TE Connectivity PRO-CRIMPER III Manuale utente

Instruction Sheet

1 of 11

TE Connectivity, TE connectivity (logo), and TE (logo) are trademarks. Other logos, product, and/or company names may be trademarks of their respective owners.

PRODUCT INFORMATION

1-800-522-6752

This controlled document is subject to change.

For latest revision and Regional Customer Service,

visit our website at www.te.com.

408-8678

12 JUL 2022 Rev F

PROPER USE GUIDELINES

Cumulative trauma disorders can result from the prolonged use of manually powered hand tools. Hand tools are intended for occasional

use and low-volume applications. A wide selection of powered application equipment is available for extended-use production operations.

Figure 1: PRO-CRIMPER III Hand Crimping Tool Assembly 58546-1 with Die Assembly 58545-1

Die set 58545-1

Ratchet adjustment wheel

Crimper (upper die)

Ratchet adjustment screw

Anvil (lower die)

Pivot pin

Stationary jaw

Die-retaining screws (2)

Moving jaw

Handle

Emergency ratchet release

The PRO-CRIMPER III Hand Crimping Tool is a commercial-grade tool and is designed primarily for field installation,

repair, maintenance work, or prototyping in industrial, commercial, or institutional applications. Product crimped with

this tool meets the crimp height requirement for hand tools in the appropriate application specification (114-series),

but might not comply with other feature parameters of the specification. TE Connectivity offers a variety of tools to

satisfy your performance requirements. For additional information, contact the Tooling Assistance Center (800-722-

1111).

PRO-CRIMPER™III

Hand Crimping Tool Assembly 58546-1

and Die Assemblies 58545-[ ]

408-8678

Rev F

2 of 11

1. INTRODUCTION

PRO-CRIMPER III Hand Crimping Tool Assembly 58546-1 for SOLISTRAND™terminals and splices is the tool

and die set shown in Figure 1. The tool consists of the PRO-CRIMPER III Hand Crimping Tool Frame 354940-1

(instruction sheet 408-9930) and the die assemblies listed in Table 1. This tool is used to crimp the terminals

listed in Table 1.

Table 1: Crimping specifications

Die assembly*

Product family (SOLISTRAND)†

Wire

Size AWG

Strip length mm [in.]

58545-1

58545-3

58545-4

Terminal (standard)

22-14

4.37-5.16 [.172-.203]

Terminal (standard) and butt splice

12-10

6.35-7.14 [.250-.281]

Terminal (long barrel) or butt splice

22-14

Terminal parallel splice

7.94-8.73 [.312-.344]

* For specific terminal and splice part numbers, contact the Tooling Assistance Center (800-722-1111) or

Product Information (at the number listed at the bottom of page 1).

†For die assembly cross reference, see Figure 12 on page 11.

NOTE

Specific part numbers for die set 58545-[ ] are used with other optional crimp tooling. Refer to Figure 12 for specific

relationships.

NOTE

Dimensions in this instruction sheet are in millimeters with [inches in brackets]. Figures are for reference only and are not

drawn to scale.

Read these instructions thoroughly before crimping connectors.

This document supersedes instruction sheet 408-4047.

Reasons for reissue of this instruction sheet are provided in Section 8, REVISION SUMMARY.

2. DESCRIPTION

The tool frame (Figure 1) features two jaws, a handle, a ratchet adjustment wheel, and an emergency ratchet

release. Each die set consists of a crimper (upper die) and an anvil (lower die). The tool frame holds a die

assembly with three crimping chambers. Die-retaining screws are used to secure the dies in the tool frame.

The tool features a ratchet and an adjustment wheel with a range of settings. The ratchet ensures that the tool

has completed the cycle and does not release until the handles have been fully closed, unless the emergency

ratchet release is pressed to manually release the ratchet. The adjustment wheel controls the amount of handle

pressure exerted on the dies during the crimping procedure.

CAUTION

The dies bottom before the ratchet releases. This feature ensures maximum tensile performance of the crimp.

