TRENDnet TEW-664UB Manuale utente

The 300Mbps Dual Band Wireless N USB Adapter (model TEW-664UB)

automatically connects your laptop or desktop computer wirelessly with

supercharged speed and reliability to a 2.4GHz and 5GHz wireless

network. Experience up to 12x the speed and 4x the coverage of a wireless

g connection*. Dual Band wireless n technology uses additional wireless

channels, reduces wireless interference and optimizes performance in the

most challenging environments.

Setup is a breeze with Wi-Fi Protected Setup technology. Advanced

wireless encryption protects your valuable data. The latest in MIMO

antenna technology ensures the fastest communication speeds that

wireless n technology provides. Stream HD media, download files, play

games and talk online with 300Mbps dual band wireless n technology.

** Maximum wireless signal rates are referenced from IEEE 802.11

theoretical specifications. Actual data throughput and coverage will cary

depending on interference, network traffic, building materials and other

conditions.

TEW-664UB(V1.0R)

TEW-664UB

rev:01.20.2009

• Wi-Fi compliant with IEEE 802.11n standard

• Backwards compatible with IEEE 802.11g, IEEE 802.11b and IEEE 802.11a devices

• Supports Ad-Hoc (Client-Client) and Infrastructure (AP-Client) Mode

• Supports Multiple Input Multiple Output (MIMO) technology

• Maximum reliability, throughput and connectivity with automatic data rate switching

• Supports 64/128-bit WEP, WPA/WPA2 and WPA-PSK/WPA2-PSK

• Low interference and high susceptibility optimize performance

• Wi-Fi Multimedia (WMM) Quality of Service (QoS) supported

• Compatible with Windows 2000/XP/Vista and Mac OS X 10.3/4/5 operating systems

• Easy user setup and intuitive diagnostics utilities

• Coverage of up to 50 meters indoor, 100 meters outdoor *

• 3-year limited warranty

FEATURES

wireless

300Mbps Dual Band Wireless N USB Adapter

Supported OS

Dimensions (LxWxH)

Weight

Humidity

Channel

• IEEE 802.11a, IEEE 802.11b, IEEE 802.11g and IEEE 802.11n (draft 2.0)

• Windows 2000/XP(32/64-bit)/Vista (32/64-bit)

• 802.11b: 11Mbps, 5.5Mbps, 2Mbps, and 1Mbps

• 80 x 27 x 12mm (3.1 x 1 x 0.5in)

• 20g (0.7oz)

• 802.11a: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps

• 802.11a: -69dBm at 300Mbps

• 802.11b/g/n: 1~11 (FCC), 1~13 (ETSI)

• 802.11a: 36, 40, 44, 48, 149, 153, 157, 161, 165 (FCC), 36, 40, 44, 48 (ETSI)

Encryption

Interface

Hardware

SPECIFICATIONS

• USB 2.0

LED Indicator

• Receive mode: 300mA (max) ; Transmit mode : 450mA (max)

Power Consumption

• 64/128-bit WEP (Hex & ASCII), WPA/WPA2 (TKIP/AES), WPA-PSK/WPA2-PSK

• 802.11n: up to 300Mbps

TEW-664UB(V1.0R)

300Mbps Dual Band Wireless N USB Adapter

• Activity

Standards

Temperature • Operating: 0° ~ 40° C (32° ~ 104° F); Storage: -10° ~ 65° C (14° ~ 149° F)

• FCC, CE

• 802.11n: 2.412 ~ 2.484 GHz

• 5% ~ 95% max (non-condensing)

Certification

Frequency

Data Rate (auto fallback)

• 802.11g: 54Mbps, 48Mbps, 36Mbps, 24Mbps, 18Mbps, 12Mbps, 9Mbps and 6Mbps

Output Power • 802.11a: 10dBm (typical)

• 802.11b: 16dBm (typical)

• 802.11n: 13dBm (typical)

Receiving Sensitivity • 802.11b: -86dBm at 11Mbps

• 802.11a: -70dBm at 54Mbps

• Built-in 2 on board antennas

Antenna

Wireless

• 802.11a: 5.150GHz ~ 5.350GHz / 5.725GHz ~ 5.825GHz (FCC)

5.150GHz ~5.350GHz / 5.470GHz ~ 5.725GHz (ETSI)

• 802.11g: 13dBm (typical)

• 802.11g: -71dBm at 54Mbps

• 802.11n: -66dBm at 300Mbps

TEW-664UB

rev:01.20.2009

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

RELATED PRODUCTS

PACKAGE CONTENTS

• CD-ROM (Utility and Driver)

• TEW-664UB

• Multi-Language Quick Installation Guide

ORDERING INFORMATION

To Order Please Call:

1-888-326-6061

NETWORKING SOLUTIONS

TEW-670APB

TEW-672GR 300Mbps Dual Band Wireless N Gigabit Router

300Mbps Dual Band Wireless N Access Point

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

• USB cable (14.5cm / 5.7in.)

TEW-664UB(V1.0R)

300Mbps Dual Band Wireless N USB Adapter

300Mbps Dual Band

Wireless N Gigabit Router

(TEW-673GR)

Notebook with

Wireless N PC Card

(TEW-641PC)

Cable/DSL

Modem

Workstation with

Wireless N PCI Adapter

(TEW-643PI)

Workstation with 300Mbps Dual Band

Wireless N USB Adapter

(TEW-664UB)

5Ghz wireless n 2.4Ghz Wireless n
