TRENDnet TEW-504UB Manuale utente

TRENDnet

TRENDware, USA

What's Next in Networking

TEW-504UB

Version 06.20.2005

108Mbps 802.11a/g Wireless USB 2.0 Adapter

Quick Installation Guide

Adaptateur USB 2.0 sans fil 108Mbps 802.11a/g

Guide d'installation rapide

Drahtloser 108 MBit/s 802.11a/g USB-2.0-Adapter

Kurzanleitung zur Installation

Adaptador USB 2.0 inalámbrico 802.11a/g a 108Mbps

Guía de instalación rápida

Адаптер 108 Мбит/сек 802.11a/g USB 2.0 для беспроводных соединений

Руководство по быстрой установке

Table of Contents

English ..................................................................................................................

Troubleshooting .....................................................................................................

1. Prepare for Installation ..................................................................................

2. Install Hardware .............................................................................................

3. Install Wireless Configuration Utility ..............................................................

4. Install Drivers ................................................................................................

5. Wireless Configuration ..................................................................................

Thank you for purchasing the TEW-504UB. Your new 108Mbps 802.11a/g

Wireless USB 2.0 Adapter will allow you to connect to 802.11a, 802.11g or

802.11b networks and begin wirelessly sharing the Internet, files, and other

resources.

This guide will help you set up and configure your Wireless USB Adapter.

Following this installation should be quick and easy. If you run into problems,

please refer to the Troubleshooting section or the more detailed installation

procedures on the User's Guide CD-ROM. If you need further technical

Before installing this 802.11a/g Wireless USB Adapter, you should have:

1. USB enabled computer

2. 300 MHz processor and 32 MB of memory (Recommended)

3. CD-ROM drive

4. 802.11a, 802.11g or 802.11b Access Point (for Infrastructure Mode) or

another 802.11g wireless adapter (for Ad-Hoc/Peer-to-Peer networking

mode).

Verify Package Contents

Minimum Hardware Requirements

Please make sure you have everything in the box:

1. Prepare for Installation

English QIG

English

USB Extension Cable Driver & Utility CD-ROM

TEW-504UB

Quick Installation Guide

TRENDnet

TRENDware, USA

What's Next in Networking

TEW-504UB

Version 06.20.2005

108Mbps 802.11a/g Wireless USB 2.0 Adapter

Quick Installation Guide

Adaptateur USB 2.0 sans fil 108Mbps 802.11a/g

Guide d'installation rapide

Drahtloser 108 MBit/s 802.11a/g USB-2.0-Adapter

Kurzanleitung zur Installation

Adaptador USB 2.0 inalámbrico 802.11a/g a 108Mbps

Guía de instalación rápida

Адаптер 108 Мбит/сек 802.11a/g USB 2.0 для беспроводных соединений

Руководство по быстрой установке

2. Install Hardware

The TEW-504UB is hot-pluggable. You can connect or disconnect the

TEW-504UB while the computer is on.

Connect the TEW-504UB Wireless USB Adapter to your computer's USB port.

English

Note: You can use the included USB extension cable for your

convenience to extend the cable connection between your computer

and the TEW-504UB.

Note: Do not connect the Wireless USB Adapter to your computer until

you have finished installing the Utility and Driver.

3. Install Wireless Configuration Utility

English

Windows 98SE/ME/2000/XP

1. Insert the TEW-504UB CD-ROM into your computer's CD-ROM drive; the

installation menu window will appear automatically. If the window does not

appear automatically, click Start, click Run, and type E:\Autorun.exe in the

text-field. Click OK.

2. On the Installation Menu, click Install Utility.

3. Follow the Install Shield Wizard's instructions to install the wireless

configuration utility.

4. Click Next.

Note: Replace "E" in "E:\Autorun.exe" with whichever letter is assigned

to your CD-ROM drive.

4English

5. Click Next.

6. Click Install.

5English

7. Click Finish.

8. On the Installation Menu, click Exit.

Note: For Windows 98/ME, manually restart your computer.

6English

4. Install Drivers

1. After installing the utility software, connect the Wireless USB Adapter to your

computer's USB port. Windows will detect new hardware and load the driver

automatically.

Windows 98SE/ME/2000/XP

Note: After driver installation is complete, the wireless icon will appear

in your system tray (next to the clock on the bottom right corner of your

screen). If it does not appear, restart your computer. Go to section 5

Wireless Configuration.

Congratulations!

Installation is now complete.

7English

5. Wireless Configuration

1. Double click the wireless icon on your desktop.

2. Click Profile Management and click Scan.

3. Select your wireless network's SSID and click Activate.

4. Type a Profile Name for the Access Point you selected and click OK.

Troubleshooting

Q1:

A1:

Q2:

A2:

Q3:

A3:

I completed all the steps in the quick installation guide, but my wireless USB

Adapter isn't connecting to my access point. What should I do?

First, you should verify that the Network SSID matches your wireless

router or access point's SSID. Second, you should check your TCP/IP properties

to ensure that Obtain an IP address automatically is selected. Third, you can

click on the Site Survey link to check and see if there are any available wireless

networks listed.

Windows is unable to recognize my hardware. What should I do?

Make sure your computer meets the minimum requirements as specified in

Section 1 of this quick installation guide. Also, you must install the wireless c

onfiguration utility (as described in Section 3) before connecting the wireless USB

Adapter.

I cannot open the wireless configuration utility. What should I do?

Go to your device manager (control panel system) to make sure the

adapter is installed properly. If you see a networking device with a yellow question

mark or exclamation point, you will need to reinstall the device and/or the drivers.

If you still encounter problems, please refer to the User's Guide CD-ROM or contact

technical support.

Certifications

This equipment has been tested and found to comply with FCC and CE Rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference.

(2) This device must accept any interference received.

Including interference that may cause undesired operation.
