TrekStor i.Beat joy 2.0 Manuale utente
TrekStor
Contents
1 Introduction 2
1.1 Box contents . . . . . . . . . . . . . . . . . . . . . . . . 2
1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 TrekStor i.Beat joy 2.0 controls . . . . . . . . . . . . . . 4
2 Functions of the TrekStor i.Beat joy 2.0 5
2.1 Note ............................ 5
2.2 Basic functions . . . . . . . . . . . . . . . . . . . . . . 5
2.2.1 Switching on and off your TrekStor i.Beat joy 2.0 5
2.2.2 Locking the keys . . . . . . . . . . . . . . . . . . 6
2.2.3 Play/Pause . . . . . . . . . . . . . . . . . . . . 6
2.2.4 Fast forwarding/rewinding/changing tracks . . . 6
2.2.5 Adjusting the volume . . . . . . . . . . . . . . . 7
2.2.6 Folder navigation . . . . . . . . . . . . . . . . . 7
Deleting files . . . . . . . . . . . . . . . . . . . . 8
2.2.7 Repeat A-B . . . . . . . . . . . . . . . . . . . . 8
2.3 Main menu . . . . . . . . . . . . . . . . . . . . . . . . . 8
I
Contents
2.3.1 Music Player . . . . . . . . . . . . . . . . . . . . 9
2.3.2 M3U-Playlist . . . . . . . . . . . . . . . . . . . . 9
2.3.3 Recorder . . . . . . . . . . . . . . . . . . . . . . 10
Recording using the built-in microphone . . . . . 10
Recording using the line-in jack . . . . . . . . . . 11
2.3.4 Music Player setup . . . . . . . . . . . . . . . . 11
Equalizer Setup . . . . . . . . . . . . . . . . . . 11
Play mode . . . . . . . . . . . . . . . . . . . . . 12
2.3.5 Record Setup . . . . . . . . . . . . . . . . . . . 12
Source....................... 12
Setting up microphone recording . . . . . . . . . 13
Setting up line-in recording . . . . . . . . . . . . 13
2.3.6 Setting Menu . . . . . . . . . . . . . . . . . . . 13
3 Connecting to your PC 15
3.1 Minimum requirements . . . . . . . . . . . . . . . . . . 15
3.2 Windows 98(SE) installation guide . . . . . . . . . . . . 15
3.3 Windows ME/2000/XP installation guide . . . . . . . . 16
3.4 Exchanging data . . . . . . . . . . . . . . . . . . . . . . 17
3.5 Creating MP3 files . . . . . . . . . . . . . . . . . . . . . 17
3.6 Logging off from your computer . . . . . . . . . . . . . 19
4 Additional Information 20
4.1 Updating the firmware for your TrekStor i.Beat joy 2.0 . 20
II TrekStor
Contents
4.2 FAQ ............................ 20
A Instructions and Warranty 23
A.1 Support and contact . . . . . . . . . . . . . . . . . . . . 23
A.2 Liability . . . . . . . . . . . . . . . . . . . . . . . . . . 23
A.3 Safety information . . . . . . . . . . . . . . . . . . . . . 24
A.4 Instructions for use . . . . . . . . . . . . . . . . . . . . 24
A.5 Trademarks . . . . . . . . . . . . . . . . . . . . . . . . 25
A.6 Battery disposal . . . . . . . . . . . . . . . . . . . . . . 25
A.7 Copyright . . . . . . . . . . . . . . . . . . . . . . . . . 26
A.8 Warranty terms and conditions . . . . . . . . . . . . . . 26
TrekStor i.Beat joy 2.0 1
1 Introduction
Congratulations on your purchase of the TrekStor i.Beat joy 2.0 . We are
sure you will enjoy countless hours of listening pleasure. The TrekStor
i.Beat joy 2.0 is a high-quality MP3 player with numerous functions for
enjoying music at home or on the go. Please read the instructions in this
manual before using the player.
1.1 Box contents
The follow components are included in the box:
1. TrekStor i.Beat joy 2.0
2. Earphones
3. AAA battery
4. Driver CD with user’s manual
5. USB cable
2
1.2 Features
1.2 Features
Large LCD
M3U playlist function
Line-in recording
Dictation function
Folder navigation
And much more
TrekStor i.Beat joy 2.0 3
1 Introduction
1.3 TrekStor i.Beat joy 2.0 controls
A USB connector H Volume ’V-’ button
B’Hold’ button (key lock) I’|
JJ
’Rewind button
C’M’ button (menu) (Left)
D’A-B’ button / Recorder J LCD
E Volume ’V+’ button K Headphone jack
F’
II
|’Fast forward button (Right) L Microphone
G’
I
q
’button (Play/Pause/OK/On/Off) M Battery cover
Note: The headphone jack also serves as a line-in jack for recording from
external devices such as CD players, stereos, etc.
4TrekStor
2 Functions of the TrekStor i.Beat joy 2.0
2.1 Note
The TrekStor i.Beat joy 2.0 has only a few buttons to make operation as
easy as possible. There are more functions than buttons, however. How
long you hold down a button determines which function you want to be
carried out.
2.2 Basic functions
2.2.1 Switching on and off your TrekStor i.Beat joy 2.0
To switch on your TrekStor i.Beat joy 2.0 , hold down the ’
I
q
’button for
three seconds.
Note: Make sure the key lock ( ’Hold’ button) is switched
off. If the key lock has been switched off, a corresponding
5
2 Functions of the TrekStor i.Beat joy 2.0
message appears, and the TrekStor i.Beat joy 2.0 switches
off.
To switch off your TrekStor i.Beat joy 2.0 , hold down the ’
I
q
’button for
at least two seconds. The TrekStor i.Beat joy 2.0 switches off automati-
cally.
2.2.2 Locking the keys
To enable the key lock, push the ’Hold’ button to the right. The key lock
icon appears in the upper right of the display next to the battery icon.
2.2.3 Play/Pause
When you switch on your TrekStor i.Beat joy 2.0 , it is in ’Music’ play
mode. To play a track, press the ’
I
q
’button. Press the ’
I
q
’button while
the track is playing to pause the track. Press ’
I
q
’to continue resume.
2.2.4 Fast forwarding/rewinding/changing tracks
Press and hold ’|
JJ
’or ’
II
|’to fast forward or rewind within a track. Use
the ’
II
|’button to fast forward and the ’|
JJ
’button to rewind in the
track.
6TrekStor
