TP-Link TL-SF1008P Manuale utente

User Guide

TL-SF1008P

8-port 10/100M Desktop PoE Switch

Rev：1.0.0

71035874

Specifications are subject to change without notice.

is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD.

Other brands and product names are trademarks or registered

trademarks of their respective holders.

No part of the specifications may be reproduced in any form or by

any means or used to make any derivative such as translation,

transformation, or adaptation without permission from TP-LINK

http://www.tp-link.com

FCC STATEMENT

This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference in a residential installation. This equipment

generates, uses and can radiate radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the

equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and

receiver.

•Connect the equipment into an outlet on a circuit different

from that to which the receiver is connected.

•Consult the dealer or an experienced radio/ TV technician

for help.

This device complies with part 15 of the FCC Rules. Operation is

subject to the following two conditions:

1) This device may not cause harmful interference.

2) This device must accept any interference received, including

interference that may cause undesired operation.

Any changes or modifications not expressly approved by the party

responsible for compliance could void the user’s authority to operate

the equipment.

CE Mark Warning

This is a class B product. In a domestic environment, this product

may cause radio interference, in which case the user may be

required to take adequate measures.

SAFETY NOTICES

Cautions

Do not use this product near water, for example, in a wet basement

or near a swimming pool.

Avoid using this product during an electrical storm. There may be a

remote risk of electric shock from lightning.

CONTENT

Package Contents...........................................................................1

Chapter 1. Introduction of the Product ........................................1

1.1 Overview of the Product .............................................1

1.2 Convention ...................................................................2

1.3 Features........................................................................2

Chapter 2. Installation ....................................................................3

2.1 Mounting the Switch on a Desk..................................3

2.2 Power On ......................................................................4

Chapter 3. Identifying External Components ..............................4

3.1 Front Panel ...................................................................4

3.2 Rear Panel ....................................................................6

Appendix A: Specifications ...........................................................8

Package Contents

The following items should be found in your box:

¾One TL-SF1008P 8-port 10/100M Desktop PoE Switch

¾One DC Power Adapter

¾Four rubber cushions to be used under the switch

¾This User Guide

Note

Make sure that the box contains the above items. If any of the listed

items are damaged or missing, please contact with your distributor.

Chapter 1. Introduction of the Product

Thank you for choosing the TL-SF1008P 8-port 10/100M Desktop

PoE Switch.

1.1 Overview of the Product

The TL-SF1008P 8-port 10/100M Desktop PoE Switch provides the

seamless network connection, which integrates 100Mbps Fast

Ethernet and 10Mbps Ethernet network capabilities.

This PoE Switch is also a Power Sourcing Equipment (PSE*). Four

of the eight Auto-Negotiation RJ45 ports (port-1~port-4) on the

switch support Power over Ethernet (PoE*) function, which can

automatically detect and supply power with those IEEE

802.3af-complaint powered devices (PDs*).

1.2 Convention

The Switch or TL-SF1008P mentioned in this User Guide stands for

TL-SF1008P 8-port 10/100M Desktop PoE Switch without any

explanation.

1.3 Features

¾Complies with IEEE802.3, IEEE802.3u, IEEE802.3af standards

¾8 10/100Mbps Auto-Negotiation RJ45 ports with 4-port PoE

function (port-1~port-4), all of them support Auto-MDI/MDIX

¾Supports PoE power up to 15.4W for each PoE port

¾Supports PoE power up to 53W for PoE ports

¾Supports PoE IEEE802.3af compliant PDs

¾Supports IEEE802.3x flow control for Full-duplex Mode and

backpressure for Half-duplex Mode

¾1K entry MAC address table of the TL-SF1008P with auto-

learning and auto-aging

*PSE: a device (switch or hub for instance) that will provide power in a PoE

setup.

*PoE: This technology describes a system to transmit electrical power, along

with data, to remote devices over standard twisted-pair cable in an

Ethernet network.

*PD: a device powered by a PSE and thus consumes energy. Examples include

powering IP telephones, wireless LAN access points, network cameras,

network hubs, embedded computers etc.

¾LED indicators for monitoring power, link, activity and speed

¾External power adapter supply

Chapter 2. Installation

During the installation procedure, please only use the accessories

equipped with the switch.

2.1 Mounting the Switch on a Desk

To install the Switch, please follow the steps:

1) You can place the Switch on a flat desk.

2) Please insert the power adapter carefully to the power socket of

the switch, and then connect it properly to a power source

through the cable of the switch.

3) Ensure adequate ventilation space around the switch for

dissipating heat and air.

Note

1) Please avoid any heavy thing placed on the switch.

2) Make sure the power is off before unplugging the power

adapter.

2.2 Power On

The TL-SF1008P Switch can be used with DC power supply.

Powering on the Switch, it will automatically initialize and its LED

indicators will respond as follows:

1) All the LED indicators except PoE ports LED will light syn-

chronously at first, then all of them included Link/Act LED

(green), 100Mbps LED (green) and PoE MAX LED (red), will

light off at once, which indicates the system initialized well.

2) The Power indicator will light all the time.

Note

If the LED indicators don’t respond as described above, please

check the power supply and its connection.

Chapter 3. Identifying External Components

This Chapter describes the front panel, rear panel and LED indi-

cators of the Switch.

3.1 Front Panel

Figure 3-1 TL-SF1008P Switch Front Panel

The Switch’s LEDs are located on the front panel.
