Targus Optical Bluetooth Mouse Manuale utente

USER GUIDE

Visit our Website at www.targus.com Features and

specifications subject to change without notice.

AMB06US / 410-1183-001A

Optical

Bluetooth®

Mouse

ID# B0

Bluetooth Qualified Product

TARGUS OPTICAL

BLUETOOTH®MOUSE

Introduction

Congratulations on your purchase of the Targus Optical Bluetooth

Mouse. This mouse uses Bluetooth wireless technology which

provides seamless connections up to 30ft (10M) in range.

System Requirements

Hardware

•Bluetooth-enabled notebook or desktop PC

Operating System

•Windows® 2000 / XP

•Windows VistaTM

• Mac OS X 10.2.8 (or greater)

Installing the Batteries (Included)

• Use the two AAA-size rechargeable NIMH batteries (Included)

WARNINGS: WHEN REPLACING THE BATTERIES, ALWAYS REPLACE WITH NiMH

BATTERIES OR OTHER RECHARGEABLE BATTERIES. NEVER USE ALKALINE

BATTERIES IN A DEVICE. AVOID MIXING NEW AND USED BATTERIES IN A DEVICE.

• Turn on the mouse by sliding on/off switch on the bottom of the mouse

to the “on” position.

• Snap the battery cover back into position.

• Remove the battery cover from the top of the mouse by sliding off the

cover of the mouse.

• Insert the batteries, making sure that the positive (+) and negative (-)

ends of each battery match the polarity indicators inside the battery

housing

Targus Optical Bluetooth Mouse

Mouse Power Management

• To power the mouse on and off, slide the on/off switch at the bottom

of the mouse to the desired position.

• During operation, the power saving feature puts the mouse into

"sleep mode" after 8 minutes of inactivity. Click any mouse button to

re-activate the mouse.

• To save battery power, turn off the mouse while traveling or while not

in use.

• The scroll wheel will glow when the batteries are low. To recharge the

mouse, plug in the USB Recharging Cable to the mouse, and plug USB

connector into any available USB port on the computer. While

charging, the mouse remains operational and connected via the

wireless Bluetooth technology.

For USB Recharging Cable

(Power Use ONLY)

Charging the Rechargeable Batteries

Charge the mouse for 8 hours before use. Plug in the USB charge

cable to the mouse and to an available USB port on the computer.

Targus Optical Bluetooth Mouse

1. Charge the mouse for at least 8 hours before using it. And please

make sure only rechargeable batteries (included) are used.

2. Your computer needs to stay powered on for the mouse to charge.

Follow these steps to prevent your computer from going in to Standby

or Hibernate:

a) Click “Start”

b) Click “Control Panel”

c) Click “Performance and Maintenance” (Skip in Classic View)

d) Click “Power Options”

e) Make sure “System Standby:” and “System Hibernates:” under

“Plugged in” are set to “Never”

3. If you use your notebook computer’s LCD monitor, please do not

close the lid. (Please ignore this step if you use an external monitor

with your notebook lid closed.)

4. If your mouse does not respond after a period of inactivity, please

wake it up by pressing one of the buttons on the mouse and moving the

mouse around.

Targus Optical Bluetooth Mouse

Establishing a Communications Link

Initial Configuration

Connecting with Bluetooth Software:

WIDCOMM or Microsoft (Windows XP & Windows Vista)

1. Go to the Bluetooth Places icon located on your desktop or in the

system tray and double click, then click Add a Bluetooth Device.

(Windows XP) (Windows Vista)

Before you can begin using Bluetooth connectivity on your computer

and other Bluetooth devices, you must set up your Bluetooth connec-

tion correctly. Please make sure this is performed before establishing

the connection with the Bluetooth device.

The Targus Optical Bluetooth Mouse is designed to work with the four

major software stack (protocol) standards: WIDCOMM, Toshiba and

Microsoft and Mac OS X. Please check your computer’s documentation

to see which software stack your computer has. Please contact your

system vendor if your system does not support one of the following

Bluetooth software standards.

NOTE: PLEASE USE THE LATEST BLUETOOTH DEVICE DRIVER. INSTRUCTION

SCREENS MIGHT VARY DEPENDING ON THE VERSION OF YOUR BLUETOOTH DEVICE

DRIVER.

Targus Optical Bluetooth Mouse

2. The Bluetooth Wizard screen will prompt. Please follow the on-

screen instructions.

3. Please turn on the mouse and press the connection ID button

located at the bottom of the mouse until the LED on the mouse blinks

red (discovery mode). Click Next to continue pairing and the computer

will search for the mouse.

(Windows XP) (Windows Vista)

Targus Optical Bluetooth Mouse

4. The confirmation window will appear after the computer finishes

detecting the Bluetooth devices. Select the Bluetooth Wireless Mouse

and click Next to continue. (There may be one or more different

Bluetooth devices detected.) If the mouse is not detected, please make

sure the power is on and in discovery mode. Press Search Again to

re-pair the device.

(Windows Vista)

(Windows XP)

5. After selecting the correct device, the computer will finish establish-

ing the connection. Please wait until the setup is completed.

(Windows Vista)

(Windows XP)

Targus Optical Bluetooth Mouse

Connecting with Bluetooth Software:

TOSHIBA (Windows Vista)

1. Double click on the Bluetooth Manager icon in the system tray, and

then click Add New Connection.

2. Please turn on the mouse and press the connection ID button

located at the bottom of the mouse until the LED on the mouse blinks

red (discovery mode). Click Next to continue pairing and the computer

will search for the mouse.

Targus Optical Bluetooth Mouse

3. The computer will now search for the Bluetooth mouse and other

Bluetooth devices. Please wait until the search is completed. Choose

the device you wish to connect. There may be more than one Bluetooth

device detected. Select Bluetooth Wireless Mouse and click Next to

continue. If the mouse is not detected, please make sure the mouse is

in discovery mode and click Refresh.

4. The computer will begin connecting with the device.
