USER MANUAL
Short air walker - 9’’
Product code: 14111/14113/14115/14117
1. Characteristics
The air walker consists of a splint in the shape of a shoe which is made
of PVC, and inner liner of soft material. Owing to the application of
modern materials, the orthosis is air permeable and removes excessive
heat and moisture perfectly. The air walker is equipped with system of
circumferential straps which enable individual adjustment of
stabilization force and with profiled anti-sliding sole which facilitates
the patient possibly physiological gait.
2. Application
Air walker is used in post-traumatic and post-operative rehabilitation
process in order to limit the range of mobility in ankle joint and to
improve functional activities. The orthosis is also used to stabilize the
foot and the shin in intermediate (neutral) position, in post-traumatic
injuries in the area of ankle joint.
Indications for use:
•post-operative treatment
•twist and dislocation of ankle joint
•Achilles tendon rupture
•as an alternative for plaster cast immobilization
•fractures in the area of foot, upper and lower ankle joint
3. Contraindications
Do not use in case of:
•skin abrasion
•eczema
•wound and other skin injuries
2
•after application of warming gel or ointment
Note! In case of varicose veins the usage of the air walker is restricted.
Contact with attending physician to determine whether the product
may be used together with compression stockings.
4. Notes and recommendations
Timago International Group does not bear responsibility of improper
use of the product, failure to comply safety regulations and misuse.
5. Fitting instruction
•Unfasten circumferential straps, take out front shell of the walker
and inner liner.
•Put the inner liner on the leg. If necessary, use included additional
air pads. Fasten the inner liner and put it inside the air walker.
•Put the front shell of the orthosis and fasten circumferential
straps by means of Velcro.
•Check the correctness of fitting in standing position. If necessary
adjust the force of circumferential straps attachment.
Size data (shoe size)
XS 34-36 cm
S 37-38 cm
M 39-43 cm
L 44-46 cm
6. Maintenance
•Circumferential straps and inner liner can be washed by hand or in
washing machine at temperature of 30oC. Do not tumble,
chlorinate, iron, bleach, dry cleaning, use tumble dryer.
•Ensure the Velcro is fastened in order not to destroy the material.
•Dry at room temperature far from intensive heat source.
•Clean the PVC splint with damp cloth with soap.
•Dry the splint thoroughly.
3
7. Storage and transport conditions
Device should not be exposed to direct sunlight, water or moisture.
8. Warranty information
All products distributed by our company are under a warranty, the
terms of which are described in the warranty card received at the time
of purchase.
Please, keep in mind that for warranty purposes, the proof of purchase
(receipt or invoice) should be retained.
9. Labels
Reference
number
Manufacturer
LOT number
Manufacture date
Serial number
Medical device
Note
Please read the
instruction
The manufacturer checked for compliance with
essential medical devices requirements.
Our complete line of products is available from our distributors. Learn
more at: timago.com. Thank you for choosing Timago!
4
Timago International Group
Spółka z o.o. i Spółka – Spółka komandytowa
ul. Karpacka 24/12, 43-316 Bielsko-Biała, Polska
UNITED SURGICAL
Fort Wayne, IN 46803,
2235 Pensylvania St., USA
EMERGO EUROPE
Molenstraat 15, 2513 BH,
The Hague, Holandia
Rev.II, date 20.05.2021
