Tenpilot TP06 3Rw Manuale utente
In order to fully explore available functions of TP06 series please take a moment and read this manual before using the device.
TP06 transmitters are compatible with all TENPILOT brand devices.
WALL-MOUNTED REMOTE CONTROL TP06_3Rw
www.sukcesgroup.pl
1. Control:
can control three motors
2. Work frequency:
433,92 MHz, rolling code
3. Power supply:
3 V
4. Battery:
CR2032
5. Dimensions:
90 x 75 x 14 mm
6. Range:
to 30 m
1. General information
2. Detailed description
3. Montage
Radio receiver range is a variable value and can differ from declared values depending on conditions in which device operates.
Possible sources of changes in range are building construction, interference caused by other radio transmitters etc.
Batteries contain substances that may be hazardous to health and may pollute the environment.
Used batteries should be disposed of properly.
1. Dedicated to indoor assembly.
2. Change the battery, when the LED diode doesn’t flash after pressing the button.
Open the upper housing. Using two screws,
mount the housing to the wall.
Close the upper housing
of the remote control.
1
LED diode
control buttons
battery
4. Programming the remote control for garage door opener.
Press CODE button. In the bottom
corner a dot (.) appears.
Press the button on the transmitter
that will control the drive.
The dot on the display disappear.
Press the same button on the transmitter again.
The dot on the display will flash several times.
The remote control has been programmed.
2
SET UP
CODE DOWN
SET UP
CODE DOWN
