Trane PIC Manuale del proprietario

Installation

Operation

Maintenance/

Programming

BAS-SVX08D-E4

Protocol interface controller

Modbus solution for Trane

chillers and rooftops

Introduction

BAS-SVX08D-E4

Foreword

These Installation Operation and Maintenance instructions are given as a

guide to good practice in the installation, start-up, operation and periodic

maintenance by the user of the Protocol Interface Controller (PIC).They do

not contain the full service procedures necessary for the continued

successful operation of this equipment.The services of a qualified service

technician should be employed, through the medium of a maintenance

contract with a reputable service company.

Warranty

Warranty is based on the general terms and conditions of the constructor.

The warranty is void if the equipment is modified or repaired without the

written approval of the constructor, if the operating limits are exceeded,

or if the control system or the electrical wiring is modified. Damage due to

misuse, lack of maintenance, or failure to comply with the manufacturer's

instructions, is not covered by the warranty obligation. If the user does not

conform to the instructions given in this document, it may entail

cancellation of warranty and liabilities by the constructor.

Reception

On arrival, inspect the unit before signing the delivery note. Specify any

damage on the delivery note, and send a registered letter of protest to the

last carrier of the goods within 72 hours of delivery. Notify the local Trane

sales office at the same time.The unit should be totally inspected within 7

days of delivery. If any concealed damage is discovered, send a registered

letter of protest to the carrier within 7 days of delivery and notify the local

Trane sales office.

Important notice: No shipping claims will be accepted byTrane if the above

mentioned procedure is not respected.

Note: More stringent national rules may apply in some countries. For more

information, refer to the general sales conditions of your localTrane sales

office.

General Information

Cautions appear at appropriate places in this instruction manual.Your

personal safety and the proper operation of this machine require that you

follow them carefully.The constructor assumes no liability for installations

or servicing performed by unqualified personnel.

Contents
3BAS-SVX08D-E4
Introduction 2
Foreword 2
Warranty 2
Reception 2
General information 2
Product description 5
General presentation 5
Supported equipment 6
Parts list 6
Installation 7
Mounting and wiring 7
Connectors layout 10
Wiring PIC withTrane equipment 12
Wiring PIC with RTAC/ CGAN / CXAN / CGCL / CCUH / CCUN /
CGWH / CGWN / RAUL / RTHD / CVGF / CGAM / CXAM / RTWD /
RTUD chillers (CH530 controller) 12
Wiring PIC with CGAN/CXAN chillers (CH532 controller) 12
Wiring PIC with RTAA/RTAB/RTXA/RTAD/RTWB/RTRA/
RTUB chillers (UCM CLD controller with LCI-C interface) 13
Wiring PIC with CGAH/CXAH/CGCL/CCUH/CGWH/RAUL chillers
(SMM controller) 13
Wiring PIC with RTAA/RTAB/RTXA/RTAD/RTWB/RTRA/RTUB chillers
(UCM CLD controller with CSR interface) 14
Wiring PIC with CVGE/CVAE/RTHC chillers (UCP2 controller)
Wiring PIC with WSD/WSH/WKD/WKH/TSD/TSH/TKD/TKH/YSD/YSH/
YKD/YKH rooftop (Reliatel™ controller) 15
Wiring PIC with WSD/WSH/WKD/WKH/TCD/TCH/TED/TEH/TSD/TSH/TKD/
TKH/YCD/YCH/YSD/YSH/YKD/YKH rooftop (UCP controller) 15
Wiring PIC with Modbus Building Management System 16
Wiring PIC with RS-232 Modbus BMS 16
Wiring PIC with RS-485 Modbus BMS 16
Diagnostic tool installation 18
Software installation 18
Diagnostic cable 21

Contents
BAS-SVX08D-E44
Operation 22
Trane equipment data point list 22
Data point list for CVGF / CVHE (Tracer CH530) 22
Data point list for RTAC (Tracer CH530) 23
Data point list for RTHD (Tracer CH530) 25
Data point list for RTWD / RTUD (Tracer CH530) 26
Data point list for CGAN / CXAN / CGCL / CCUH / CCUN /
CGWH / CGWN / RAUL / CGAM / CXAM (Tracer CH530) 27
Data point list for CGAN/CXAN (Tracer CH532 V1.2) 28
Data point list for CGAN/CXAN (Tracer CH532 V2.0) 29
Data point list for RTAA/RTAB/RTXA/RTAD/RTWB/RTRA/RTUB
(UCM CLD + LCI-C interface) 30
Data point list for CGAH/CXAH/CGCL/CCUH/CGWH/RAUL (SMM) 31
Data point list for RTAA/RTAB/RTXA/RTAD/RTWB/RTRA/RTUB
(UCM CLD + CSR) 34
Data point list for CVGE/CVAE/RTHC chillers (UCP2 controller) 38
Data point list for Rooftops (UCPII / UCPIII and Reliatel controllers) 43
Modbus functions 47
Modbus configuration 47
Modbus parameters - SW3 47
Modbus slave address - SW4 48
Variable format 56
PIC andTrane equipment configuration 56
Configure the PIC connected to a LONTrane equipment 56
Configure the PIC connected to a Comm3Trane equipment 59
Configuration change 62
Maintenance 64
Diagnostic tool operation 64
PIC status 64
Trane equipment communication status 66
Modbus communication status 69
Modbus data point tables 71
Modbus traffic 73
Appendix 77

Product description

5BAS-SVX08D-E4

General presentation

The PIC is the gateway to allow communication between a TRANE

equipment and a BMS (Building Management Systems) vendor through the

Modbus protocol over a RS232 or a RS-485 link.

