TP-Link TL-SF1008D - 10/100M FAST ETHERNET SWITCH Manuale utente

www.tp-link.com

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

Features：

8-Port 10/100Mbps

Desktop Switch

Description：

Up to 200Mbps full duplex bandwidth capability for high speed

data processing

8 10/100Mbps Ethernet ports

Auto MDI/MDIX eliminates the need for crossover cables

Auto-Negotiation ports provide smart integration between

10Mbps and 100Mbps hardware

IEEE 802.3x ow control provides reliable data transfer

Innovative energy-ecient technology saves power consumption

up to 60%

Plug and play design simplies installation

TL-SF1008D

The TL-SF1008D 8-Port 10/100M desktop switch provides an easy way to expand your wired network. All 8 ports support Auto MDI/MDIX, no need to

worry about the cable type, simply plug and play. Featuring full duplex, the TL-SF1008D can process the data at a speed of up to 200Mbps, making it an

ideal choice for expanding your high performance wired network. Moreover, with the innovative energy-ecient technology, the TL-SF1008D can save

up to 60% of the power consumption, making it an eco-friendly solution for your home or oce network.

www.tp-link.com

Specifications are subject to change without notice. TP-LINK is a registered trademark of TP-LINK Technologies Co., Ltd. Other brands and product names are

TL-SF1008D

8-Port 10/100Mbps Desktop Switch

Package:

Related Products:

- 8-Port 10/100Mbps Desktop Switch

TL-SF1008D

- User Guide

- Power Adapter

- 300Mbps Wireless N ADSL2+ Modem Router

TD-W8961ND

- 5-Port 10/100Mbps Desktop Switch

TL-SF1005D

- 8-Port Gigabit Desktop Switch

TL-SG1008D

Specifications：

Interface

IEEE Standards

Protocol

Switching Features

Forwarding Rates

Data Rates

LEDs

Transfer Method

Power Supply

Certications

Dimensions (W x D x H)

Environment

8 10/100Mbps ports, Auto-Negotiation, Auto-MDI/MDIX

IEEE 802.3, IEEE 802.3u, IEEE 802.3x

CSMA/CD

Half and Full Duplex,

MAC Address Learning,

1.6Gbps backplane bandwidth

10BASE-T: 14880pps/port;

100BASE-TX: 148800pps/port

10/100Mbps at Half Duplex;

20/200Mbps at Full Duplex

Power, Ethernet Ports (1, 2, 3, 4, 5, 6, 7, 8)

Store and Forward

External Power Adapter (Output:5.0V/0.6A)

CE, FCC, RoHS

5.3 × 3.1 × 0.9 in. (134.5 × 7× 22.5 mm)

Operating Temperature: 0°C~40°C (32°F~104°F)

Storage Temperature: -40°C~70°C (-40°F~158°F)

Operating Humidity: 10% ~ 90% non-condensing

Storage Humidity: 5%~90% non-condensing

Diagram:
