QUICK GUIDE FOR INSTALLERS

Dear Customer!

Thank you for choosing our product. For more information,

please visit the product website at:

https://tell.hu/en/products/gsm-automation/gsm-gate-control-20

MAIN FUNCTIONS:

Remote control of automated gates, garage doors, barriers or other

controllable electric devices, with free phone call.

Control of 2 different gates by presenting or hiding the caller ID.

Supports up to 20 users (phone numbers).

2 NO/NC inputs.

2 NO relay outputs.

Reports the status of the 2 contact inputs by SMS (can be used to forward

fault reports of the gate’s control board, or other output status).

SMS sending limitation option.

Forwards incoming SMS messages.

Programming and status query by SMS.

GENERAL OPERATION OF THE GATE CONTROL 20:

The device has 2 controllable relay outputs. One can be controlled by calls with

presented caller ID, using caller identification, and the other can be controlled by

calls with hidden caller ID (private number).

You can register up to 20 user phone numbers, which can control output NO1 by

call for free, using caller identification.For this, it is necessaryto enable the caller

identification service on the SIM card installed in the device, and control calls

should be made with presented caller ID. When the device receives a control call

with presented caller ID, it identifies the caller’s phone number, rejects the call,

and if the number is registered, it activates output NO1.

Controlling from private numbers (with hidden caller ID) can be used by an

unlimited number of users (registered users too), since this does not require

a phone number registration. When the device receives a control call with hidden

caller ID, it rejects the call, and activates output NO2. You can hide the caller ID

in a call by using the #31# code in front of the device’s phone number

(e.g. #31#+36301234567).

Attention! Anyone can control output NO2 with hidden caller ID (not only

the registered users)! This option should only be used for low-risk

applications, since an incoming call (with hidden caller ID) made to the

wrong number may also activate the output! You can increase safety on

this if you do not publish the device’s phone number.

If you want to control both outputs from the same phone, you can add the

device’s phone number to your phonebook in both formats (e.g. +36301234567

and #31#+36301234567), and call one or the other, depending on which output

you want to control. For instance, you can control a garage door (with caller ID

presentation) and a low-risk entrance gate (with hidden caller ID).

The device will reject all calls received from non-registered (unauthorized) phone

numbers (with presented caller ID), and will not activate any output.

Gate Control 20 Quick guide

PUTTING INTO OPERATION:

1. Choose the SIM card services according to the device functions you would

like to use (voice call, SMS service).

2. Enable the caller identification service on the SIM card at the mobile service

provider.

3. Disable the PIN code request, voice mail and notification about missed calls

on the SIM card.

4. Remove the SIM card bay cover of the device and install the SIM card.

The SIM cover can be removed by pressing it horizontally on the marked side

towards the status LED, and then pulling it out.

5. Check the installation environment for avoiding weak signal and other

problems (strong electromagnetic disturbances, high humidity).

6. Connect the antenna.

7. Do the wiring as shown in the wiring diagram.

8. Connect the device to the power supply (12-30V AC/DC, min. 400mA).

9. The device can be configured using SMS commands, as specified later inthis

guide.

Under Voltage Lock Out (UVLO) function

The product is provided with built-in automatic power cut (Under Voltage

Lock Out) function. The device will turn off automatically when the

supply voltage drops under a critical level, and turns back on when the

voltage restores to operational level.

DEVICE WIRING:

Attention! Do NOT connect the connector of the antenna directly or

indirectly to the protective ground, because this may damage the device!

V+ Supply voltage 12-30V AC/DC (min. 400mA)

V- Supply voltage negative (GND)

IN1 Input 1 (NO or NC)

IN2 Input 2 (NO or NC)

NO1 Relay output 1 (normally open)

NO2 Relay output 2 (normally open)

STATUS LED SIGNALS:

Flashing green

Normal operation,

connected to the mobile network

Permanent green

Processing SMS command, changing the

settings

Alternate red and green flash

SMS command error

Flashing red

Modem start/restart in progress

Permanent red

Mobile network search or SIM card error

Gate Control 20 Quick guide

Inputs:

You can use the two contact inputs (IN1 and IN2) to forward e.g. fault reports of

the gate’s control board (ifit has error outputs), or for any other application. When

the inputs are activated, the device sends the ALARM1! respectively ALARM2!

message by SMS to the phone number which you can configure with the

REPORT command. The factory default messages cannot be changed.

The default setting for the type of the inputs is normally open (N.O.).

The default sensitivity of the inputs is 1 second, i.e. you have to close the input

for at least 1 second in order to send an SMS message.

You can change the input type and sensitivity in the settings if needed.

The input restore sensitivity cannot be changed (the default value is 1 second).

This means that the input will react to a newer activation with a 1 second delay

after it restores to the default state.

