USER’S MANUAL
Refrigerator Model
TBF134WMDB
To ensure proper use of the appliance and your safety, please read the
following user manual completely before operating this appliance.
Engineered To Perform
Thank you for purchasing our product and thank you for placing your
confidence in us.
Read this manual carefully before using. Follow instructions and
keep it for future reference.
Follow the operating instructions and safety notices in this manual.
If any trouble arise, do not fix it yourself or hand it to the after sales
service centre which have not been authorised. Please contact the
local authorised service centre.
This refrigerator is designed and approved for use with flammable
R600A hydrocarbon refrigerant.
R600A refrigerant is better for the environment.
R600A is an eco-friendly hydrocarbon refrigerant.
The appliance is specifically constructed for domestic
use and is therefore suitable for the refrigeration and storage
of fresh and frozen foods and the production of ice-cubes.
The appliance has not been designed or manufactured for
professional use. Teco declines all responsibility for damage
deriving from improper use of the appliance. The refrigerator
has undergone the necessary tests on the tightness of the
refrigeration circuit and complies with the safety regulations
for electrical appliances.
All images contained within this manual are for illustration purposes
only.
WARNING ICON
This symbol indicates information concerning your personal
safety
CAUTION ICON
This symbol indicates information on how to avoid damaging
the appliance
FLAMMABLE ICON
R600A WARNING LABEL
CAUTION
R600a
WARNING
TABLE OF CONTENTS
Safety precautions................................................
Name of parts and usage.....................................
Installation instructions.........................................
Transporting the appliance ..................................
Operating instructions .........................................
Defrosting ............................................................
Maintenance ......................................... ..............
Disconnection of the appliance ............................
Reversing the door ..............................................
Troubleshooting .................................................
Repairs, service & warranty ................................
Specifications ......................................................
1 - 2
3
4
5
6
7
8
9
10 - 11
12 - 13
13
14
R600A Iso-butane Refrigerant
Hydrocarbon refrigerants have excellent refrigerant
properties and minimal low global warming potential and
no ozone depletion potential.
This appliance contains a small quantity of flammable, non-
synthetic R600A refrigerant:
Hydrocarbon refrigerants cannot be ‘retrofitted’ to the appliance
that has not been designed and approved to use that type of
refrigerant.
Ensure that the tubing of the refrigerant circuit is not damaged
during transportation and installation.
Leaking refrigerant may cause eye injuries or could ignite.
The room for installing the appliance must be at least 1m3per 8g
of refrigerant. The amount of refrigerant in the appliance can be
found on the rating plate attached to the appliance.
Risk of fire
If the refrigerant circuit should become damaged. Avoid
open flames and sources of ignition. Disconnect the appliance
from the mains power. Thoroughly ventilate the room in which
the appliance is situated for several minutes.
SAFETY PRECAUTIONS
Instructions
The refrigeration system behind and inside the refrigerator
contains refrigerant. Do not alow any sharp objects to come in
contact with the refrigerant system.
Keep ventilation openings, in the appliance enclosure or
in the built in structure, clear of obstruction.
Do not use mechanical devices or other means to accelerate
the defrosting process, other than those recommended by the
manufacturer.
Do not damage the refrigerant circuit, do not use electrical items or fire
equipment nearby, and open all windows to provide good ventilation.
Do not use electrical appliances inside the food storage compartments
of the appliance unless they are the type recomended by the
manufacturer.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
WARNING
WARNING
WARNING
1
Young children should be supervised to ensure that they do not
play with the appliance.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
When disposing of the appliance, do so only at an
authorised waste disposal centre.
Don’t store inflammable materials such as ether,
benzene, LP gas and glue etc in the refrigerator.
Please remove all the doors before you dispose your refrigerator
and leave the shelves in place to prevent access by children.
Do not expose to flame.
Please keep the appliance away from substances which could
cause ignition.
Before obtaining access to electrical terminals, all electrical supply
circuits must be disconnected.
The fridge is designed to operate on a single phase
power supply within a voltage range of 220~240V/50Hz.
Don’t splash water on the rear of the appliance,
for it may cause malfunction or electric shock.
Containers with flammable gases or liquids can leak at
low temperature. There is a risk of explosion.
Do not store any container with flammable materials such
as spray cans in the refrigerator.
Do not operate any electrical appliance in the refrigerator (e.g.
electric ice cream makers, mixers etc.).
Before cleaning the appliance, always switch off the appliance
and unplug it, or pull the house fuse or switch off the circuit
breaker.
Safety of children
Packaging (e.g. wraps, polystyrene) can be dangerous for
children. There is a risk of suffocation. Keep packaging materials
away from children. Remember to dispose of old appliances in
accordance with local laws. Pull out the mains plug, cut off the
mains cable, break or remove spring or bolt catches if fixed and ensure
that children cannot lock themselves in the appliance when playing (there
is risk of suffocation) or involve themselves in other dangers, for children
cannot recognize the hazard present in household appliances themselves.
Therefore, it is very important for parents to make adequate supervision
and never let children play with the appliance.
WARNING
2
NAME OF PARTS AND USAGE
1. Ice box compartment 7. Adjustable leg(s)
2. Defrost drip tray 8. Door storage
3. Lamp switch 9. Storage bar
4. Temperature control dial 10. Internal can dispenser *
5. Removable shelf 11. Can dispenser frame
6. Vegitable crisper 12. Ice cube tray
* Can dispenser intended for can size no larger than ǿ66mm x 130mm length.
The refrigerator you purchased is subject to continuous improvement,
which may not be completely consistent with the manual, however the
functions and operating methods will not change.
