Teac LCD2639HD Manuale utente

LCD2639HDLCD2639HD

LCD Digital TVLCD Digital TV

SOUND MENU

PICTURE MENU

TIME MENU

LOCK MENU

CHANNEL MENU

EPG and Channel List MENU

INPUT SOURCE

Multimedia(USB) MENU

DVR MENU

OPTION MENU

Remote control instructions in TV mode

Remote control instructions in DTV/USB mode

Remote control setup

Remote control instructions in TELETEXT mode

Remote control instructions in DVD mode 13

INSTALLATION GUIDE

SAFETY

PRECAUTIONS

SAFETY

PRECAUTIONS

PREFACEPREFACE

FRONT BACK

CONNECTIONS

OF LCD

FRONT BACK

CONNECTIONS

OF LCD

REMOTE CONTROLREMOTE CONTROL

BASIC

INSTALL TION

BASIC

INSTALLATION

IN THE CARTONIN THE CARTON

77MENU

OPERATION

SPECIFICATIONSSPECIFICATIONS

88TROUBLESHOOTING

AND ADVICE

TROUBLESHOOTING

AND ADVICE 39

Power Cord Connection

YPbPr Connection

HDMI Connection

Antennas Connection

AV Connection

COAX Connection

VGA(PC) Connection

USB PORT FUNCTION

1 PREFACE. 1. PREFACE

2 SAFETY PRECAUTIONS. 2. SAFETY PRECAUTIONS

Power cord and cables must be properly routed and protected to prevent

people from stepping on them and causing the TV to fall.

Minimum distances

10cm

20cm

10cm 5cm

Put the TV on a stable surface.

Do not place any material on the TV.

Do not block or cover the ventilation openings on the TV.

Do not use the TV with fixtures other than those provided or

suggested by the manufacturer.

Thank you for Choosing this TEAC product. Before operating the TV, please read and follow all

instructions and heed all warning.

Please keep these instructions for future reference.

Please note the diagrams in this manual are for reference only, your unit may differ slightly.

Keep the TV away from heat sources.

Unplug the TV before cleaning it. Do not use solvent or liquid to clean

the TV.

Only clean the TV with a soft and dry cloth.

Unplug the TV during lightning storms or when unused for long periods

of time.

Keep the TV dry and away from humidity.

Do not subject the TV to dripping liquids or moist environments.

Do not place any vessels containing liquids on or near the TV such as

vases,cups, etc.

If the following problems occur,turn off the TV set and unplug the AC power

cord immediately:

- AC power cord is damaged.

- Poor fitting AC power outlet.

- TV set is damaged by being dropped, hit or having something thrown at it.

- Any liquid or solid object has fallen through the openings in the cabinet.

NEVER attempt to repair the unit yourself. Contact your dealer or the

TEAC Customer Care Centre (see back page for details) to have your

unit checked and repaired by approved service personnel.

3 . IN THE CARTON. IN THE CARTON

Remote ControlRemote ControlLCD TV SETLCD TV SET

2 x AAA Battery2 x AAA Battery

1.5V

Power CablePower Cable

Quick Start GuideQuick Start Guide

User ManualUser Manual Quick Start GuideQuick Start Guide

User ManualUser Manual

Please make sure the following items are included in your package.

If any items are missing, please contact your dealer.

4 FRONT, BACK, CONNECTIONS OF L D. C 4. FRONT, BACK, CONNECTIONS OF LCD

Front View

Back View and Control Connections

VOL + VOL - CH+ CH- MENU INPUT POWE R

1. Press“VOL+/VOL-”to increase or decrease the sound level.

2. Press“CH+/CH-”to scan through channels.

3. Press “MENU”to bring up the main menu on the screen.

4. Press“INPUT”to select the input source.

5. POWER on or off.

6. POWER INDICATOR: show red in standby mode, show green or blue when your TV is switched on.

7. REMOTE SENSOR: infrared sensor for the remote control.

Press“ ” button to turn the TV

1. AC IN: Main power input.

2. USB : Connect to the External drive.

3. HDMI1 HDMI2 HDMI3: Connect to the HDMI output jack

4. VGA(PC): Connect to the PC-RGB output jack of PC.

5. PC AUDIO : Connect the Audio output jack of PC.

6. YPbPr1/YPbPr2: Connect the YPbPr output jack of DVD

or VCR.

7. COAX: Connect the SPDIF receiver.

8. VIDEO Audio L R : Connect to the Video output jack

of DVD or VCR.

9. RF IN: Connect the antenna.

10. PHONE: Connect the headphone.

PORT

/ /

of DVD

/ ( / ) /Audio

VGA(PC)VGA(PC)

USBUSB HDMI1HDMI1 HDMI2HDMI2 HDMI3HDMI3

AUDIO

CO XA

PHONEPHONE

RF IN RF IN

458 9

Pb1Pb1 Pr1Pr1

Y1Y1

Pb2Pb2 Pr2Pr2

Y2Y2

LLRR

VIDEOVIDEO

AC INAC IN

167

75 OHM

ANTENNA

PLUG

POWER PLUG OF

ANTENNA

AMPLIFIER

OUTDOOR

ANTENNA

AMPLIFIER

VHF ANTENNA UHF ANTENNA

INDOOR

ANTENNA

AMPLIFIER

To ensure good picture and sound, TV antenna system needs to be installed. The antenna system as

Shown can be sourced from TV equipment shops, which will provide service for correct installation

and connection. After installation, insert the 75-ohm antenna plug into the antenna jack as shown.

5. BASIC A INSTALL TION

Power Cord Connection

Antennas Connection

- Connect the power cord correctly as shown.

- Press the POWER switch of your LCD TV to switch on the LCD TV. The power indicator

on the front panel lights up in red.

RF IN

Off
