TRENDnet TBW-104UB Manuale utente
TBW-104UB
Quick Installation Guide
Table of Contents
(Version 03.21.2007)
English ......................................................................................................
Troubleshooting .........................................................................................
1
1
2
5
7
1. Before You Start
2. How to Install .....................................................................................
3. Configuring the Bluetooth Adapter ....................................................
................................................................................
System Requirements
1. Before You Start
English
1
Package Contents
TBW-104UB
Quick Installation Guide
Utility& Driver CD-ROM
CD-ROM drive
Computer With An Available USB 1.1 or 2.0 Port
CPU: Pentium 300MHz or Above
Memory: 256 MB or Above
Hard Drive Space: 50MB or Above
Windows 2000/XP/Vista
Application
Note: Do not insert the TBW-104UB USB adapter until instructed to do so.
2. How to Install
English
2
1. Insert the Utility & Driver
CD-ROM into your CD-ROM drive
and click Install Utility.
2. Select Language from the drop
down menu. Click OK
4. Select I accept the terms in the
license agreement. Click Next
3. Click Next.
5. Follow the InstallShield Wizard
instructions and then click Finish.
6. Click Yes to restart the computer.
(Windows 2000 only)
7. Connect the TBW-104UB into the
computer's USB port.
English
3
Drivers for Window Vista and 2000 will install automatically. Proceed to
section 3. For Windows XP, continue on to step 8.
English
4
10. Click Finish.
Your installation is now complete.
For detailed information regarding the TBW-104UB configuration and
advanced settings, please refer to the User's Guide included on the Utility &
Driver CD-ROM or TRENDnet's website at www.trendnet.com
8. Select No, not this time and then
click Next.
9. Select Install the software
automatically (Recommended)
and then click Next.
Windows XP
English
5
3. Configuring the Bluetooth Adapter
1. Double-click the Bluetooth icon on
your system tray.
4. Right click on your Bluetooth
device and select Pair Device.
5. Type in a Passkey (for example:
0000. Please consult your
Bluetooth device's manual for more
information) and then click OK.
Then put in the same Passkey on
your Bluetooth device.
3. Go to View -> Refresh Devices.
Note: Make sure your Bluetooth device is powered on and in pairing mode.
2. Click OK.
6. Double left-click on your Bluetooth
device to show the available
services.
Your configuration is now complete.
For detailed information regarding the TBW-104UB configuration and
advanced settings, please refer to the User's Guide included on the Utility &
Driver CD-ROM or TRENDnet's website at www.trendnet.com
English
6
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.TRENDnet.com/register
Thank you for choosing TRENDnet
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
Windows is unable to recognize my hardware. What should I do?
First, make sure your computer meets the minimum requirements as specified
in Section 1 of this quick installation guide. Second, you must install the Bluetooth utility
BEFORE you physically install your Bluetooth Adapter. Third, plug the adapter into a
different USB slot.
The Bluetooth software is unable to detect my Bluetooth-enabled device. What should I
do?
First, disable any software firewall programs such as ZoneAlarm or Norton Internet
Security. If your have Windows XP/Vista installed on your computer, make sure to disable
the built-in firewall. Second, make sure Bluetooth enabled device is powered on.
I cannot pair my Bluetooth enabled device to the TBW-104UB USB Adapter. What
should I do?
First, make sure that Bluetooth device is powered on. Second, make sure that your
Bluetooth enabled device is in pairing mode. Third, make sure to put in the same Passkey
on both devices.
I am not receiving 3Mbps data rate through the adapter. What should I do?
In order to get the full data rate, your Bluetooth device must support Bluetooth v2.0 with
Enhanced Data Rate (EDR).
If you still encounter problems or have any questions regarding the TBW-104UB, please refer to
the User's Guide included on the Utility & Driver CD-ROM or contact TRENDnet's Technical
Support Department.
7
Troubleshooting
Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.
