TRENDnet TV-IP121W Manuale utente

TV-IP121W

rev: 02.16.2010

Features

The SecurView Wireless Day/Night Internet Camera (model TV-

IP121W) transmits real-time high quality video over the Internet. See

and hear people in your camera's viewing field in complete darkness for

distances up to 5 meters (16 feet) from any Internet connection.

Manage of up to 16 cameras with complimentary SecurView camera

management software. This stylish Internet camera provides crystal

clear MJPEG video streams over a secure encrypted wireless

connection.

Mount the camera on most surfaces with an included mounting kit.

Advanced software features motion detection recording, email alerts*,

scheduled recordings, video viewing options and digital zoom. The

camera´s brilliant image quality, compact size, audio support and night

vision capability make it ideal for your home or office.

TV-IP121W [A1.0R]

SecurView Wireless Day/Night Internet Camera

internet

cameras

Compatible with 802.11g and b wireless networks

Compatible with 802.11n wireless networks when set to 802.11n/g/b mixed mode

Encryption support for WEP, WPA-PSK and WPA2-PSK standards

Infrared lens enables night vision for distances up to 5 meters (16 feet)

60 degree viewing angle, 4.5mm focal length and 2.8 F/No

Supports still image snapshot to FTP and email*

Record streaming video to your computer

Supports TCP/IP networking, SMTP email* and HTTP

High quality MJPEG video recording with up to 30 frames per second at 640x480 VGA resolution

Motion detection and scheduled recording

Control two adjustable motion detection windows with just-in-time snapshot and email notification* capabilities

Embedded Watchdog feature automatically reboots camera if an operational errors is detected

Supports time stamp overlay

Hear people in your camera's viewing area through your computer

Quick Universal Plug and Play installation

Complimentary SecurView™ software: view and record up to 16 SecurView cameras simultaneously **

Complimentary SecurView™ software: supports Windows 2000/XP/Vista operating systems

3-year limited warranty

* Does not support SSL

** Monitoring multiple cameras may require a high performance CPU and graphics card

SPECIFICATIONS

LED

Reset Button

Power Consumption

Dimension

• Built-in omni-directional microphone

• Power, Link/Act

• IEEE 802.11b/g

• Reset settings

• 6 watts (max)

• Windows 2000, XP, Vista

General

Camera

• Sensor: 1/4” color CMOS sensor

Image & Video

• IEEE 802.3u 10/100Mbps Fast Ethernet, Auto-MDIX

Network

Standard

• Exposure/white balance control: automatic

• Internet Explorer 6.0 or above

Audio

Power • 5V DC, 2.5A external power adapter

• CE, FCC

• 70 x 100 x 57mm (2.67 x 3.94 x 2.95 in.)

Certifications

Camera Configuration

To Run Software

SecurView™ Software

Weight • Camera: 165g (5.8 oz.)

Temperature • Operating: 0°C ~ 45°C (32°F ~ 113°F)

• Cameras Supported:16

Hardware

• Sensitivity: -48dB +/- 3dB (5 meters max)

• Resolution: VGA (640x480), QVGA (320x240), QQVGA (160x120) up to 30fps

• Record/Playback/Motion Detection/Audio

TV-IP121W [A1.0R]

SecurView Wireless Day/Night Internet Camera

TV-IP121W

• Resolution: 640 x 480 pixels • Focal Length: 4.5mm

• F/No: F2.8 (Board Lens) • Minimum illumination: 0.5 Lux @ F2.8 • View angle: 60 degrees diagonal

• Frequency: 50~16000Hz • Codec: PCM

• Compression: MJPEG

• Flip Images: Vertical/horizontal • Light Frequency: 50Hz, 60Hz or outdoor

Requirement (SecurView™)

• Storage: -15°C ~ 60°C (14°F ~ 140°F)

• Stand: 135g (4.76 oz.)

Wireless

• 64/128-bit WEP, WPA-PSK, WPA2-PSK

• 1 x 2dBi detachable Reverse SMA connector

Antenna

Security


• Recording type: event based (motion detection and digital input trigger), continuous and scheduled

Settings

• HTTP port: 80 (default)

• Trigger event: motion detection

Recording

Snapshot

• Yes

• 3x

Port Settings

Digital Zoom

• Synchronize with NTP server or set time/date manually

Dynamic DNS

• Brightness, contrast, saturation, sharpness, white balance, flip, mirror (horizontal/vertical)

Time

• Storage size: 32MB (minimum)

• Action: send alert email and/or upload to FTP

rev: 02.16.2010

• Internet Explorer

Browser

• 2.412~ 2.484GHz

Frequency

TRENDnet is a registered trademark. Other Brands and product names are trademarks of their respective holders. Information provided in this document pertain to TRENDnet

products and is subject to change at any time, without notice. For the most recent product information please visit

http://www.trendnet.com.

ORDERING INFORMATION

20675 Manhattan Place,Torrance, CA 90501 USA

Tel: 1-310-961-5500

Fax: 1-310-961-5511

Web:

Email: [email protected]

To Order Please Call:

1-888-326-6061

www.trendnet.com

RELATED PRODUCTS

PACKAGE CONTENTS

• TV-IP121W

• Multi-Language Quick Installation Guide

TV-IP422W SecurView Wireless Day/Night Pan/Tilt/Zoom Internet

Camera

TV-H110 Internet Camera Server

TV-IP312W SecurView Wireless Day/Night Internet Camera

TV-IP121W [A1.0R]

SecurView Wireless Day/Night Internet Camera

• Cat.5 Ethernet cable (1.8m / 5.9ft)

• Power adapter (5V DC, 2.5A)

• CD-ROM (Utility & User’s Guide)

• Mounting kit

NETWORK SOLUTIONS

54Mbps

SecurView Wireless Day/Night

Internet Camera

(TV-IP121W)

Wireless G Firewall Router

(TEW-432BRP)

Modem

Notebook with Wireless G PC Card

(TEW-421PC)

Internet
