Tecno SPARK 5 Pro Manuale utente
User Manual
Mobile Phone
Model：KD7
Hereby, TECNO MOBILE LIMITED
declares that this Mobile Phone is in compliance
with the essential requirements and other
relevant provisions of Directive 2014/53/EU.
Know your phone
01
1. Front camera
2. Volume key
3. Power key
1. Power off mobile.
2. Refer to the following picture for
SIM / SD card installation.
SIM/SD card installation
02
Charging the phone
03
You can charge your device using a
charger or by connecting it to the
computer using a USB cable (comes
with the phone).
1. Please remind the front and back of
the plug.
2. Use only TECNO charger and cables.
Other chargers or cables may damage
the device. This will invalidate your
phone warranty.
04
This device may be restricted for use,
depending on the local network.
Restrictions in the 5GHz band:
According to 10(10) of Directive
2014/53/EU, the packaging shows that
this radio equipment will be subject to
some restrictions when placed on the
market in Belgium(BE),Bulgaria(BG),the
Czech Republic(CZ) ,Denmark
(DK),Germany(DE),Estonia(EE),Ireland
(IE),Greece(EL),Spain(ES),France
(FR),Croatia(HR),Italy(IT),Cyprus
(CY),Latvia(LV),Lithuania
(LT),Luxembourg(LU),Hungary
(HU),Malta(MT),Netherlands(NL),Austria
(AT),Poland(PL),Portugal(PT), Romania
(RO),Slovenia(SK),Finland(FI),Sweden
(SE),the United Kingdom(UK),Turkey
(TR),Norway(NO),Switzerland
(CH),Iceland(IS),and Leichtenstein(LI).
The WLAN function for this device is
restricted to indoor use due to its
operation in the 5.15 to 5.35 GHz
frequency range.
Operating Frequency Band (RF)：
E-GSM900: 880-915MHz (TX),
925-960MHz (RX)
DCS1800: 1710-1785MHz (TX),
1805-1880MHz (RX)
WCDMA BAND I:1920-1980MHz (TX),
2110-2170MHz (RX)
WCDMA BAND VIII: 880-915MHz (TX),
925-960MHz (RX)
LTE BAND 1:1920-1980MHz (TX),
2110-2170MHz (RX)
LTE BAND 3:1710-1785MHz (TX),
1805-1880MHz (RX)
LTE BAND 7:2500-2570MHz (TX),
2620-2690MHz (RX)
LTE BAND 8:880-915MHz (TX),
925-960MHz (RX)
LTE BAND 20:832-862MHz (TX),
791-821MHz (RX)
05
LTE BAND 38:2570-2620MHz (TX),
2570-2620MHz (RX)
LTE BAND 40:2300-2400MHz (TX),
2300-2400MHz (RX)
BT: 2402-2480MHz (TX/RX)
Wi-Fi (2.4G): 2412~2472MHz (TX/RX)
Wi-Fi (5G): Band 1: 5150-5250MHz
(TX/RX)
Band 2: 5250-5350MHz (TX/RX)
Band 3: 5470-5725MHz (TX/RX)
GPS:1.57542GHz
FM:87.5-108MHz
Modulation mode：
GMSK, 8PSK (GSM)
BPSK, QPSK ,16QAM(WCDMA)
QPSK, 16-QAM, 64-QAM (LTE)
GFSK, π/4-DQPSK, 8DPSK (BT)
GFSK (BLE)
DSSS (DBPSK, DQPSK, CCK) for IEEE
802.11b
OFDM(BPSK,QPSK,16QAM,64QAM) for
06
07
IEEE 802.11g/n HT-20/HT-40
IEEE 802.11a/n:OFDM (BPSK / QPSK /
16QAM / 64QAM) (WiFi)
BPSK (GPS)
FM
RF output power：
GSM900: 33dBm±2dB
DCS1800: 30dBm±2dB
WCDMA BAND I/VIII:
24dBm+1.7dB/-3.7dB
LTE BAND 1/3/7/8/20/38/40:
23dBm+2.7dB/-2.7dB
Bluetooth: 0-10dBm
WiFi: 14dBm+/-3dB
08
Specific Absorption Rate (SAR)
Certification
THIS DEVICE MEETS INTERNATIONAL
GUIDELINES FOR EXPOSURE TO RADIO WAVES
Body parts
Test value
Test distance
Limit
Head
0.471W/Kg 10g
0cm
2.0 W/Kg 10g
Body
0.586 W/Kg 10g
0.5cm
2.0 W/Kg 10g
