TRENDnet TBW-105UB Manuale utente

TBW-105UB

Quick Installation Guide

Table of Contents

(Version 08.28.2006)

English ......................................................................................................

Troubleshooting .........................................................................................

1. Before You Start

2. How to Install .....................................................................................

3. Configuring the Bluetooth Adapter ....................................................

................................................................................

System Requirements

1. Before You Start

English

Package Content

TBW-105UB

Quick Installation Guide

Utility & Driver CD-ROM

CD-ROM drive

Computer With An Available USB 1.1 or 2.0 Port

CPU: Pentium 300MHz or Above

Memory: 256 MB or Above

Hard Drive Space: 50MB or Above

Windows 2000/XP

Application

* Backwards compatible with USB 1.1 at 12Mbps

PDA

Bluetooth

Headset Printer

(TBW-105UB)

Compact Bluetooth USB 2.0 Adapter

Cell Phone

Note: Do not insert the TBW-105UB USB adapter until instructed to do so.

Note: For Windows 98SE and ME, refer to the User's Guide.

2. How to Install

English

1. Insert the Utility & Driver

CD-ROM into your CD-ROM drive

and click Install Utility.

3. Select I accept the terms in the

license agreement. Click Next

2. Click Next.

4. Click OK.

6. Click Finish.

7. Click Yes (Windows 2000 only).

English

5. When you reach this screen,

connect the TBW-105UB into the

computer's USB port. Then click

OK.

Your installation is now complete.

For detailed information regarding the TBW-105UB configuration and

advanced settings, please refer to the User's Guide included on the Utility &

Driver CD-ROM or TRENDnet's website at www.trendnet.com

English

3. Configuring the Bluetooth Adapter

1. Double-click the Bluetooth icon on

your system tray.

4. When you reach this screen, click

Skip.

2. Click Next.

3. Click Next.

Note: Make sure your Bluetooth device is powered on and in pairing mode.

English

9. Type in a Bluetooth security

code (for example: 0000. Please

consult your Bluetooth device's

manual for more information) and

then click OK. Then put in the

same Bluetooth security code on

your Bluetooth device.

10. Double left-click on your

Bluetooth device to show the

available services.

Your configuration is now complete.

For detailed information regarding the TBW-105UB configuration and

advanced settings, please refer to the User's Guide included on the Utility &

Driver CD-ROM or TRENDnet's website at www.trendnet.com

6. Double-click the My Bluetooth

Places icon.

7. Click Bluetooth -> Search For

Devices.

8. Right click on your Bluetooth

device and then click Pair.

5. Click Finish.

Q1:

A1:

Q2:

A2:

Q3:

A3:

Q4:

A4:

Windows is unable to recognize my hardware. What should I do?

First, make sure your computer meets the minimum requirements as specified

in Section 1 of this Quick Installation Guide. Second, you must install the Bluetooth utility

BEFORE you physically install your Bluetooth Adapter. Third, plug the adapter into a

different USB slot.

The Bluetooth software is unable to detect my Bluetooth-enabled device. What should I

do?

First, disable any software firewall programs such as ZoneAlarm or Norton Internet

Security. If your have Windows XP installed on your computer, make sure to disable the

built-in XP firewall. Second, make sure your Bluetooth device is powered on.

I cannot pair my Bluetooth device to the TBW-105UB USB Adapter. What should I do?

First, make sure your Bluetooth device is powered on. Second, make sure that your

Bluetooth device is in pairing mode. Third, make sure to put in the same Security Code on

both devices.

I am not receiving 3Mbps data rate through the adapter. What should I do?

In order to get the full data rate, your Bluetooth device must support Bluetooth v2.0 with

Enhanced Data Rate (EDR)

If you still encounter problems or have any questions regarding the TBW-105UB, please refer to

the User's Guide included on the Utility & Driver CD-ROM or contact TRENDnet's Technical

Support Department.

Troubleshooting

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received. Including interference that may

cause undesired operation.

NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV

INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS

EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO

OPERATE THE EQUIPMENT.

Waste electrical and electronic products must not

be disposed of with household waste. Please

recycle where facilities exist. Check with you Local

Authority or Retailer for recycling advice.

ADVERTENCIA

En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de

alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al

mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador

de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria

existente en el pais o zona de instalación.

Product Warranty Registration

Please take a moment to register your product online.

Go to TRENDnet’s website at http://www.trendnet.com

TRENDnet Technical Support

US Canada

24/7 Tech Support

Toll Free Telephone: 1(866) 845-3673

Europe (Germany France Italy Spain Switzerland UK)

English/Espanol - 24/7

Francais/Deutsch - 11am-8pm, Monday - Friday MET

English/Espanol - 24/7

Francais/Deutsch - 11am-8pm, Monday - Friday MET

Worldwide

Telephone: +(31) (0) 20 504 05 35

Toll Free Telephone: +00800 60 76 76 67

. . . . .

20675 Manhattan Place

Torrance, CA 90501

USA
