TRENDnet TE-PCIW Manuale utente

he TE-PCI/W is a jumperless, plug and play, 32-bit Ethernet

adapter featuring half/full duplex operations. The TE-PCI/W

utilizes the latest PCI bus technology to process network packets

with minimal CPU utilization. The TE-PCI/W is recommended for

workstations in a PC client/server environment.

Taking advantage of 32-bit bus width and speed up to 33MHz,

the TE-PCI/W is superior to all ISA adapters. It is equipped with

both BNC and RJ-45 connectors, includes drivers for every

popular network operating system. The TE-PCI/W is also

NE2000 compatible there it can be used with virtually all existing

network operating systems. The TE-PCI/W is backed by

TRENDware's 5 Year Parts and Labor Warranty.

TE-PCIW

High Performance Plug-n-Play Ethernet Adapter

Compliant with IEEE 802.3 10Base-2 and 10Base-T

Ethernet standards

Full-duplex operation at 10Base-T connection

Compliant with PCI Local Bus Specification 2.0

Simply insert the card and it will be automatically configured

in a PnP system

Supports PCI Bus Slave mode

Supports Multi-thread Operation

Supports Virtual Memory

NE2000 Compatible

Auto-sensing connector in use

On-board socket for optional Boot ROM

External LED Indicators for troubleshooting (LINK and

TRAFFIC)

10Mbps (Half duplex)/20Mbps (Full duplex) Transfer Rate

5 Year Warranty

FEATURES

TE-PCIW (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

SPECIFICATIONS

TE-PCIW

High Performance Plug-n-Play Ethernet Adapter

TE-PCIW

High Performance Plug-n-Play Ethernet Adapter

Standards:

IEEE 802.3 10Base-2 and 10Base-T

On-board Connector:

RJ-45 and BNC

Data Bus Supported:

32-bit, PCI Local Bus Specification 2.0

IRQ’s Supported:

Assigned by the BIOS to a free IRQ (interrupt)

number

I/O Base Address:

Assigned by the BIOS to a free I/O address block

RAM Buffer:

16Kb

Boot ROM Size:

8Kb, 16Kb, and 32Kb

•

Dimensions:

5.20" x 3.27"

FCC Compliance:

FCC Class B

Power Consumption:

430mA at 5V

Operating Temperature:

0° to 55°C

Operating Humidity:

10 to 90%, non-condensing

•

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

ORDERING INFORMATIONORDERING INFORMATION

TRENDnet

TRENDware, USA

TE-PCI

32-bit PCI Plug-n-Play Ethernet Adapter

with BNC + RJ-45 Connectors

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com
