Toyota Navigation and Multimedia System Manuale utente

249

Interior features

3-2. Using the audio system

Audio system types

Entune Audio

Title Page

Using the radio P. 272

Using the CD player P. 274

Playing back MP3 and WMA discs P. 274

Operating an iPod P. 281

Operating a USB memory P. 287

Optimal use of the audio system P. 271

Using the AUX port P. 293

250

3-2. Using the audio system

Entune Audio Plus

Owners of this system should refer to the “Navigation and Multime-

dia System Owner's Manual”.

Entune Premium Audio with Navigation

Owners of this system should refer to the “Navigation and Multime-

dia System Owner's Manual”.

251

3-2. Using the audio system

Interior features

Audio system

Audio system operation buttons

Operations such as listening to audio, using the hands-free phone

and changing audio settings are started by using the following but-

tons.

“AUDIO” button

Display the “Select Audio Source”

screen or audio top screen. (→P. 268)

button

Press this button to access the

Bluetooth® hands-free system.

(→P. 312)

“CAR” button

Press this button to access the energy

monitor/consumption screen. (→P. 41)

“SETUP” button

Press this button to customize the

function settings. (→P. 261)

252

3-2. Using the audio system

Operating the touch screen

By touching the screen with your finger, you can control the audio

system, etc.

■Drag*

Touch the screen with your finger, and move the screen to the

desired position.

●Scrolling the lists

■Flick*

Touch the screen with your finger and quickly move the screen by

flicking your finger.

●Scrolling the main screen page

*:The above operations may not be performed on all screens.

■When using the touch screen

●If the screen is cold, the display may be dark, or the system may seem to

be operating slightly slower than normal.

●The screen may seem dark and hard to see when viewed through sun-

glasses. Change your angle of viewing, adjust the display on the “Display

Settings” screen (→P. 265) or remove your sunglasses.

●Flick operations may not be performed smoothly in high altitudes.

253

3-2. Using the audio system

Interior features

NOTICE

■To avoid damaging the touch screen

●To prevent damaging the screen, lightly touch the screen buttons with your

finger.

●Do not use objects other than your finger to touch the screen.

●Wipe off fingerprints using a glass cleaning cloth. Do not use chemical

cleaners to clean the screen, as they may damage the touch screen.

254

3-2. Using the audio system

Steering wheel audio switches

Operating the audio system using the steering wheel switches

Volume switch

• Increases/decreases vol-

ume

• Press and hold: Continu-

ously increases/decreases

volume

Back switch

• Returns to the previous

screen

Cursor switch

• Selects (radio stations/radio

presets/tracks/files/songs)

• Moves cursor

• Press and hold: Seek up/

down (radio stations)

• Fast up/down (tracks/files)

Enter switch

• Displays the preset/list

screen

• Selects items

Some audio features can be controlled using the switches on the

steering wheel.

Operation may differ depending on the type of audio system or navi-

gation system. For details, refer to the manual provided with the

audio system or navigation system.

255

3-2. Using the audio system

Interior features

“MODE/HOLD” switch

• Changes audio source

• Press and hold this switch

to mute or pause the current

operation

To cancel the mute or

pause, press and hold

CAUTION

■To reduce the risk of an accident

Exercise care when operating the audio switches on the steering wheel.

256

3-2. Using the audio system

USB/AUX port

Connecting using the USB/AUX port

■iPod

Push the lid.

Open the cover and connect an

iPod using an iPod cable.

Turn on the power of the iPod if it

is not turned on.

■USB memory

Push the lid.

Open the cover and connect the USB memory device.

Turn on the power of the USB memory device if it is not turned on.

■Portable audio player

Push the lid.

Open the cover and connect the portable audio player.

Turn on the power of the portable audio player if it is not turned on.

Connect an iPod, USB memory device or portable audio player to the

USB/AUX port as indicated below. Select “iPod”, “USB” or “AUX” on

the audio source selection screen and the device can be operated

via audio system.

STEP

257

3-2. Using the audio system

Interior features

CAUTION

■While driving

Do not connect a device or operate the device controls.

258

3-2. Using the audio system

Basic audio operations

Operating the audio system

Basic audio operations and functions common to each mode are

explained in this section.

Press the “∧” or “∨” button

to seek up or down for a

radio station, or to access a

desired track or file.

Press this knob to turn the audio sys-

tem on and off, and turn it to adjust

the volume.

Press this button to eject a disc Press to pause

or resume play-

ing music.

Insert a disc

into the disc slot

: Select to pause music.

: Select to resume playing

music.

Turn this knob to select radio

station bands, tracks and files.

Also the knob can be used to

select items in the list display.
