Quick Start Guide

Live Streaming Encoder

Vidiu X

A: SD card slot (not shown)

B: Broadcast button

C: Video status indicator (top)

D: Network status indicator (top)

E: Broadcast status indicator (top)

F: OLED display

G: Menu joystick

H: USB modem port (not shown)

I: HDMI input

J: HDMI output

K: Mic/Line stereo input

L: 10/100 Ethernet port

M: USB Type-C power input

PHYSICAL PROPERTIES

BEF

KLM

TABLE OF CONTENTS

Button Operation ................................ 2

Power and Connect ............................. 2

Get Online .......................................... 3

Sharelink ............................................ 6

Choose a Platform and Quality ............ 8

Vidiu App .......................................... 9

Recording ........................................ 10

Menu Joystick

Use the menu joystick to

navigate through the menus.

Press the joystick inward to

conﬁrm or open selection.

Broadcast/Record Button

Start/stop broadcast or

recording.

2Connect power to Vidiu X using the included USB-C A/C adapter or another USB-C

power source. Vidiu X will power on once connected.

Connect the HDMI output from your video source to Vidiu X’s HDMI input (I).

BUTTON OPERATION

POWER AND CONNECT

Use the Menu joystick and the Broadcast/Record button to navigate the front panel and

to begin your livestream.

GET ONLINE

You can use the front panel interface, the built-in web UI, or the Vidiu app (iOS/Android)

to remotely control and conﬁgure Vidiu X to connect to a network and get online.

b. Client Mode - Select Client, tap Scan for Networks, then enter your credentials

for the network you select.

Select a wireless mode:

CONNECT TO A WIFI NETWORK

Navigate to the Network Settings menu from the front panel, then select Wireless.

a. Access Point (AP) Mode - Connect your phone or laptop to Vidiu X’s network,

Vidiu-X-XXXXX (XXXXX represents the last ﬁve digits of Vidiu X’s serial number).

Vidiu X supports two wireless (wi-ﬁ) modes; Access Point (AP) Mode and Client Mode.

In AP Mode, Vidiu X generates a wi-ﬁ network for your phone or laptop to connect to. To

use wi-ﬁ as your Internet connection, you’ll need to connect Vidiu X to another network

using Client mode.

Insert a compatible 3G/4G USB modem, then wait for the icon to appear on the

front panel display.

CONNECT VIA USB MODEM

2Navigate to the Network menu, then select Wired to verify that Ethernet is set to

DHCP and to view Vidiu X’s IP address.

Plug an Ethernet cable from the Vidiu X’s Ethernet port to an Ethernet switch

or ro uter.

CONNECT VIA ETHERNET

2Enter the network’s IP address in your

web browser’s navigation bar.

Press down on the Menu joystick until

the IP address that corresponds to the

selected network is revealed.

ACCESS THE WEB UI

Before you begin streaming, make sure you visit teradek.com/pages/downloads to check for the latest

ﬁrmware and/or software updates. You can also check for the latest ﬁrmware updates by navigating to

System>Firmware>Check for update on the web UI.

3Enter the default password ”admin.”

Sharelink is a cloud service by Teradek created speciﬁcally for Vidiu devices. Sharelink

unlocks the full potential of your live streams by oering network bonding, streaming

to multiple platforms simultaneously, remote management from anywhere in the world,

and cellular tethering. NOTE: A subscription to Sharelink is required to bond Internet

connections.

SHARELINK

TO CREATE A SHARELINK ACCOUNT:

2After selecting a plan and creating an account, return to the login screen and enter

your credentials.

Visit sharelink.tv and select a pricing plan that best suits your needs.

• Ethernet

• Up to one Teradek Node or 3G/4G/LTE USB modem.

• WiFi (Client mode) − Connect to an existing wireless network or mobile hotspot

SUPPORTED CONNECTIONS

Select Sharelink from the Streaming

menu, then click Apply.

Copy the authorization code generated

for your Vidiu X, then navigate to the

link provided.

select Add new Vidiu.

TO CONNECT TO SHARELINK:

Enter the authorization code, then click Add.

Vidiu X can broadcast directly to any compatible video streaming platform. Simply enter

your credentials using the Vidiu app, web UI (page 5), or the front panel interface.

2Select a Stream mode - Facebook, YouTube, Vimeo, Wowza − or select RTSP or

manual RTMP.

Enter the Streaming menu.

4Enter the Input/Encoding menu, then select your desired video bitrate and resolution.

Enter your credentials or destination information, then click Apply.

5To Go Live:

• From the front panel - Press the Broadcast/Record button.

• From the web UI - Click the button.

• From the Vidiu app - Tap the Go Live button.

CHOOSE A PLATFORM AND QUALITY
