OPERATION MANUAL

MODEL T802

PARAMAGNETIC OXYGEN ANALYZER

9480 CARROLL PARK DRIVE

SAN DIEGO, CA 92121-5201

USA

Toll-free Phone: 800-324-5190

Phone: 858-657-9800

Fax: 858-657-9816

Email: [email protected]

Website: http://www.teledyne-api.com/

Teledyne Advanced Pollution Instrumentation 14 January 2013

ABOUT TELEDYNE ADVANCED POLLUTION INSTRUMENTATION (TAPI)

Teledyne Advanced Pollution Instrumentation, Inc. (TAPI) is a worldwide

market leader in the design and manufacture of precision analytical

instrumentation used for air quality monitoring, continuous emissions monitoring,

and specialty process monitoring applications. Founded in San Diego, California,

in 1988, TAPI introduced a complete line of Air Quality Monitoring (AQM)

instrumentation, which comply with the United States Environmental Protection

Administration (EPA) and international requirements for the measurement of

criteria pollutants, including CO, SO2, NOXand Ozone.

Since 1988 TAPI has combined state-of-the-art technology, proven measuring

principles, stringent quality assurance systems and world class after-sales support

to deliver the best products and customer satisfaction in the business.

For further information on our company, our complete range of products, and the

applications that they serve, please visit www.teledyne-api.com or contact api-

[email protected].

NOTICE OF COPYRIGHT

TRADEMARKS

All trademarks, registered trademarks, brand names or product names appearing

in this document are the property of their respective owners and are used herein

for identification purposes only.

07275B DCN6418

Teledyne API T802 Paramagnetic O2 Analyzer Operation Manual

This page intentionally left blank.

07275B DCN6418

iii

SAFETY MESSAGES

Important safety messages are provided throughout this manual for the purpose

of avoiding personal injury or instrument damage. Please read these messages

carefully. Each safety message is associated with a safety alert symbol, and are

placed throughout this manual; the safety symbols are also located inside the

instrument. It is imperative that you pay close attention to these messages, the

descriptions of which are as follows:

WARNING: Electrical Shock Hazard

HAZARD: Strong oxidizer

GENERAL WARNING/CAUTION: Read the accompanying message for

specific information.

CAUTION: Hot Surface Warning

Do Not Touch: Touching some parts of the instrument without

protection or proper tools could result in damage to the part(s) and/or the

instrument.

Technician Symbol: All operations marked with this symbol are to be

performed by qualified maintenance personnel only.

Electrical Ground: This symbol inside the instrument marks the central

safety grounding point for the instrument.

CAUTION

This instrument should only be used for the purpose and in the manner

described in this manual. If you use this instrument in a manner other than

that for which it was intended, unpredictable behavior could ensue with

possible hazardous consequences.

NEVER use any gas analyzer to sample combustible gas(es)!

Note For Technical Assistance regarding use and maintenance of this or any other

Teledyne API product, contact Teledyne API’s Technical Support Department:

Telephone: 800-324-5190 Email: [email protected]

or access the service options on our website at http://www.teledyne-api.com/

07275B DCN6418

Teledyne API T802 Paramagnetic O2Analyzer Operation Manual

CONSIGNES DE SÉCURITÉ

Des consignes de sécurité importantes sont fournies tout au long du présent

manuel dans le but d’éviter des blessures corporelles ou d’endommager les

instruments. Veuillez lire attentivement ces consignes. Chaque consigne de

sécurité est représentée par un pictogramme d’alerte de sécurité; ces

pictogrammes se retrouvent dans ce manuel et à l’intérieur des instruments. Les

symboles correspondent aux consignes suivantes :

AVERTISSEMENT : Risque de choc électrique

DANGER : Oxydant puissant

AVERTISSEMENT GÉNÉRAL / MISE EN GARDE : Lire la consigne

complémentaire pour des renseignements spécifiques

MISE EN GARDE : Surface chaude

Ne pas toucher : Toucher à certaines parties de l’instrument sans protection ou

sans les outils appropriés pourrait entraîner des dommages aux pièces ou à

l’instrument.

Pictogramme « technicien » : Toutes les opérations portant ce symbole doivent

être effectuées uniquement par du personnel de maintenance qualifié.

Mise à la terre : Ce symbole à l’intérieur de l’instrument détermine le point central

de la mise à la terre sécuritaire de l’instrument.

MISE EN GARDE

Cet instrument doit être utilisé aux fins décrites et de la manière décrite dans ce

manuel. Si vous utilisez cet instrument d’une autre manière que celle pour

laquelle il a été prévu, l’instrument pourrait se comporter de façon imprévisible

et entraîner des conséquences dangereuses.

