TRENDnet TEW-648UBM Manuale utente
150Mbps Micro Wireless N USB
Adapter
TEW-648UBM
ŸQuick Installation Guide (1)
ŸTroubleshooting (5)
1.11
Ÿ
Ÿ
USB port: 2.0 or 1.1 (Disclaimer: When connecting the TEW-648UBM to a
USB 1.1 port, the maximum speed is 12Mbps)
CD-ROM Drive
Minimum Requirements
1
Supported Operating
Systerms
CPU Memory
Windows 7 (32/64-bit)
Windows Vista (32/64-bit)
Windows XP (32/64-bit)
1GHz or above
800MHz or above
300MHz or above
1GB RAM or above
512MB RAM or above
256MB RAM or above
Package Contents
Ÿ
ŸCD-ROM (Utility and User's Guide)
ŸMulti-Language Quick Installation Guide
TEW-648UBM
If any of the above contents are missing, please contact your reseller.
1. Before You Start
2. How to Install
Important! DO NOT connect the TEW-648UBM to the computer
until instructed to do so.
1. Insert the Utility & Driver
CD-ROM into your computer's
CD-ROM Drive.
2. Click Run Autorun.exe
(Windows 7/Vista only).
3. Click Install Utility.
4. Click Next. Then follow the
InstallShield Wizard instructions.
5. Click Install this driver anyways
(Windows 7/Vista).
6. Click Continue Anyway
(Windows XP).
7. Click Finish.
2
8. Connect the wireless adapter to an
available USB port on your
computer.
Note: For Windows 7/Vista, drivers will install automatically. Proceed
to section 3 Using the Wireless Adapter. For Windows XP, continue
on to step 9.
9. The Found New Hardware Wizard
appears Select No, not this time
and then click Next.
10. Select Install this software
automatically (recommended
and then click Next.
11. Click Continue Anyway.12. Click Finish.
Your installation is now complete.
3
3. Using the Wireless Adapter
1. On the bottom right-hand corner of the
screen, double-click on the Wireless
Configuration Utility icon. On Windows
7, if the icon does not appear, click the
Show hidden icons arrow.
2. Click Available Networks. Select a
SSID and then click Add Profile. The
SSID is the wireless network name of
your wireless network (e.g. wireless
router or access point).
3. If Encryption is enabled on your
wireless network (e.g. access point or
wireless router), the correct Network
Authentication and Data Encryption
type should be selected. Enter the
Network Key (wireless network
password), confirm the network key
and then click OK.
Wireless configuration is now complete
For detailed information regarding the TEW-648UBM configuration and advanced
settings, please refer to User's Guide included on the Utility CD-ROM, or TRENDnet's
website at http://www.trendnet.com.
4
1. I inserted the Utility & User's Guide CD-ROM into my computer's CD-
ROM Drive and the installation menu does not appear automatically.
What should I do?
1. For Windows 7, if the installation menu does not appear automatically,
click on the Windows Icon on the bottom left hand corner of the
screen, click the “Search programs and files” box, and type
D:\Autorun.exe, where “D” in “D:\Autorun.exe” is the letter assigned to
your CD-ROM Drive, and then press the ENTER key on your keyboard
2. For Windows Vista, if the installation menu does not appear
automatically, click on the Windows Icon on the bottom left hand
corner of the screen, click on the “Start Search” box, and type
D:\autorun.exe, where “D” in “D:\Autorun.exe” is the letter assigned to
your CD-ROM Drive, and then press the ENTER key on your keyboard.
3. For Windows XP, if the window does not appear automatically, click
Start, click Run and type D:\Autorun.exe where “D” in “D:\Autorun.exe”
is the letter assigned to your CD-ROM Drive, and then press the
ENTER key on your keyboard.
2. I completed all the steps in the quick installation guide, but my
Wireless USB Adapter is not connecting to my wireless network (e.g.
wireless router or access point). What should I do?
1. Verify that the SSID (Network Name) matches your wireless router or
access point's SSID (Network Name).
2. Please check with your network administrator for the security key in
order to access the secured wireless access point or router. Please
refer to the User's Guide for more information regarding wireless
network security.
3. Check your TCP/IP properties to ensure that Obtain an IP address
automatically is selected.
4. Double-click the Wireless Configuration Utility icon, click Available
Networks and then click Refresh to check and see if there are any
available wireless networks listed.
5. Please refer to the Wireless tips section if you continue to have
wireless connectivity problems.
5
Troubleshooting
6
3. Windows is unable to recognize my hardware. What should I do?
1. Make sure your computer meets the minimum requirements as
specified in Section 1 of this quick installation guide.
2. You must complete the installation of the Wireless Configuration Utility
(as described in Section 2) before connecting the Wireless USB
Adapter to your computer.
3. Connect the Wireless USB Adapter to a different USB port on your
computer.
4. I cannot open the Wireless Configuration Utility. What should I do?
Access your device manager to make sure the adapter is installed
properly.
1. To access the device manager on Windows 7, click on the Windows
icon on the bottom left-hand corner, click Computer, click System
Properties and then click Device Manager.
2. To access the device manager on Windows Vista, right-click Computer,
click Properties and then click Device Manager.
3. To access the device manager on Windows XP, right-click My
Computer, click Properties, click the Hardware tab, and then click
Device Manager.
If you see a networking device with a yellow question mark or
exclamation point:
1. Uninstall the device from device manager
2. Remove the adapter from the computer
3. Click the Windows / Start icon, click All Programs, click TRENDnet,
click TEW-648UBM and then click Uninstall.
4. Reinstall the adapter. See Section 2. How to Install.
If you still encounter problems or have any questions regarding the
TEW-648UBM, please refer to the User's Guide included on the Utility &
User's Guide CD-ROM or contact TRENDnet's Technical Support Department.
TRENDnet
20675 Manhattan Place
Torrance, CA 90501. USA
Copyright ©2011. All Rights Reserved. TRENDnet.
Version 06.15.2011
