zip Coaxitron – OSD Menu

D. Check ifthe DVR (digitalvideo recorder) supports the resolutionofthe camera.

7.3 Image is Black & White

A. Check the video format your DVR supports, thenset the camera to the relevant video format

– see the 4-In-1 Technology

B. Reset the camera menuvia Zip Coaxitron OSD Menu

D. Check ifthe DVR (digitalvideo recorder) supports the resolutionofthe camera.

7.4 NCD / No Image Displayed on Recorder

A. Check the voltage to the camera (under load) using a digitalmulti-meter, ifbelow 10.8V then

move the power supply closer to the camera.

B. For 12V DC cameras, only use regulated power supply rated above the current consumption,

so that the camera is always receiving the correct supplywhichis rated above the current

consumption.

31/03/2022

xSEE702

8NiteDevil.com

C. Use thicker gauge copper cablingto reduce the voltage drop to the camera, using thicker

cable willreduce the resistance betweenthe camera and the power supply and therefore reduce

the voltage dropped along the cable.

D. Ensure that the BNC – BNC lead that is connected betweenthe camera and DVR has no

shorts between the ground and the centre core (positive) or open circuits along the centre core

(positive) or open circuits along the ground.

General Maintenance

Routinely clean the camera to prevent dust build up as this can effect the performance ofthe

camera. It is recommended to use a damp non-abrasive microfibre cloth.

Routinely check the connections for power and data to ensure no water ingress and corrosion.

Check that the cameras are firmly attached to the wallor mounting bracket.

Check playback in the recorder to ensure the camera is recording and triggering properly.