NE JAMAIS utiliser un analyseur de gaz pour échantillonner des gaz

combustibles!

07275B DCN6418

WARRANTY

WARRANTY POLICY (02024F)

Teledyne Advanced Pollution Instrumentation (TAPI), a business unit of Teledyne

Instruments, Inc., provides that:

Prior to shipment, TAPI equipment is thoroughly inspected and tested. Should

equipment failure occur, TAPI assures its customers that prompt service and support

will be available.

COVERAGE

After the warranty period and throughout the equipment lifetime, TAPI stands ready

to provide on-site or in-plant service at reasonable rates similar to those of other

manufacturers in the industry. All maintenance and the first level of field

troubleshooting are to be performed by the customer.

NON-TAPI MANUFACTURED EQUIPMENT

Equipment provided but not manufactured by TAPI is warranted and will be repaired

to the extent and according to the current terms and conditions of the respective

equipment manufacturer’s warranty.

PRODUCT RETURN

All units or components returned to Teledyne API should be properly packed for

handling and returned freight prepaid to the nearest designated Service Center.

After the repair, the equipment will be returned, freight prepaid.

The complete Terms and Conditions of Sale can be reviewed at

http://www.teledyne-api.com/terms_and_conditions.asp

CAUTION – Avoid Warranty Invalidation

Failure to comply with proper anti-Electro-Static Discharge (ESD) handling and packing instructions

and Return Merchandise Authorization (RMA) procedures when returning parts for repair or calibration

may void your warranty. For anti-ESD handling and packing instructions please refer to “Packing

Components for Return to Teledyne API’s Technical Support” in the Primer on Electro-Static

Discharge section of this manual, and for RMA procedures please refer to our Website at

http://www.teledyne-api.com under Customer Support > Return Authorization.

07275B DCN6418

Teledyne API T802 Paramagnetic O2Analyzer Operation Manual

This page intentionally left blank.

07275B DCN6418

vii

ABOUT THIS MANUAL

This operation manual, PN 07275, is comprised of multiple documents in

PDF format, as listed below.

Part No. Rev Name/Description

07275 B T802 Operation manual

06530 C Menu Trees and Software Documentation (inserted as Appendix A in this manual)

07269 A Spare Parts List (located in Appendix B of this manual)

06535 A Expendables Kit (located in Appendix B of this manual)

06532 C Repair Request Form (inserted as Appendix C in this manual)

Appendix D Documents:

0738001 A Interconnect List

07380 A Interconnect Diagram

05803 B SCH, PCA 05802, MOTHERBOARD, GEN-5

06698 D SCH, PCA 06697, INTRFC, LCD TCH SCRN

06882 B SCH, LVDS TRANSMITTER BOARD

06731 A SCH, AUXILLIARY-I/O BOARD

Note We recommend that this manual be read in its entirety before any attempt is

made to operate the instrument.

ORGANIZATION

This manual is divided among three main parts and a collection of appendices at

the end:

Part I contains introductory information that includes an overview of the

analyzer, specifications, descriptions of the available options, installation and

connection instructions, and the initial calibration and functional checks.

Part II comprises the operating instructions, which include setup and calibration,

as well as remote operation, and ends with the specifics of calibrating for use in

monitoring within EPA protocol.

Part III provides detailed technical information starting with maintenance,

troubleshooting and service, frequently asked questions, principles of operation, a

primer on electrostatic discharge, and a glossary.

The appendices at the end of the manual provide support information such as

version-specific software documentation, lists of spare parts* and recommended

stocking levels, and schematics.

*Part numbers do not reflect real-time updates – contact Sales or Technical

Support).

07275B DCN6418

Teledyne API T802 Paramagnetic O2Analyzer Operation Manual

viii

CONVENTIONS USED

In addition to the safety symbols as presented in the Important Safety Information

page, this manual provides special notices related to the safety and effective use

of the analyzer and other pertinent information.

Special Notices appear as follows:

ATTENTION COULD DAMAGE INSTRUMENT AND VOID WARRANTY

This special notice provides information to avoid damage to your

instrument and possibly invalidate the warranty.

IMPORTANT IMPACT ON READINGS OR DATA

Could either affect accuracy of instrument readings or cause loss of

data.

Note Pertinent information associated with the proper care, operation or

maintenance of the analyzer or its parts.

REVISION HISTORY

T802 Operation and Maintenance Manual, PN07275

Date Rev DCN Description

2013 January 14 B 6418 Administrative Updates and specs updates

2011 February 18 A 6005 Initial Release

07275B DCN6418
