MR-8A ASSIGNER/PATCH BAY

TOA

PROFESSIONAL MUSIC & ENTERTAINMENT

The Toa model MR-8A is a one-rack space Assigner Unit for use with Toa’s MR-8T

Eight Track Studio Cassette Recorder. The MR-8A adds patch-free channel bouncing,

rack and source mixing, and input assignment capabilities to the MR-8T Recorder.

With the MR-8A as an interface, connections can be made by means of the switches

on its front panel.

Two microphone inputs with level controls ensure optimum performance when

recording mics. Multiple inputs can be mixed by simultaneously routing them to the

same destination.

The MR-8A can be utilized as a standalone 8 x 8 electronic audio Patch Bay.

SPEClFlCATlONS

Line input/Monitor input

Input impedance: 100k Ω

Normal input level: -10dBV

Maximum output level: +18dBV

Line output/TO INPUT DIN connector

Output impedance: 100 Ω

Normal output level: -10dBV

Maximum output level: + 18dBV

Microphone input

Input impedance: 2k Ω unbalanced

Normal input level: -55dBV

Maximum input level: -25dBV

FROM OUTPUT DIN connector (PB input)

Input impedance: 20k Ω

Normal input level: -10dBV

Maximum input level: +18dBV

Frequency response

20 - 20,000Hz, +0, -2dB (LINE IN)

50 - 20,000Hz, +0, -3dB (MIC IN)

Distortion

0.05% (1 kHz, - 1 10dBV/LINE IN)

Noise

-90dBV

(LINE IN/Volume control at maximum position)

-122dBV (IHF-A, equivalent input noise)

(MIC IN/Volume control at maximum position)

Crosstalk

60dB (1 kHz, - 10dBV/LINE IN)

Power consumption

4W

Dimensions

483 (w) x 49 (h) x 299 (d) mm

19 (w) x 1.93 (h) x 11.8 (d) inches

Weight: 3.8kg (8.38 Ibs)

Accessories

Instruction manual x 1

Fuse x 1

*The above specifications are subject to change

without notice.

MR-8A

BLOCK DIAGRAM

TRACK BUSS

12345678

LINE IN

(-1OdBV)

(1OOk

Ω )Ω )

CH1~CH2

MIC

(–55dBV)

(2k Ω)Ω)

LINE IN

CH3~CH8

(-1OdBV)

(1OOk

Ω)Ω)

FROM MR-8T

OUTPUT

HOOK-UP DIAGRAM

Drum Synthesizer

MONITOR

MR-8T

Toa Electronics, Inc.

601 Gateway Boulevard

South San Francisco, California 94080

TOA

Telephone: (415) 588-2538

FAX (415) 588-3349
