FEATURES
• 1x 10/100Mbps Fast Ethernet port
• MJPEG video compression at up to 30 frames per second
• Resolution up to VGA: 640 x 480 pixels
• Pan: -156° ~ +156° and tilt: -45° ~ +70°
• Defi ne up to 24 preset viewing points
• 4x digital zoom
• Create up to 64 user accounts
• Full image color, saturation and contrast controls
• Exposure/white balance controls
• Flip-Image feature adjusts image when camera is mounted upside down
• Included wall and ceiling mounting hardware
• Supports TCP/IP networking, SMTP Email*, HTTP and other Internet protocols
• Record streaming video to your computer or network storage devices (after mapping)
• Motion detection email alerts, ftp uploads and recording from complimentary software
• Quick Universal Plug and Play (UPnP) installation
• Complimentary IPView Pro 2.0 software: manage up of up to 32 cameras **
• 3-year limited warranty
* Does not support SSL
** Monitoring multiple cameras may require a high performance CPU
TV-IP600
Rev: 08.11.2009
ProView Pan/Tilt/Zoom Internet Camera
TV-IP600 (V1.0R)
The ProView Pan/Tilt/Zoom Internet Camera provides real-time security
surveillance over a large viewing area. Monitor people in your camera’s
viewing fi eld from any Internet connection. See more with one Internet
camera—remotely pan the camera side-to-side a remarkable 312 degrees
and tilt up-and-down 115 degrees.
Manage up to 32 TRENDnet cameras with the included complimentary
camera management software. Advanced features include motion detection
recording, email alerts, scheduled recording sessions, auto-patrol pan/tilt and
digital zoom. This camera’s brilliant image quality, pan and tilt functionality
and recording capabilities make it ideal for home, small offi ce and business
use.
ProView Pan/Tilt/Zoom Internet Camera
TV-IP600 (V1.0R)
SPECIFICATIONS
CAMERA
General • Sensor: 1/4” color CMOS SOC image sensor
• Resolution: 640 x 480 pixels
• Board Lens
• Focal Length: 4.57mm
• F/No: F1.9
• Minimum illumination: 1 Lux @ F1.9
• Focus depth: 20cm ~ infi nity
• View angle: horizontal: 46 degree, vertical: 35 degree
Image & Video • Compression: MJPEG
• Exposure/white balance control: automatic
• Resolution: up to 15fps for VGA (640x480), 30fps for QVGA (320x240), 30fps for QQVGA (160x120)
Pan/Tilt • Pan: -156° ~ +156°
• Tilt: -45° ~ +70°
• Preset position: 24 positions
HARDWARE
Network • IEEE 802.3u 10/100Mbps Fast Ethernet, Auto-MDIX
LED • Power, Link
Reset Button • Reset settings
Power Consumption • 8 watts
Power • 5V, 2.5A external power adapter
Dimension • 112 x 112 x 110mm (4.4 x 4.4 x 4.3 in.)
Weight • 450g (1lb)
Temperature • Operating: 5°C ~ 40°C (41°F ~ 104°F)
• Storage: -25°C ~ 50°C (13°F ~ 122°F)
Certifi cation • CE, FCC
REQUIREMENT
To View • Internet Explorer 6.0 or above, Safari 2.0 or above, Firefox 2.0 or above, Opera, Netscape, and Google Chrome
To Run Software • Windows 7 (32/64-bit), Vista (32/64-bit), XP (32/64-bit)
IPView Pro 2.0 • Channel: supports up to 32 cameras
• Record/Playback/Motion Detection
Network Protocols • IP, ARP, TCP, UDP, ICMP
• DHCP Client, NTP Client, DNS Client, DDNS Client, SMTP Client, FTP Client
• HTTP Server
• PPPoE
• UPnP
MANAGEMENT
Account • Up to 64 user accounts*
Remote • Remote management supported
Backup / Restore • Save/retrieve confi guration fi les
TV-IP600
Rev: 08.11.2009
TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet products and is subject to change at any time,
without notice. For the most recent product information please visit http://www.trendnet.com Copyright ©TRENDnet.All Rights Reserved.
CONTACT INFORMATION
20675 Manhattan Place,Torrance, CA 90501 USA
Tel: 1-310-961-5500
Fax: 1-310-961-5511
Web: www.trendnet.com
Email: [email protected]
1-888-326-6061
PACKAGE CONTENTS
TV-IP600
CD-ROM (Utility & User’s Guide)
Multi-Language Quick Installation Guide
Cat. 5 Ethernet cable (1.5m / 5ft.)
Power adapter (5V, 2.5A)
Wall mount kit
RELATED PRODUCTS
TWG-BRF114 4-Port Gigabit Firewall Router
TS-S402 2-Bay SATA I/II Network Storage Enclosure
TV-H400 Outdoor Camera Dome Enclosure
NETWORKING SOLUTIONS
ProView Pan/Tilt/Zoom Internet Camera
TV-IP600 (V1.0R)
SPECIFICATIONS
SETTINGS
Image • Brightness, contrast, noise reduction, saturation, sharpness, white balance, fl ip, mirror (horizontal/vertical), black/white mode
Video • Encoding type: MJPEG
• Resolution: 640 x 480, 320 x 240, 160 x 120
• Frame rate: 1, 5, 7, 15, 20, Auto
• Compression: 5 levels
Recording • Recording type: continuous, schedule or motion detection with software
Port Settings • HTTP port: 80 (default)
Digital Zoom • 4x
Dynamic DNS • Yes
Time • Synchronize with NTP server or set time/date manually
SMTP • Support SMTP mail
