FormNo.3380-737RevA

LEDLightKit

GreensPro™1240GreensRoller

ModelNo.44923

InstallationInstructions

WARNING

CALIFORNIA

Proposition65Warning

ThisproductcontainsachemicalorchemicalsknowntotheStateofCaliforniato

causecancer,birthdefects,orreproductiveharm.

LooseParts

Usethechartbelowtoverifythatallpartshavebeenshipped.

DescriptionQty.Use

Lightmountingbracket(right)1

Lightmountingbracket(left)1

LEDlight2

Hex-headbolt(M6x20mm)2

Locknut(M6)2

Washer(1/4x7/8inch)2

Washer(M6x20mm)2

InstalltheLEDlights.

Switch1

Wiringharness1

Cabletie4

Installtheswitchandthewiringharness.

©2014—TheToro®Company

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUK

AllRightsReserved*3380-737*A

InstallingtheLEDLights

1.Aligntheleftlightmountingbracketwiththeholein

therearleftcorneroftheseatpan(Figure1).

Note:Thebracketshouldbenearlyparallelwiththe

ground.Ifitisnot,trytheotherbracket;referto

Figure2.

G025237

1

6

7

2

3

4

5

Figure1

1.LEDlight5.Washer(M6x12mm)

2.Lightmountingbracket6.Washer(1/4x7/8inch)

3.Nut(includedwithlight)7.Hex-headbolt(M6x20

mm)

4.Locknut(M6)

G025238

Figure2

2.Securethebrackettotheseatpanwithahex-headbolt

(M6x20mm),alargewasher(1/4x7/8inch),asmall

washer(M6x12mm),andalocknut(M6).

3.AlignthebottomoftheLEDlightontheleftsidewith

theholeonthelightmountingbracket(Figure1).

4.Securealighttothemountingbracketbytighteningthe

locknut(includedwiththelight)asshowninFigure1.

5.Repeatsteps1through4toinstalltherightlight.

2

InstallingtheSwitchandthe

WiringHarness

1.Removeanddiscardtheholeplugthatisinstalledin

theholenearthehourmeterinthesideoftheseatpan.

1

G025239

2

Figure3

1.Lightswitch2.Holeplug

2.Inserttheswitchintothehole(Figure3).

3.Connecttheappropriateconnectorofthelightkit

wiringharnesstothebackoftheswitch(Figure4).

1

G025240

2

Figure4

1.Lightkitwiringharness2.Switch

4.Connecttheappropriateconnectorofthelight

kitwiringharnesstotheunusedconnectorofthe

hour-meterwiringharness(Figure5).

1

G025241

2

Figure5

1.Hour-meterwiringharness2.Lightkitwiringharness

5.RoutethelightkitwiringharnessasshowninFigure6.

2

G025245

2

1

Figure6

Undersideshown

1.Lightkitwiringharness2.Cableties

6.Connecttheremainingconnectorstothelights.

7.Securethewiringharnesswiththecabletiesinthe

locationsshowninFigure6.

8.Ensurethatallofthecomponentsaresecure.

9.Inawell-ventilatedarea,startthemachineandsetthe

enginetofullspeed.

10.Operatetheswitch,andensurethatbothofthelights

work.

Important:Ifthelightsdonotturnon,checkall

theconnections.

11.Ifnecessary,loosenthescrewandthenutonthesides

ofeachlight,androtatethelightsupordownandfrom

sidetosidetoattainthedesiredoperatingposition.

Important:Securetheadjustmentsbytightening

thescrewandthenutonthesidesofeachlight.

3
