part description

part number

qty.

A — 1

B1.5" attachment strap

8535494 4

PARTS INCLUDED • PIÈCES INCLUSES • PIEZAS INCLUIDAS

A

B

Model # XXXXXXXXXXXXXXXXXXXXXX Purchase Date XXXXX/XXXXX/XXXXX Place of PurchaseXXXXXXXXXXXXXXXXXXXXXX

OUTBOUND ROOFTOP CARGO BAG 868

• If your vehicle does not have raised crossbars or

side rails, DO NOT USE this product.

CAUTION: When mounting bag to raised side rails,

front attachment straps must be forward

of rail’s center support post, otherwise

bag may slide o back of roof.

CAUTION: NOT recommended for use on glass

roof surfaces like sun/moonroofs and

panoramic roofs. Bag contents can

damage or shatter glass roofs.

•

Do not overload cargo bag.

•

Do not exceed 100 lbs. weight capacity or the

weight capacity of your roof as stated by vehicle

manufacturer.

•

This bag is WEATHER RESISTANT, NOT

WATERPROOF. Cargo must be packed in plastic

bags if raining.

•

Be sure to check all straps for tightness at regular

intervals during travel.

•

Do NOT leave mounted on vehicle without cargo.

•

This product will NOT prevent dents resulting from

improper loading, securing, or driving.

•

ZIPPER IS NOT TO FACE THE FRONT OF THE

VEHICLE.

•

Avoid removing bag from roof while fully loaded.

•

For cleaning, a damp sponge works best using

only water with a mild detergent which contains no

additives (such as alcohol, chlorine or ammonia)

as these could discolor the surface. Allow to air dry

completely.

PRODUCT REGISTRATION

WARNINGS / LIMITATIONS

cargo bag

1

• Unfold the

cargo bag and

unzip the top.

Do not open

the top yet.

3

• Using supplied attachment straps, secure bag tightly to

crossbars by routing strap around bar and through front/

rear anchoring ring. See diagram for routing of strap through

buckle. Excess strap should be wrapped around luggage rack

and secured.

Buckle

Routing

• If the distance between your crossbars is less than 36" drape the remaining

length of the bag over rear crossbar, and follow instructions in a. above using side

anchoring rings instead of rear.

2

• Make sure vehicle roof is clean of dirt or debris. Place cargo bag, opening

towards rear of vehicle, on roof between crossbars and/or side rails of your

factory-installed or aftermarket roof rack. When attaching to crossbars, if

possible adjust bar placement so that bag ends just contact bars and bag

bottom sits fully on roof. Center bag side-to-side on roof.

A

B

MOUNTING TO CROSSBARS

Center Support Post

Front

Back

4

• When mounting to roof racks equipped with side rails only, use side anchoring

rings and position bag so that at least one set of rings is forward of side rail center

support post.

5

• Open the top of the cargo bag and gently rest on the roof and windshield.

6• Load cargo bag evenly. Avoid overstung.

CAUTION: Before loading, consult vehicle

owner’s manual for any weight

bearing limitations. Placing hard

point items directly on roof may

cause vehicle damage.

MOUNTING TO SIDE RAILS

7

• Close bag completely with zipper.

9

• Secure zipper storm ﬂap to bag at all hook+loop closure points.

• Tighten compression straps to secure bag’s contents.

8

• Place narrow hook+loop zipper pull inside wide hook+loop pull and press together to join securely.

A B

ROOF RACKS

THULE CARGO CARRIERS
