Chapter One Product Brief Introduction
1.1 Features…………………………………..……………………....3
1.2 Unpacking ……………………………………………………….5
Chapter Two Hardware Installation
2.1 Introduction of Panels……………………………………………5
2.2 Environment Required…………………………………………...6
2.3 Hardware Installation…………………………………………….7
Chapter Three Configuration Guide
3.1 Fast Log In ……………………………………………….. 8
3.2 Administrator ……………………………………………… 9
3.2.1 Authentication Configuration…………………………… 9
3.2.2 System IP Configuration…………………………………….. 10
3.2.3 System Status ……………………………………………….. 11
3.2.4 Load Default Setting ………………………………………... 11
3.2.5 Firmware Update …………………………………………...12
3.3 Port Management ……………………………………………... 13
3.3.1 Port Configuration ……………………………………………13
3.3.2 Port Mirroring ………………………………………………. 15
3.3.3 Bandwidth Control…………………………………………… 16
3.3.4 Broadcast Storm Control …………………………………… 17
3.4 VLAN Configuration…………………………………………… 18
3.4.1 Group VLAN Setting …………………………………………18
3.4.2 Multi to 1 Setting……………………………………………. 19
3.5 Trunk Setting …………………………………………………..21
3.6 QoS Setting……………………………………………………..23
3.6.1 Priority Mode………………………………………………….23
3.6.2 Class of Service Configuration………………………………..24
3.7 MAC Address Configuration……………………………………25
3.8 Configuration Backup/Recovery………………………………..27
3.9 Logout……………………………………………………………28
Chapter One Product Brief Introduction
Thanks for purchasing Tenda TEH1206/1216/1224 Web-Smart Ethernet
Switch. TEH1206/1216/1224 is auto-negotiation web-smart switch with
auto-negotiation function. It supports port mirroring, port bandwidth
control; You are able to have real-time monitor on the connectivity status
of each port; Supports 8/16/24 groups of port VLAN and 2 groups of
Trunk Configuration, supports QoS, MAC address Filtering, Broadcast
Storm control etc, equipped with individuation operating interface. It is a
high quality low price product especially suitable for Net-bar, SMB
(Small and Medium-size Business), and Smart residential area.
Configuration of TEH1206/1216/1224 is simple, enables you to plug and
finish the configuration easily.
1.1 Features
¾Fully Compliant with IEEE802.3, IEEE802.3u, IEEE802.3x, 8/16/24
10/100Mbps Auto-Negotiation RJ45 ports, Auto MDI/MDI-X
¾Basic setting function of each port: 10/100Mbps Auto-Negotiation
mode setting, Full/Half duplex mode setting, 802.3x back pressure
flow control setting, port status indicating
¾Port Mirroring: To monitor more than one port at the same time,
supports port monitoring receiving, port monitoring sending and port
monitoring of receiving and sending modes, supports monitoring
across different VLANs
¾Port Bandwidth Control: support 16 different levels of port
bandwidth control
¾VLAN: supports port-based VLAN to divide different VLAN groups
¾Port Trunking: Supports Port Trunking of 2 groups, 2/4 ports per
group, support fault tolerant and hot backup of the cascade
connection pipeline
¾Priority setting: Support 3 types of Priority Queues control, realize
simple QoS application, to prioritize mission-critical data such as
voice or video packets
¾MAC Address Filtering: MAC address learning control, filtering of
fixed MAC address
¾Broadcast storm control: broadcast storm configuration
¾Backup: Support the backup and recovery of the configuration of the
switch
¾Firmware upgrade: Support firmware upgrade via TFTP
¾Easy-to-use operation guide: offer simplified and simple description
of function, operating guide, help user to fast plug and play
¾Auto-Negotiation on each port senses the link speed of a network
device (either10, 100,1000 Mbps) and intelligently adjusts for
compatibility and optimal performance
¾Internal high frequency power switching, ensure stable and reliable
operating
¾Standard 19-inch rack-mountable steel case, 1U height
1.2 Unpacking
Please unpack product and you would find the following items inside:
1. One unit of TEH1208/1216/1224 Ethernet Switch
2. One Power Line
3. One copy of User’s Manual
4. One copy of Warranty Card
Chapter Two Hardware Installation
2.1 Introduction of LED Indicators
Indicator Introduction
ON Power on
POWER OFF Power Off, please check power line and power
interface
ON Other device is connected to the port in normal
condition
LINK/AC
T
Blinking The port is transferring or receiving data
SYS Blinking Switch is restoring to factory default setting or is
restored to factory default setting
ON System is started in normal condition
Note:
How to use the “RESET” button?