408-8678

Rev F

3 of 11

3. INSTALLING THE DIE ASSEMBLY

1. Open the tool handles and remove the two die-retaining screws from the tool jaws (see Figure 1).

2. Place the upper die in the stationary jaw of the tool frame so that the largest indenter is facing inward.

3. Insert a die-retaining screw through the stationary jaw and through the die. Tighten the screw just

enough to hold the die in place. Do not tighten the screw completely.

4. Place the lower die in the moving jaw of the tool frame so that the largest anvil is facing inward.

5. Insert a die-retaining screw through the moving jaw and through the die. Tighten the screw just enough

to hold the die in place. Do not tighten the screw completely.

6. Carefully close the tool handles, making sure the anvil and crimper align properly. Continue closing the

tool handles until the ratchet in the tool frame engages sufficiently to hold the dies in place.

7. Tighten both die-retaining screws.

4. REMOVING THE DIE ASSEMBLY

1. Open the tool handles until the ratchet releases.

2. Remove the two die-retaining screws.

3. Slide the dies out of the tool jaws.

5. CRIMPING

NOTE

The tool is provided with a crimp adjustment feature. Refer to section 7, INSPECTING THE CRIMP HEIGHT, and section 8,

ADJUSTING THE RATCHET, to verify crimp height before using the tool.

NOTE

The crimping chamber marked 12-10 cannot be used to crimp spade-type terminals.

1. Refer to Table 1 and select wire of the specified size and insulation diameter.

2. Strip the wire to the length indicated. Do not nick or cut wire strands.

3. Select an applicable terminal or splice and identify the appropriate crimp section according to the wire

size markings on the dies.

4. Hold the tool so that the back (wire side) is facing you. (See Figure 2.) Squeeze the tool handles

together until the ratchet releases and allow them to open fully.

Figure 2: Front and back of tool

Front of tool

Back of tool (wire side)

408-8678

Rev F

4 of 11

5. Center the terminal or splice wire barrel on the anvil of the upper die as shown in Figure 3, Figure 4,

and Figure 5. If the brazed seam on the terminal or splice is visible, orient it toward the indenter.

Figure 3: Crimping a splice

Figure 4: Crimping a parallel splice

Wire barrel centered on anvil of lower die

Brazed seam oriented toward indenter

Figure 5: Crimping a terminal

Wire barrel centered on anvil of lower die

Stripped wire

408-8678

Rev F

5 of 11

6. While holding the wire barrel in place, squeeze the tool handles together until the ratchet engages

sufficiently to hold the terminal or splice in position. Do not deform the insulation barrel or wire barrel.

7. Insert the stripped wire into the wire barrel, making sure that the insulation does not enter the wire

barrel. See Figure 3.

8. While holding the wire in place, fully cycle the tool until the ratchet releases and allows the handle to

open.

9. To crimp the other half of a splice, reposition the uncrimped wire barrel in the crimping chamber and

repeat steps 1-8.

NOTE

If the splice cannot be turned for crimping the other half, turn the tool around.

10. Inspect the crimped terminal or splice as described in section 6.

11. Check the crimp height as described in section 7. If necessary, adjust the ratchet as described in

section 8.

CAUTION

Do not use damaged terminals or splices. If a damaged terminal or splice is evident, replace it with a new one.

408-8678

Rev F

6 of 11

6. INSPECTING THE CRIMP

Inspect crimped terminals and splices by checking the features shown in Figure 6. Poor crimps (Figure 7) can

be avoided by carefully following the procedures provided in section 5, and by following the tool maintenance

procedures provided in section 9.

Figure 6: Features of a good crimp

Terminal

Parallel splice

Butt splice (strap type)

Butt splice (sight hole or stranded type)

Wire insulation does not enter wire barrel

Crimp is centered. Crimp can be off center, but not off end of wire barrel.

Wire is visible through inspection hole. Wire is flush with or extends

slightly beyond end of wire barrel.

Wire size matches wire range or size stamped under tongue.

Bare wire ends are flush with or extend slightly beyond end of wire barrel.

Wire size matches wire range or size stamped on splice.

Figure 7: Features of a poor crimp

Terminal

Parallel splice

Butt splice (strap type)

Butt splice (sight hole or stranded type)

Crimped off end of wire barrel

Wire not inserted far enough. End of wire must be visible through inspection

hole, and be flush with (or extend slightly beyond) end of wire barrel.