Outputs:

The two outputs provide normally open (NO) dry contacts as the default state,

and closed contacts when controlled. They can take a load of 5A@24V AC/DC.

The outputs support 2 operating modes: timed and bistable. The default setting

is “timed” / 1 second.

If the output is set as “timed”, it becomes closed for the configured period of time

when controlled. In case that the maximum activation time (1000 seconds) is not

sufficient for the given application, it is possible to activate the output by a first

call, and deactivate by a second call. This is called bistable operating mode.

If the output is set as “bistable”, it changes its state upon each control call.

CONFIGURING THE DEVICE:

You can configure the device using commands sent by SMS to the phone

number of the SIM card installed in the device. It is possible to send multiple

commands (settings) in the same SMS, but the message must not exceed

140 characters! Each message must begin with the device password, using the

PWD=password#command, and must end with the hash #character. Otherwise,

the device will reject the requests.

SMS COMMANDS

PWD=1111#

Providing the password –necessary at the beginning

of each message! (Default password: 1111)

PWC=new password#

Changing the password. The password must consist of

4 alphanumeric non-accented characters (A…z, 0...9)

TEL=phone number#

Adding a new user (phone number)

DEL=phone number#

Deleting a user (phone number)

REL1=X#

Output NO1 activation time: substitute parameter X

with the time interval –value between 1…1000 (sec)

or with parameter FIX for bistable mode (default: 1s)

REL2=X#

Output NO2 activation time: substitute parameter X

with the time interval –value between 1…1000 (sec)

or with parameter FIX for bistable mode (default: 1s)

INTYPE1=X#

Type of input IN1: substitute Xwith: NO=normally open

or NC=normally closed (default: NO)

INTYPE2=X#

Type of input IN2: substitute Xwith: NO=normally open

or NC=normally closed (default: NO)

IN1=X#

Sensitivity of input IN1: substitute parameter Xwith the

needed sensitivity –value between 1…1000 (seconds)

(default: 1s)

IN2=X#

Sensitivity of input IN2: substitute parameter Xwith the

needed sensitivity –value between 1…1000 (seconds)

(default: 1s)

REPORT=phone

number#

Adding a phone number where the device will send

and forward SMS messages

REPORT=#

Deleting the SMS sending/forwarding phone number

SMSLIMIT=X#

SMS limitation per input: substitute Xwith the desired

setting: value between 1…50 (pcs). To disable the

limitation, substitute Xwith 0. (default: 1)

TEL?#

Requesting registered phone numbers

STATUS?#

Requesting module status

Gate Control 20 Quick guide

Example:

Adding 2 user phone numbers, changing the activation time of output NO1 to

3 seconds, and setting output NO2 to bistable operating mode:

PWD=1111#TEL=+36301111111#TEL=+36202222222#REL1=3#REL2=FIX#

Response of the device to SMS commands

After receiving commands, the device will send response messages as follows:

Device response

Meaning

Wrong password

The provided password is invalid

Password changed

The password has been changed successfully

3 user(s) added

3 phone numbers added successfully

User removed

Phone number deleted successfully

User not found to delete

The phone number you want to delete was not found

Rel1 mode set OK

Output NO1 operating mode changed

Invalid Rel1 time

The activation time specified for output NO1 is

invalid

Rel1 time OK

Output NO1 activation time has been set

successfully

Input type OK

Input type changed successfully

Intype error

Input type error, invalid parameter

Input sens. OK

Input sensitivity changed successfully

Invalid input sens.

Input sensitivity error, invalid value

Report nr. OK

The phone number for SMS sending/forwarding

changed successfully

SMS limit OK

SMS limitation value changed successfully

SMS limit=50!

Invalid SMS limitation value, therefore set to 50

No SMS limit

SMS limitation disabled

CMD error

Command typing error

Empty phonebook

No users/phone numbers found

SMS forwarding:

The device can forward incoming SMS messages to the phone number

configured with the REPORT command. After forwarding, it deletes the message

from the SIM card. If no phone number is set, the device will delete all incoming

messages without forwarding. A forwarded message looks as follows:

SMS forward from the sender’s phone number: forwarded message.

SMS sending limitation:

With this option, you can limit the number of SMS messages generated by the

inputs. When the configured limit is reached, the device will not send further SMS

messages generated by inputs until it receives a control call. By default, the

device allows sending only 1 SMS message per input between two control calls.

The next call will reset the message counter. You can change the limit or disable

the limitation function using the SMSLIMIT command.

Status query:

It is possible to request status report from the device in SMS. For a status query,

send the PWD=password#STATUS?# command in SMS to the phone number

of the device. The device will send an answer containing the actual status.