The PIC handles Modbus RTU according to Reference Guide: Modicon

PI-MBUS-300 Rev. D

Modicon®is a trademark of Modicon, Inc.

Jbus®is a trademark of April.

Modbus/Jbus Considerations:

Jbus is an extension of Modbus. Jbus supports more functions than

Modbus.

• Functions supported by both Modbus and Jbus:

1, 2, 3, 4, 5, 6, 15 and 16

• Functions supported by Jbus but not supported by Modbus:

7, 8, 11, 12 and 13

Product description

BAS-SVX08D-E46

Supported equipment

Outdoor Chillers

Helical rotary compressor RTAA / RTAB / RTAC / RTAD / RTXA

Scroll compressor CGAN / CXAN / CGAH / CXAH / RAUL /

CGAM / CXAM

Centrifugal compressor CVAE

Indoor Chillers

Helical rotary compressor RTWB / RTUB / RTRA / RTHC / RTHD /

RTWD / RTUD

Scroll compressor CGWH / CGWN / CGCL / CCUH / CCUN

Centrifugal compressor CVGE / CVGF

Absorption ABSC / ABSD / ABTF

Rooftops

Reversible WSD / WSH / WKD / WKH

Cooling-only TCD /TCH /TED /TEH /TSD /TSH /TKD / TKH

Gas-fired YCD / YCH / YSD /YSH /YKD /YKH

Parts list

Table 1 - Parts list

Communication Boards ControllerType Equipment Drawing # Part Number

CH530 LCI-C Tracer CH530 RTAC Public Extension MOD 0160E

RTAC Chiller Profile MOD 0164E

RTHD MOD 0161E

SCROLL MOD 0162E

Centrifugal MOD 0163E

RTWD, RTUD MOD 0186E

RTAC, RTHD, CGAN..

(hardware only) X13650845-002 MOD 01216

CH532 LCI-C V1.2 Tracer CH532 V1.2 CGAN/CXAN X 13740189-001 BRD0079E

CH532 LCI-C V2.0 Tracer CH532 V2.0, V2.3

and greater CGAN/CXAN X 13740189-002 BRD0084E

UCM CLD LCI-C UCM CLD RTAA, RTAD, RTWB X 13651074-001 KIT 12182

UCM CLD CSR UCM CLD RTAA, RTAD, RTWB X 13650364-004 MOD01422

TCI4-Comm3 UCP2 RTHC X13650618-002 MOD00720

TCI4-Comm3 UCP2 CVGE X13650460-011 MOD01396

TCI Comm3-Comm4 Reliatel Rooftop X01650524-001 BRD03029

TCI Comm3-Comm4 UCP II / III Rooftop X13650464-004 BRD00917

Installation

7BAS-SVX08D-E4

Mounting and wiring

PIC mounting recommendations

To mount the PIC device:

• Select a location near the controlled equipment to reduce wiring costs

and EMC disturbance risks.

• Verify that the location conforms to the specifications below.

• Secure the controller to a 35 mm DIN rail (Use only 10/10 mm thickness

sheet) or directly mount the PIC using four M3 screws (not supplied).

1 = Screw holes

2 = DIN rail

Table 2 - PIC specifications

Board dimensions 95 mm height x 132 mm width x 60 mm depth

Minimum clearances Front 100 mm

Each side 25 mm

Top and bottom 100 mm

Operating environment Temperature: from -40° to 70°C

Relative Humidity: from 5% to 95% non-condensing

Dust protection: pollution level 1

Storage environment Temperature: from -50° to 85°C

Relative Humidity: from 5% to 95% non-condensing

Protocol Interface

Controller

MODBUS

TxRx RS485RS232 A Ref BRJ-45 Resistor

DIAG

USB

COMM3

1TxRx2 SHD

Service

PIN LON BABA 24VGND

CONFIGURATION

SW1 SW2 SW3 SW4 Rx

Serv. 0VON 24V Imax=0.5A

Installation

BAS-SVX08D-E48

PIC Power Supply recommendations

The PIC device is powered by 24 VAC/VDC +6V/-12V power supply. A 3-wire

quickconnect terminal (TB3) is provided for power supply connection to the

board.