Nicked or missing strands

Wire size does not match wire range or size stamped under tongue.

Wire insulation enters wire barrel. Check for incorrect strip length.

Excess “flash” on terminal or splice indicates damaged jaws or use of wrong

wire, splice, or tooling combination.

Wire size does not match wire range or size stamped on splice.

408-8678

Rev F

7 of 11

7. INSPECTING THE CRIMP HEIGHT

This inspection requires the use of plug gages conforming to the dimensions provided in Figure 8 and Table 2.

TE Connectivity does not manufacture or market these gages.

Figure 8: Recommended plug gage design

GO dimension

50.8 [2.00] minimum (typical)

NO-GO dimension

Radius (see Table 2)

12.7 [.50] minimum (typical)

Die closure configuration

Table 2: Gage element dimensions

Crimping chamber

(die marking)

GO element

NO-GO element

Radius

22-16

1.143-1.151 [.0450-.0453]

1.344-1.346 [.0529-.0530]

1.57 [.062]

16-14

1.346-1.354 [.0530-.0533]

1.547-1.549 [.0609-.0610]

1.98 [.078]

12-10

1.905-1.913 [.0750-.0753]

2.106-1.108 [.0829-.0830]

2.77 [.109]

To gage the crimping chamber, complete the following steps:

1. Remove traces of oil or dirt from the crimping chamber and plug gages.

2. Close the tool handles until the crimping dies have bottomed. Do not force dies beyond initial contact.

3. Align the GO element with the crimping chamber. Gently push the element straight into the crimping

chamber. The GO element must pass completely through the crimping chamber (Figure 9).

Figure 9: GO element

408-8678

Rev F

8 of 11

4. Align the NO GO element and try to insert it straight into the same crimping chamber. The NO GO

element can start entry, but it must not pass completely through the crimping chamber (Figure 10).

Figure 10: NO GO element

If the crimping chamber conforms to the gage inspection, the tool is considered dimensionally correct.

Lubricate it with a thin coat of any good SAE 20 motor oil.

If not, return the tool to TE for further evaluation and repair. Refer to section 10, REPLACEMENT AND

REPAIR.

For additional information regarding the use of a plug gage, refer to instruction sheet 408-7424.

408-8678

Rev F

9 of 11

8. ADJUSTING THE RATCHET

The ratchet is preset prior to shipment, but it is important to verify the crimp height using a micrometer or

caliper. Use and wear can cause the tool to go out of adjustment. Inspect the crimp height and adjust the

ratchet, if necessary, on a regular basis.

To adjust the ratchet, complete the following steps.

1. Remove the lock screw from the ratchet adjustment wheel (Figure 11).

2. With a screwdriver, adjust the ratchet wheel from the front side of the tool.

If the crimp height is larger than recommended, rotate the adjustment wheel counter-clockwise ()

to a higher setting.

If the crimp height is smaller than recommended, rotate the adjustment wheel clockwise (–) to a

lower setting.

3. Reinstall the lock screw.

4. Make a sample crimp and measure the crimp height.

5. Repeat as required.

If the crimp height cannot be made to conform to the recommended crimp height, replace the tool or die

set. See section 10, REPLACEMENT AND REPAIR.

Figure 11: Ratchet adjustment

Screwdriver

Ratchet adjustment wheel

Lock screw (typical)

408-8678

Rev F

10 of 11

9. MAINTENANCE AND INSPECTION

9.1. Maintenance

Remove dust, moisture, and other contaminants with a clean, soft brush or soft, lint-free cloth. Do not

use objects that could damage the dies or tool.

When the tool is not in use, keep the handles closed to prevent objects from becoming lodged in the

dies.

Remove all lubrication and accumulated film by immersing the dies in a suitable commercial degreaser.

Store the tool in a clean, dry area.

9.2. Visual inspection

Inspect the tool and dies on a regular basis to ensure that they are not worn or damaged.

Inspect the crimping chambers of the die assembly for flattened, chipped, worn, or broken areas.

If damage or abnormal wear is evident, replace the tool or dies. Refer to section 10, REPLACEMENT

AND REPAIR.

