FormNo.3448-708RevA

FrameKit

Greensmaster®e1021oreFlex®1021Greensmower

ModelNo.140-9341

InstallationInstructions

Installation

PreparingtheMachine

1.Parkthemachineonalevelsurface.

2.Engagetheparkingbrake.

3.Shutoffthemachineandremovethekey.

RemovingtheExisting

FrameandInstallingthe

NewFrame

Toremovetheexistingframeandinstallthenew

frame,refertotheinstructionsinthetraction

unitServiceManualforremovingandinstalling

componentsthatconnecttotheframe,includingthe

drumdrive,transmission,andcuttingunit,among

othercomponents.RefertoInstallingtheHandle

(page2)forinstructionstouseloosepartsinthiskit

toinstallthehandletotheframe.

Figure1showsanoverviewoftheGreensmaster

e1021frameandthesurroundingcomponents.

g368055

Figure1

1.Frame

©2021—TheToro®Company

8111LyndaleAvenueSouth

Bloomington,MN55420

Registeratwww.T oro.com.OriginalInstructions(EN)

PrintedintheUSA

AllRightsReserved*3448-708*

InstallingtheHandle

1.Applythread-lockingcompound(e.g.,blue

Loctite®)tothethreadsofthebolts(1/2x2-1/2

inches)andframe(Figure2).

g370533

Figure2

1.Applythread-locking

compoundtothebolt

threads.

2.Applythread-locking

compoundtotheframe

threads.

2.Use2bolts(1/2x2-1/2inches),1anti-rotation

washer,and1existingatwashertosecurethe

handleassemblytotheframe(Figure3).

g370531

Figure3

1.Bolts(1/2x2-1/2inches)3.Handleassembly

2.Existingatwasher4.Anti-rotationwasher

3.Torquetheboltsto102N∙m(75ft-lb).