To ensure the controller will operate properly, verify that the power supply

circuit is in compliance with the following circuit requirements:

To keep the PIC in accordance with the Separated Extra Low Voltage (SELV)

circuit, the transformer 'T' shall be in accordance with EN / IEC 61558-2-6.

Table 3 - Power supply recommendations

CAUTION! PIC power supply circuit MUST NOT be connected to the ground

as shown in the above illustration.The non-respect of this requirement will

damage the PIC.

CAUTION! If local electrical regulations do not allow the recommended

power supply wiring, contact your local Trane Sales Office for an adequate

solution to comply with local electrical regulations.

Note:This wiring is in accordance with IEC 60364-4-41 and national

standards which incorporate the same requirements.

PIC

24V

GND

F : 0.5A / 250V / M

24V

Installation

9BAS-SVX08D-E4

Power supply recommendations

Power

requirements

24 VAC/VDC +6V / -12V

50 or 60 Hz

0.5 A maximum

Protection

The PIC device must receive power from a dedicated circuit which is

connected to a dedicated isolation screened transformer. The circuit

must be protected by a 0.5 A / 250V / Medium time lag circuit

breaker/fuse located next to it.

Recommended

wire

The AC/DC-power wiring requires three-wire cable.

The recommended wire is 1.5mm² (16 AWG) copper wire.

Standards

The AC/DC-power wiring complies with IEC or EN 60364-4-41 and

2006/95/EEC for electrical safety.

For compliance with 2006/108/EEC and 89/336/EEC European directive

for electromagnetic compatibility:

- EN 55022 level B

- EN 61000-3-2

- EN 61000-4-2

- EN 61000-4-4

Ground

Connection

The ground connection of the PIC (GND connector) MUST BE

connected to the building earth to prevent electromagnetic

compatibility risks.

Installation

BAS-SVX08D-E410

Connectors layout

Protocol Interface

Controller

MODBUS

TxRx RS485RS232 A Ref BRJ-45 Resistor

DIAG

USB

COMM3

1TxRx2 SHD

Service

PIN LON BABA 24VGND

CONFIGURATION

SW1 SW2 SW3 SW4 Rx

Serv. 0VON 24V Imax=0.5A

1 2 3 4

Indice

Altri manuali Trane Controllori

Trane

Trane Tracer UC400 Istruzioni per l'installazione e il funzionamento

Trane

Trane mP30 Manuale del proprietario

Trane

Trane Tracer UC400 Istruzioni per l'installazione e il funzionamento

Trane

Trane Tracer AH540 Manuale di istruzioni

Trane

Trane Tracer CH535 Manuale utente

Trane

Trane OXBOX JAYLOAM001 Manuale utente

Trane

Trane Symbio 210 Istruzioni per l'installazione e il funzionamento

Trane

Trane Tracer MP580 Istruzioni operative

Trane

Trane Tracer AH540 Guida all'installazione

Trane

Trane TCONT 800 Series Istruzioni per l'installazione e il funzionamento

Trane

Trane Thermo King CANAIRE Manuale utente

Trane

Trane CVHE Manuale utente

Trane

Trane Tracer ZN511 Manuale del proprietario

Trane

Trane 700 Manuale per l'uso e la cura

Trane

Trane Tracer ZN521 Manuale del proprietario

Trane

Trane Tracer AH541 Manuale di istruzioni

Trane

Trane TCONT 800 Series Guida rapida alla configurazione

Trane

Trane Tracer UC400 Manuale utente

Trane

Trane ZN. LonWorks control Manuale utente

Trane

Trane Tracer ZN524 Guida all'installazione

Trane

Trane TCONTCCMHCM04A Manuale utente

Trane

Trane 700 Manuale utente

Trane

Trane Symbio 210 Istruzioni per l'installazione e il funzionamento

Trane

Trane CONTH01AAUTOA Istruzioni per il montaggio

Manuali Controllori popolari di altre marche

Digiplex

Digiplex DGP-848 Istruzioni operative

YASKAWA

YASKAWA SGM series Manuale utente

Sinope

Sinope Calypso RM3500ZB Manuale utente

Isimet

Isimet DLA Series Style 2 Manuale di installazione

LSIS

LSIS sv-ip5a Manuale utente

Rockwell Automation

Rockwell Automation 1769-L31 Manuale utente

Airflow

Airflow Uno hab Manuale utente

ABB

ABB ACS580-01 drives Manuale utente

Panasonic

Panasonic GM1 Series Manuale utente

Emerson

Emerson SW93 Manuale utente

AutoAqua

AutoAqua Smart ATO micro SATO-120P Manuale utente

Panasonic

Panasonic FP? Positioning Unit RTEX Manuale utente

Samson

Samson Type 5824 Manuale di servizio

Alpha IP

Alpha IP MIOB 21001 Manuale utente

Siemens

Siemens OpenAir GMA 1 Series Manuale utente

Surecom

Surecom SR-629 Manuale utente

Fishman

Fishman TriplePlay Manuale utente

Regulus

Regulus SRS1 T Manuale utente
