TRENDnet TEW-687GA Manuale utente

wireless

Features

• 1 x 10/100/1000Mbps Auto-MDIX LAN port

• 1 x Wi-Fi Protected Setup (WPS) button

• 1 x Reset button

• Diagnostic LEDs

• High performance wireless data rates of up to 450Mbps

• Wi-Fi compliant with the IEEE 802.11n standard

• Backwards compatible with IEEE 802.11g/b devices

• Supports 64/128-bit WEP, WPA-PSK, and WPA2-PSK wireless security

• Power Save mode conserves electricity

• Supports Multiple Input Multiple Output (MIMO) antenna technology

• Wi-Fi Multimedia (WMM) Quality of Service (QoS) data prioritization

• One-touch wireless security setup using the Wi-Fi Protected Setup (WPS) button when connecting to a WPS supported device

• Maximum reliability, throughput and connectivity with automatic data rate switching

• Easy user setup wizard and intuitive Web browser configuration

• Coverage of up to 50 meters indoor, 100 meters outdoor *

• 3-year limited warranty

* Maximum wireless signal rates are referenced from IEEE 802.11 theoretical specifications. Actual data throughput and coverage will vary depending

on interference, network traffic, building materials and other conditions.

TEW-687GA

rev:12.22.2011

TEW-687GA(V1.0R)

450Mbps Wireless N Gaming Adapter

TRENDnet's 450Mbps Wireless N Gaming Adapter, model TEW-687GA,

networks gaming consoles, televisions, and DVRs to the Internet with an

ultra-high performance 450Mbps wireless connection.

Setup is quick and simple, with no drivers to install and a Gigabit Ethernet

port transfers wired data fast.

Advanced Multiple Input Multiple Output (MIMO) antenna technology with

three spatial streams per antenna generates a maximum theoretical wireless

throughput of 450Mbps. Connect to a router at the touch of a button with Wi-

Fi Protected Setup (WPS). WMM® Quality of Service (QoS) technology

prioritizes gaming, Internet calls, and video streams. LEDs on the front of the

adapter convey device status. Cut your cables and start winning with ultra-

high performance 450Mbps wireless n.

SPECIFICATIONS

Standards

Interface

LED Indicator

• IEEE 802.11b, IEEE 802.11g, and IEEE 802.11n

• 153 g (5.4 oz.)

• Storage: -20° ~ 60° C (-4° ~ 140° F)

• 1 x 10/100/1000Mbps Auto-MDIX LAN ports

• 60 x 118 x 135 mm (2.4 x 4.6 x 5.3 in.)

• Power, LAN, Wireless, WPS

• WPS button – enables WPS function

Weight

Hardware

SPECIFICATIONS

• Operating: 0° ~ 40° C (32° ~ 104° F)

Temperature

• Max. 90% (non-condensing)

Humidity

• CE, FCC

Certifications

Dimensions (LxWxH)

Button

Frequency

Data Rate (auto fallback)

• 2.412 ~ 2.472 GHz

• 802.11b: up to 11Mbps

Wireless

• 802.11g:up to 54Mbps

Encryption

Channels

• 802.11b: -84dBm (typical)

Receiving Sensitivity

• 1~ 11 (FCC), 1~13 (ETSI)

• 802.11n: up to 450Mbps

• 64/128-bit WEP , WPA/WPA2-PSK

• Reset button – restores factory default settings

Power • 12V DC 0.5A power adapter

• 4.5 watts (max)

Power Consumption

• 802.11g: -72dBm (typical) • 802.11n: -69dBm (typical)

Output Power • 802.11n : 13dBm (typical)

• 802.11g: 15dBm (typical)

• 802.11b: 18dBm (typical)

1-888-326-6061

CONTACT INFORMATION

RELATED PRODUCTS

PACKAGE CONTENTS

NETWORKING SOLUTIONS

• Multi-Language Quick Installation Guide

• 1 x Cat. 5 Ethernet cable (0.6 m / 2 ft.)

• TEW-687GA

• CD-ROM (Utility and User’s Guide)

TEW-691GR

TEW-690AP

TEW-640MB 300Mbps Wireless N 4-Port Media Bridge

450Mbps Wireless N Gigabit Router

450Mbps Wireless N Access Point

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

www.trendnet.com

• Power adapter (12V DC, 0.5A)

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

TEW-687GA(V1.0R)

450Mbps Wireless N Gaming Adapter
