TRENDnet TFC-1600 Manuale utente

TRENDnet's TFC-100 series Fiber Media Converter

transforms 100Base-TX UTP/STP media to 100Base-FX

media and vice versa. The 100Base-TX port auto-negotiates

half-/full-duplex connection and it has a slide-switch for

selecting MDI-X / MDI-II media type. The fiber connection can

be multi-mode SC, MT-RJ, or single-mode SC connector and

supports half-duplex and full-duplex modes. This converter

will give your Switch/Hub the ability to interface with fiber

connections over a distance up to 75 km. With the optional 16-

slot EIA-19" rack-mount chassis, the TFC series converters

are the perfect solutions for various fiber media conversions

for your network.

TFC-100 SERIES Fiber Media Converter

Compliant with IEEE 802.3u 100Base-TX and

100Base-FX standards

One 100Mbps RJ45 port with MDI-X / MDI-II selector

Auto-Negotiation for half-duplex/full-duplex on

100Mbps port

One 100Mbps fiber port with Multi-mode SC or MT-

RJ, or Single-mode SC connector

Status LED indicators for Power, TX (Link/Activity),

Full-Duplex, and FX

Wall-Mountable

Optional 19" system chassis with redundant power

supply, holds up to 16 TFC series Media Converters

5 Year Warranty

FEATURES

TFC-100 (11-17-2002)

TRENDnet

TRENDware, USA

What's Next in Networking

SPECIFICATIONS

PRODUCT INFORMATION

To Order Please Call:

1-888-326-6061

TFC-100MSC: 100Base-TX to 100Base-FX Multi-mode

Fiber with SC Connector

TFC-100MM: 100Base-TX to 100Base-FX Multi-mode

Fiber with MT-RJ Connector

TFC-100S15: 100Base-TX to 100Base-FX Single-

mode 15 km Fiber with SC Connector

TFC-100S40: 100Base-TX to 100Base-FX Single-

mode 40 km Fiber with SC Connector

TFC-100S75: 100Base-TX to 100Base-FX Single-

mode 75 km Fiber with SC Connector

TFC-1600: 16-slot EIA-19" (2 Unit-Height) Chassis for

TFC series Media Converters

ORDERING INFORMATIONORDERING INFORMATION

TRENDnet

TRENDware, USA

Standards:

• IEEE 802.3u 100Base-TX, IEEE 802.3u 100Base-FX

Ports:

• 1 x 100Base-TX and 1 x 100Base-FX

FX port Media Types:

• Multi-mode SC or MT-RJ; Single-mode SC

Network Media:

• 100Base-TX: CAT 5, EIA/TIA-568 100-ohm UTP/STP, up to

100 meters.

• 100Base-FX: 50/125µm or 62.5/125µm multi-mode fiber

optic cable, up to 2 km. 9/125µm or 10/125µm single-mode

fiber optic cable, up to 75 km.

Protocol:

• CSMA/CD

Data Transfer Rate:

• 100Mbps (Half-Duplex)

• 200Mbps (Full-Duplex)

Diagnostic LEDs:

• Power, Link/Activity, and Full-Duplex

Power Adapter:

• 7.5VDC, 1.5A (7.2 watts max.)

Dimensions:

• 120 x 88 x 25 mm (W x D x H)

Weight:

• Appro. 305 g. (10.8 Oz.)

Temperature:

• Operating: 0° ~ 40° C (32° ~ 104° F),

• Storage: -25° ~ 70° C (-13° ~ 158° F)

Humidity:

• Operating: 10% ~ 90%,

• Storage: 5% ~ 90% (non-condensing)

Certifications:

• FCC, CE, VCCI

TFC-100 SERIES Fiber Media Converter

TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this

document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit

____________________

http://www.TRENDNET.com.

TRENDware International, Inc.

3135 Kashiwa Street

Torrance, CA. 90505. USA

Tel: 310-891-1100

Fax: 310-891-1111

Web:

Email: [email protected]

www.TRENDNET.com
