TrekStor i.Beat ice 1GB Manuale utente
0101
Welcome to the digital world provided by TreKstor
Thank you for purchasing TreKstor i.Beat ice
This user manual is provided to improve customer convenience in using the product.
http://www.trekstore.de
Customer inquiries on TreKstor and the product are fully supported if
related information is available.
Continuous product improvements are available through firmware and software upgrades.
Register as a customer to receive online service, new product information,
firmware upgrades and other matters via email.
Greetings
Product Characteristics
Charging with a USB Cable
Charging with a USB Adaptor
Re-chargeable Battery Maintenance
Product Package
List of Items Included
Optional Items
Device Configuration
Connecting to a Computer (PC)
Installing thei.Beat iceSoftware
Connecting to a PC
Using USB
Removing thei.Beat iceSafely
Using Windows Media Player
Formatting thei.Beat ice
Using thei.Beat ice
OLED Screen By Each Mode
Table of Contents
02 03
7
8
8
8
9
9
9
10
11
11 ~ 15
16
16 ~ 17
17
19 ~ 21
22
23
23 ~ 24
Safety Precautions
Button Description
Basic Function
Listening to Music
Switching To VOICE Mode
Switching To FM Mode
Switching To LINE-IN Mode
Menu Setting
Upgrading Firmware
Product Specification
Troubleshooting
Usage Cautions
04 05
Protect the product
from high humidity,
dirt and dust, and
direct sunlight.
Do not let the product come
into contact with chemicals
such as benzene or paint
thinner etc.
Be aware that if you
fall with the player in
your pocket it may
cause injuries.
Be aware that the neck strap
may break if too much force is
applied to the strap, or when
exercising vigorously. If this
occurs the player may fall and
break or cause injuries.
When using the neck
strap take care that
the strap does not get
stuck in doors,
elevators, etc.
Do not try to
dismantle, repair, or
modify the product.
Avoid places with high or low
temperature and high humidity.
Do not apply
excessive force to or
place any heavy
object on the
product.
Do not press two buttons
simultaneously, or use
excessive force.
25 ~ 28
29
30 ~ 31
32
33 ~ 35
36
36 ~ 44
45
46
47
48
0706
- Multi-Codec Player
Supports MP3, WMA, ASF (Music files only), ADPCM format digital audio files.
It also supports all bandwidths of MP3 and WMA.
- Firmware Upgrade
Supports continuous functional updates, modification, and upgrades for the player.
- Lyrics Support
Provides a Lyrics download and edit function.
- Supports USB2.0 High Speed
Supports USB 2.0 interface enabling high-speed file transfer.
- 3D Sound Effect
Supports dynamic sound effects and 3D sound through SRS WOW
- Automatic folder search, Playback type function select
Playback list function enables dynamic methods for playing
- Automatic FM frequency detection
- 2 color OLED
- Supports lyrics display and ID3 Tag
- Windows Media Player Plug-in support
- GUI (Graphic User Interface) support
Supports GUI and various functions (sleep, repeat)
- Supports user EQ
- Multilingual support
- Multiple language support (Unicode 2.0 Standard)
Product CharacteristicsNote for Battery and Charger
Make sure to
charge the
battery for use
after purchase
of the product.
(See pages
08) Never disassemble the
battery or charger.
Store the battery and
charger below 45℃.
(i.e. 113℉)
Charge the battery at the
ambient temperature of 0℃to
45℃.
Keep the
charger away
from water.
Keep your hands off the inside
of the charger.
Please do not
open the case
of the charger
Use the charger
indoors only.
08 09
Use a USB cable to connect the i.Beat iceto a PC and leave it connected for 90~120
minutes to completely
charge the device. The LED turns on during charging and turns off again when charging is
complete.
Make sure to disconnect the device from the PC after charging.
Charging with a USB Adaptor
Connect thei.Beat iceto the adaptor and leave it for 90~120 minutes to charge the device
completely.
Please disconnect after charging.
* Caution
The Adaptor output must be 5V, 500mA~2A.
Fire, explosion, or leakage may be caused if output differs from the
specified values.
Re-chargeable Battery Maintenance (New Information)
- The product has a built-in re-chargeable battery. Keep the product indoors.
- Dismantling the product and damaging the re-chargeable battery, or placing it near a heater may cause an
explosion. Allowing any metal to make contact across the battery terminals may cause a short circuit and explosion.
- Charge the device before putting the product away for a long time. Recharge the device fully before re-use.
- Re-chargeable batteries are consumable items, and their usable life shortens with time.
- Keep the product away from children and animals since there is a danger of explosion if mishandled.
Charging with a USB Cable
List of items included
i.Beat iceDevice Earphones Installation CD
User Manual USB Cable Neck Strap
Product Package
10 11
1)i.Beat ice Device Configuration
Device Configuration
Note
Installation of software is required for Windows 98 before using the product with
the USB drive. Update Windows when the USB drive does not operate in
Windows 98/ME/2000/XP systems.
Windows Update
Click on the [Start]->[Windows Update] to update Windows to the latest version.
Installing i.Beat ice Software
Insert the installation CD. The TrekStor menu will open.
Select "Driver/Tools" and the following screen appears.
Connecting to a Computer (PC)
LINE-IN Terminal
USB Terminal
OLED
Playback Button
Record Button
Lock Button
Reset
Mode Button
Search(-) Button
Search(+) Button Menu Button
Volume(-) Volume(+)
Microphone
Earphone Terminal
12 13
Clicking on the Next button brings up the user terms as shown below.
Click on the Yes button if the user terms
are acceptable.
Designate the folder to install the program.
Click on Next.
Click on Finish when installation is complete.
* Caution
The computer has to be re-started
after installation. (For Windows 98/ME)
14 15
Input the desired program name in
the program list. Click on Next.
Please wait while the program installs.
Use the‘removable disk’like a floppy disk. Maximize the use of the i.Beat ice folder function as shown above by creating a number of folders,
and place music files in the desired folders. Note that creating a“Data”folder and putting data files in this folder may speed up booting time.
FM, LINE-IN, and VOICE folders are automatically generated and store FM, Line-IN, and microphone input files respectively.
Removing the i.Beat ice Safely
For Windows ME/2000/XP Users
Select and click on“Remove USB Drive”in the System Tray. A message appears on the screen informing the user that it has been safely
removed. Then remove the i.Beat ice.
16 17
Minimum PC Requirements
- Pentium 133MHz or above - Windows 98/ME/2000/XP
- 20MB HDD space or more - CD-ROM Drive - USB port
Using USB
Open the i.Beat ice’s protective USB cover and
connect the cable.
The i.Beat ice is identified by the PC as a
removable disk when connected, and may be
used like a floppy disk.
Connecting to a PC
Select the Device tab.
Select Removable Disk and then click on the Properties button.
18 19
For Windows 98 Users
Close all i.Beat ice related windows.
Data is still in transfer if the blinks on the LCD screen. Remove the SSF-9621/965 when
data transfer is complete and the no longer blinks.
Using Windows Media Player
The i.Beat ice supports Media Player Plug-in enabling it to directly convert music or download
from Media Player.(Applicable for Media Player version 9)
Setting Option
The setting needs to be changed in order to save MP3s etc. in WMA format
Connect the i.Beat ice to a PC and run Media Player.
Select the Options menu in Tools.