If you use the refrigerator for the first time, remove the adhesive tapes
from the drawers, shelves, trays, ice box door and defrost tray.
Do not pull or push the drawers and shelves forcefully during use in
case of damage.
3
1
2
3
4
5
5
6
77
89
8
9
10
8
11
9
9
12
PACKING LIST
Note: Product specifications are subject to change without prior notice
4
Model TBF134WMDB
Ice cube tray
User manual
Warranty
Information
1 piece
1 copy
1 copy
Part No.
(see pg.3)
12
TRANSPORTING THE APPLIANCE
1.The appliance must be transported only in a vertical position. The
packing must be intact during the transportation.
2. When unpacking and re-packing the appliance, please memorise the
position of each accessory of the appliance when unpacking it. When
re-packing the appliance for transportation, ensure all accessories are
secured before transportation.
3. Do not lift or pull the door during transportation
4. When moving the appliance, do not tilt >45 degrees
(the angle of the vertical direction). Please avoid strong
vibration and impacts that could cause damage to the
appliance.
5. The refrigerator should be located on a firm and flat surface. An uneven
surface may cause excess operating noise or vibration.
(a) The noise may be increased if the floor is not firm.
(b) If the appliance is to be positioned on carpet flooring and heat
emitted from the appliance is a concern, place a solid sheet
under the appliance.
6. Choose a location which is not exposed to sunlight, high temperature or
humid, as humidity may cause staining.
7. It is recommended a clearance of at least 100mm away
from objects and walls on both sides and back. Ensure the
clearance above the appliance is not less than 200mm and
160° clear for the door to swing open.
8. If the appliance is unstable, rotating either of the front two legs in a
clockwise direction will raise the appliance.
9. When adjusting the front legs, ensure the
appliance slopes backwards slightly for keeping the
door closed.
10. Remove all internal packaging before operating
200mm
50mm
50mm
5
OPERATING INSTRUCTIONS
PLACEMENT OF FOOD
1. There should always be some space between
items inside for air circulation.
2. Food should be kept in sealed packaging to
avoid becoming dry or spoilt.
3. Hot food should be cooled down before placing
into the appliance. Otherwise, the interior
temperature and power consumption will increase.
4. Reduce opening the door frequently.
This will increase the appliance efficiency and reduce
power consumption.
Do not use any electronic equipment inside the appliance.
The temperature of refrigerator can be controlled manually by adjusting
the thermostat dial. However, the number shown on the dial
does not directly represent the temperature. Instead, the
larger the number is, the lower the interior temperature will
be. 0 stands for off (refrigeration system only). Turn the dial
to position 4 for normal use, turn it to position 4-6 if a lower
interior temperature is required; alternatively, to increase the
interior temperature select position 4-1.
Do not store objects which are costly or subject to temperature
variations. e.g. medication or chemicals.
ICE MAKING
The ice box compartment is not a deep freezer
and is designed for making ice cubes. It is not
recommended for storage of frozen food.
To make ice cubes, fill the ice tray with potable
water and place it in the ice box. To remove ice
cubes easily, run water on the tray before gently
twisting and inverting the tray.
WARNING
6
WARNING
DEFROSTING
Heavy frost will effect the refrigerating process or internal temperature of
the appliance and increase the power consumption. Thus, defrosting is
required if the frost is >5mm thick. Defrosting is a manual process. Please
follow these steps:
1. Switch off and disconnect the appliance.
2. Remove all food from the ice box and refrigerator compartments.
3. Remove the shelving and crisper.
4. Ensure the defrost drip tray is correctly located under the ice box.
5. Open the door and wait for the ice to defrost.
6. When de-icing, a scraper or plastic utensil may be used. Never use
metal instruments or electrical appliances to de-ice the ice box.
7. To speed up the defrosting process, you can place a bowl of hot water
in the compartment and close the door.
8. When defrosting is complete, clean the appliance and wipe dry.
9. Replace shelving, crisper and food before restoring power.
Do not use an electric heater or hair dryer to increase the
defrost process. It may destroy the cooling system.
ENERGY SAVING TIPS
1. Adjust the temperature control to a setting that is acceptable for the
storage of the food. This will reduce the power consumption.
2. Only open the door when required. Frequently opening the door will
increase power consumption.
3. To maintain good air circulation, keep the shelves and crisper of the
refrigerator as supplied.
CAUTION
7
Indice
Altri manuali TECO Frigorifero
TECO
TECO THCF200WMGM Manuale utente
TECO
TECO TFF270WNTBM Manuale utente
TECO
TECO TSXS580WNA Manuale utente
TECO
TECO TSXS582SNCM Manuale utente
TECO
TECO TFF210WNTAM Manuale utente
TECO
TECO TBF86WMTAG Manuale utente
TECO
TECO TFF278WNTAG Manuale utente
TECO
TECO THCF145WMGM Manuale utente
TECO
TECO TFF411WNBRM Manuale utente
TECO
TECO TAF230WMPCM Manuale utente
TECO
TECO TBF117WMDE Manuale utente
TECO
TECO TBF84WMTA Manuale utente
TECO
TECO TAF237WMPA Manuale utente
TECO
TECO TFF203WNTDM Manuale utente
TECO
TECO TFF210WNTBM Manuale utente
TECO
TECO TFF536WNMATEBF Manuale utente
TECO
TECO TFF470WNTA Manuale utente
TECO
TECO TBF75WMDA Manuale utente
TECO
TECO TFF400WNTCM Manuale utente
TECO
TECO THF268WNTAM Manuale utente
