MULTIMEDIA REPAIR GUIDE

for

Touch 2 & Touch 2 with Go

DA & Ext. Box

How to Identify T2wG and Device ID

How to access the Service Menu

How to check DTC codes

How to access the Repair Manual

How to install latest softwares

Top page

NG Techdoc

Unknown issue

Preamble

This document is intended to help technicians to solve issues related to the

multimedia system Touch 2 (with Go) only.

This document concerns all Toyota vehicles equipped Touch 2 or Touch 2 with

Go except Aygo, ProAce and Land Cruiser 200.

This document aims to guide you in effectively diagnosing the customer

complaint and to support you solving the issue.

Toyota Aygo

Toyota ProAce

Toyota Land Cruiser 200

DA & Ext. Box

How to Identify T2wG and Device ID

How to access the Service Menu

How to check DTC codes

How to access the Repair Manual

How to install latest softwares

Top page

NG Techdoc

Unknown issue

Information about the Touch 2 system

There are 2 possible configurations for the Touch 2 system :

-Display Audio only (Touch 2)

-Display Audio + Extension Box (Touch 2 With Go)

The Extension Box is an optional module which brings new functionalities to the

multimedia system.

Display Audio

Display Audio with location of the Extension Box

Extension Box

DA & Ext. Box

How to Identify T2wG and Device ID

How to access the Service Menu

How to check DTC codes

How to access the Repair Manual

How to install latest softwares

Top page

NG Techdoc

Unknown issue

How to install the Extension Box in the vehicle

Go on:

Remarks: (C-HR only)

When installing the Extension Box, pay attention that the Extension unit is correctly

oriented. The big supplier label must face the ground, and the terminals of the EXT box

should face the interior of the car not the engine.

Techdoc 1: Accessory Installation Manual

1- Select the vehicle

2- Select installation manual

3- Select Navigation systems

4- Follow the manual instructions

DA & Ext. Box

How to Identify T2wG and Device ID

How to access the Service Menu

How to check DTC codes

How to access the Repair Manual

How to install latest softwares

Top page

NG Techdoc

Unknown issue

1- Understand the problem

Ask the customer details about the complaint and its occurrence conditions

1. What is the problem (phenomenon description)

2. When did the problem start (i.e. after pairing new phone, after update,

always present…)

3. When does the problem occur (i.e. at vehicle start, when driving,

random, certain area, specific operation, ...)

4. Details count (i.e. brand and model of paired phone, size USB memory…)

DA & Ext. Box

How to Identify T2wG and Device ID

How to access the Service Menu

How to check DTC codes

How to access the Repair Manual

How to install latest softwares

Top page

NG Techdoc

Unknown issue

2- Identify the multimedia system

-Is it a Touch 2 system ?

-Is the multimedia system composed by the Display Audio only, or is

there also an Extension Box ?

The software version gives the information.

Go to: -> Setup -> General -> System information

In this menu, you can find the Device ID and the system configuration:

-Touch 2 with Extension Box:

Touch 2 with Go / Go Plus

Touch 2 with Go versions: 3.x.x, 4.x.x and 6.x.x (MM13-14-16)

W / E: West Europe Map / East Europe Map

L (Low): Touch 2 with Go

H(High): Touch 2with Go Plus

-Touch 2 without Extension Box (DA only): Touch 2

Device ID starts by 13, 14 or 16

(MM13-14-16)

MM13

4.x.x W L

DA & Ext. Box

How to Identify T2wG and Device ID

How to access the Service Menu

How to check DTC codes

How to access the Repair Manual

How to install latest softwares

Top page

NG Techdoc

Unknown issue

3- Check the DTC codes menu in the vehicle

Access the Service menu ?

1) First method

a- Key “ON”

b- Press and hold the hard key “CAR”

c- Switch On/Off the headlights 3 consecutive times in quick succession

2) Alternative method (Service menu for vehicle with Daytime Running Light)

4 Click on Screen off

1 Audio off (click on On/Off button)

2 Access to the Setup Menu

3 Access to the Display Menu

5 Once Screen off, click 5 times on “>”, then 5 times on “<”

DA & Ext. Box

How to Identify T2wG and Device ID

How to access the Service Menu

How to check DTC codes

How to access the Repair Manual

How to install latest softwares

Top page

NG Techdoc

Unknown issue

Check the presence of DTC codes

After following one of the two methods previously explained, the Service Menu appears.

Please see below > Next “Failure Diagnosis” > “System Check”

If any DTC exist click “Details” next to the component (for example DA or EXT BOX)

DA & Ext. Box

How to Identify T2wG and Device ID

How to access the Service Menu

How to check DTC codes

How to access the Repair Manual

How to install latest softwares

Top page

NG Techdoc

Unknown issue

A - No DTC code found

Please click on :

B - DTC codes found –How to access the Repair Manual

Look-up the meaning of the DTC-codes in the Repair Manual

Go on NG Techdoc. (See hyperlink at the bottom of the page)

Next Step

1 - Click on the magnifying glass

2 - Select the customer vehicle

DA & Ext. Box

How to Identify T2wG and Device ID

How to access the Service Menu

How to check DTC codes

How to access the Repair Manual

How to install latest softwares

Top page

NG Techdoc

Unknown issue

3 - Select Repair Manual

4 - Click on Search

5 –Select the corresponding repair guide