If you want to restore to factory default setting, please press the
RESET button when power is off, and then turn on the power, the
system LED will shrink for several times, then please release the
RESET button, after around 5 seconds, the system LED will shrink
for several times again, this means that reset has been finished. Please
turn power off and then restart, then switch will be restored to
factory default setting.
Cautions: Unless you require to delete the current configuration,
please don’t press RESET casually.
2.2 Working Environment Required
¾Ethernet LAN
¾Connect the port of TEH1208/1216/1224 to LAN with twisted pair
cable
¾Web Browser should be Microsoft IE 4.0 or Netscape Navigator 4.0
or above
¾Operating system supporting Windows, Linux, NetWare etc, and
network should be compliant with TCP/IP
¾Please put the switch with base down and don’t put heavy items on
top of switch
¾Please put switch away from heat, ensure enough air flowing near the
switch
¾Please don’t put switch in dirty or wet environment
2.3 Hardware Installation
¾Switch to PC: PC is connectable to any port of switch through
Catalogue 3/4/5 UTP/STP straight or cross over cable
¾Switch to Hub (Through Uplink port): MDI-II Uplink port of Hub (10,
100BASE-TX) is connectable to any port of switch through
Catalogue 3/4/5 UTP/STP straight or cross over cable
¾Switch to Hub (no Uplink port): If the hub is not equipped with
uplink port (MDI-II), you are still able to connect any port of the hub
to any port of the switch through Catalogue 3/4/5 UTP/STP straight or
cross over cable
¾Switch to Switch: You are able to connect any port of two switches
through Catalogue 3/4/5 UTP/STP straight or cross over cable
¾
Note:
Please make sure that there is only one uplink pipeline between switch
and switch, or between switch and hub, otherwise multi pipeline will
form loops, this may cause the whole network to broke down. (Port
Trunking is an exception)
Chapter Three Configuration Guide
3.1 Fast Login
Notice: You must set IP Address manually for the management PC,
because there is not built-in DHCP server in
TEH1208/TEH1216/TEH1224. You can login and configure the switch
after setting the IP Address. The default parameters of the switch are as
follows:
Parameter Default Value
Default IPAddress 192.168.0.1
Default User’s Name admin
Default Password admin
Figure 1
You can fast log in to the configuration Interface of the switch through
the following steps:
a. Connect the switch to NIC port of the computer
b. Turn on the power of the switch
c. Make sure that the IP Address of the computer is at 192.168.0.x (where
x is a number between 2 and 254)
d. Open the Web browser, enter IP Address http://192.168.0.1 into the
address location
e. Input user name and password in the dialog page (default user name
and password are “admin”), press “Enter” button and you will login to the
configuration Interface of the switch as the Figure as follows:
Figure 2
On the menu which is on the left hand side of the page, there are totally 8
items: “Administrator”, “Port Management”, “VLAN Setting”, “Trunk Setting”, “QoS
Setting”, “MAC Address Configuration”.,” Configuration Backup/Recovery” and “Logout”.
Single click on a certain button and you will have the related function
configured. We will give detailed introduction to the setting step by step
in the following chapters.
3.2 Administrator
3.2.1 Authentication Configuration
To set the log in name and password of the switch