10. REPLACEMENT AND REPAIR

Customer-replaceable parts are shown in Figure 1.

The PRO-CRIMPER III Hand Crimping Tool Repair Kit 679221-1 (available separately) includes a replacement

nut and a variety of pins, rings, screws, and springs.

Order the repair kit and replaceable parts through your TE representative. You can also order parts by any of

the following methods:

Go to TE.com and click the Shop TE link at the top of the page.

Call 800-522-6752.

Write to:

CUSTOMER SERVICE (038-035)

TE CONNECTIVITY CORPORATION

PO BOX 3608

HARRISBURG PA 17105-3608

For customer repair services, call 800-522-6752.

11. REVISION SUMMARY

Revisions to this instruction sheet include:

Reformatted to current standard for instruction sheets

Altri manuali per PRO-CRIMPER III

Questo manuale è adatto per i seguenti modelli

Indice

Altri manuali TE Connectivity Utensili per crimpatura

TE Connectivity

TE Connectivity SDE-SA Manuale utente

TE Connectivity

TE Connectivity ERGOCRIMP 5-1579001-2 Manuale utente

TE Connectivity

TE Connectivity 2392637-1 Manuale utente

TE Connectivity

TE Connectivity PRO-CRIMPER III Manuale utente

TE Connectivity

TE Connectivity 2368740-1 Manuale utente

TE Connectivity

TE Connectivity ERGOCRIMP 539671-2 Manuale utente

TE Connectivity

TE Connectivity 2372541-1 Manuale utente

TE Connectivity

TE Connectivity 2063490-1 Manuale utente

TE Connectivity

TE Connectivity CERTI-CRIMP Manuale utente

TE Connectivity

TE Connectivity SOLISTRAND 69097 Manuale utente

TE Connectivity

TE Connectivity 58425 Series Manuale utente

TE Connectivity

TE Connectivity SDE-SA Manuale utente

TE Connectivity

TE Connectivity 90117 Manuale di istruzioni

TE Connectivity

TE Connectivity 90017-3 Manuale utente

TE Connectivity

TE Connectivity SDE-SA Manuale utente

TE Connectivity

TE Connectivity AT-65 Manuale utente

TE Connectivity

TE Connectivity Faston Series Manuale utente

TE Connectivity

TE Connectivity ERGOCRIMP 2-1579016-2 Manuale utente

TE Connectivity

TE Connectivity 2391789-1 Manuale utente

TE Connectivity

TE Connectivity 2063379-1 Manuale utente

TE Connectivity

TE Connectivity 2390882-1 Manuale utente

TE Connectivity

TE Connectivity PRO-CRIMPER III Manuale utente

TE Connectivity

TE Connectivity ERGOCRIMP 539 685-2 Manuale utente

TE Connectivity

TE Connectivity 90382- 2 Manuale utente

Manuali Utensili per crimpatura popolari di altre marche

Panduit

Panduit CT-1000 Guida per l'amministratore

JST

JST CS 10 Manuale utente

molex

molex 63811-5100 Manuale utente

Danfoss

Danfoss ET4200 Manuale utente

Tyco Electronics

Tyco Electronics PRO-CRIMPER III Manuale utente

molex

molex 63825-3000 Manuale utente

Tyco Electronics

Tyco Electronics 69156-1 Manuale utente

CRH

CRH CRL CBLHCT1 Manuale utente

Emerson

Emerson Klauke ES 105CFM Manuale utente

KIMBALL MIDWEST

KIMBALL MIDWEST 27-798 Manuale di istruzioni

Danfoss

Danfoss ET4350 Manuale utente

Milwaukee

Milwaukee M18 Manuale utente

HOGERT

HOGERT HT1P169 Manuale utente

Textron

Textron ESG105L Manuale utente

Tyco Electronics

Tyco Electronics 90035-3 Manuale utente

Emerson

Emerson Klauke ES 20RMCCFB Manuale utente

Continental Refrigerator

Continental Refrigerator PC150HD Manuale utente

Tyco Electronics

Tyco Electronics CERTI-CRIMP 90418-1 Manuale utente