Example:

SIGNAL (0-10)=9 Mobile signal level on a 0 to 10 scale

INTYPE1=NO; Type of input IN1 (NO or NC)

IN1=3;STATUS=IDLE Sensitivity and status of input IN1 (5s, ALARM/IDLE)

INTYPE2=NC; Type of input IN2 (NO or NC)

IN2=5;STATUS=ALARM Sensitivity and status of input IN2 (5s, ALARM/IDLE)

REL1=3;STATUS=OFF Activation interval and status of output 1 (ON/OFF)

REL2=FIX;STATUS=ON Activation interval and status of output 2 (ON/OFF)

SMSLIM=1 Actual SMS limitation setting

Restoring the factory default settings (factory reset):

This process will restore the factory default settings, will reset the device

password, and will erase all users. For this, follow the steps below:

1. Powered down the device and leave the SIM card installed.

2. Close input IN1 (we suggest to use a toggle switch for this).

3. Power up the device (LED signals: permanent green and flashing red)

4. After 5 seconds LED lights are inverted (permanent red and flashing green)

5. Open input IN1.

6. After 5 seconds green and red flash together.

7. Close input IN1 again and wait until the device connects to the mobile

network (this will be indicated by a continuous green LED flashing).

Gate Control 20 Quick guide

SAFETY INSTRUCTIONS

For your safety, please read carefully and follow the instructions below!

Failure to observe safety instructions may be a threat to you and your

environment!

TELL’s product (hereinafter referred to as „device”) has a built-in mobile

communication modem. The built-in modem is capable of 2G mobile

communication.

The 2G modem can use the following frequency bands:

850/900/1800/1900 MHz @GSM/GPRS

DO NOT USE the device in an environment where radio frequency radiation

can cause a risk and may interfere with other devices that may cause

undesired operation - such as medical devices!

DO NOT USE the device if there is a risk of high humidity, hazardous

chemicals or other physical impact!

DO NOT USE the device beyond the specified operating temperature range!

DO NOT MOUNT the device in a hazardous environment!

DO NOT INSTALL/WIRE the device under voltage. For easy disconnection,

the device’s power adapter or power supply should be easily accessible!

ALWAYS DISCONNECT the power supply before starting to mount the

device!

ALWAYS DISCONNECT the device’s power supply before inserting,

removing or replacing the SIM card!

TO SWITCH OFF the device, disconnect all power sources, including the

power supply and USB!

The computer connected to the device must always be connected to the

protective ground!

DO NOT USE a computer to program the device that is not connected to the

protective ground. To avoid a ground loop, the power supply of the computer

and the device must use the same grounding!

DO NOT ATTEMPT to repair the device. Only qualified personnel is allowed

to repair the device!

PROVIDE APPROPRIATE POWER SOURCE for the device. The device

operates safely and properly only with a power supply which meets even the

maximal requirements specified in the user’s manual. You can find the exact

data in the user’s manual and on the http://tell.hu website as well.

DO NOT USE the device with a power supply that does not meet the MSZ

EN 60950-1 standard!

DO NOT REVERSE THE POLARITY of the power supply! Wire the power

supply always according to the polarity indicated on the device!

DO NOT CONNECT the antenna connector to the protective ground! Do not

connect the metallic parts of the antenna connector or the device’s terminals

directly or indirectly to the protective ground, because this may damage the

device!

ATTENTION! The product is provided with built-in automatic power

disconnection (Under Voltage Lock Out) function. The device will turn off

automatically when the supply voltage drops under a critical level.

Indice

Lingue:

Altri manuali tell Telecomando

tell

tell Gate Control PRO Manuale utente

Manuali Telecomando popolari di altre marche

Panasonic

Panasonic EUR7622KB0 Manuale utente

Bang & Olufsen

Bang & Olufsen Beo4 Manuale utente

Sunwave Tech.

Sunwave Tech. RemoteComm SRC-7000 Manuale utente

Multiplex

Multiplex PROFI TX 9 Manuale utente

One Remote

One Remote RMB4 Manuale utente

FUTABA

FUTABA 9ZAP - PART2 Manuale utente

HR Matic

HR Matic HR MULTI 3 Manuale utente

Yamaha

Yamaha ACC-GNRST-30-20 Manuale utente

EisSound

EisSound KBSOUND Manuale utente

Marantz

Marantz RC101 Manuale utente

Conrad

Conrad FS20 TC6 Manuale utente

Anritsu

Anritsu MP1777A Manuale utente

Niles

Niles WVC100 Guida alla risoluzione dei problemi

RCA

RCA RCU1300 Manuale utente

Bang & Olufsen

Bang & Olufsen BEO6 Manuale utente

GE 94901 Manuale utente

Onbon

Onbon YQ1-75 Manuale utente

FUTABA

FUTABA R7108SB Istruzioni per l'installazione

tell Gate Control 20 Manuale utente

Manuali Telecomando popolari di altre marche
