Topeak FlashStand FAT Manuale utente

for 26" Mountain Bike

FlashStand FAT

User's Guide

* Maximum Weight Load: 20 kgs / 44 lbs

83˚~86˚

Adjust FlashStand FAT height to make sure your bike is within the

recommendedangleof83˚~86˚ (from horizontal plane) forstability

of your bike. Improper installation or lean angle may cause your

bike to fall and cause damage to it and/or FlashStand FAT.

IMPORTANT NOTES

80mm~ 180mm

(3.2"~7")

45mm (1.8")

60mm (2")

FlashStand FAT is designed to be used on bikes with crank-

arm width less than 45mm (1.8") at top 60mm (2") insert.

4mm

Allen Key

Support

Leg

If support legs on FlashStand FAT become loose, tighten its bolts

as shown. Do not over tighten the bolts as this may damage the

support legs.

FlashStand FAT is designed to be used on bikes with crank-

arm distance from the ground between 80mm and 180mm

(3.2"~7").

* Please read all instructions and caution notes carefully before use.

WARRANTY

for 26" Mountain Bike

FlashStand FAT

User's Guide

Topeak products are available only from professional bicycle shops. Please contact your nearest Topeak authorized bicycle dealer for any questions.

For customers in the USA, call: 1-800-250-3068

Website: www.topeak.com

2-year Warranty: All mechanical components against manufacturer defects only.

Warranty Claim Requirements

To obtain warranty service, you must have your original sales receipt. Items returned without a sales receipt will assume that the warranty begins on the date of manufacture.

All warranties will be void if the the product is damaged due to user abuse, overload, system alteration, modification, or used in any way not intended as described in this

user's guide.

* The specifications and design are subject to change without notice.

M-TW007-GB 9/08

• Remove any large or heavy bicycle accessories (handlebar bag, rack bag, large saddle bag, pannier bags, etc.) that may cause any possible injury.

• Never exert force on the bike when using FlashStand FAT. Doing so may damage FlashStand FAT's support legs.

• Not recommended for use on grass, loose dirt, gravel, uneven or soft surfaces.

• Topeak FlashStand

FAT

is designed for supporting your bike only.

INSTALLATION

When crank-arm width is larger

than 36mm, remove the top plate

ofFlashStandFATbeforeinstalling.

Adjusting

FlashStand FAT

height

PRESS

•FlashStandFAT is NOTrecommended

for use on downhill or freeride

mountainbikes because theirbottom

bracket height designs may be

beyond the FlashStand FAT support

limitations.

•Adjust FlashStandFAT heighttomake

sure your bike is within the

recommended angle of 83˚~ 86˚

(from horizontal plane) for stability

of your bike.

83˚~86˚

PRESS

36mm (1.4")

45mm (1.8")

CAUTION
