Tripp Lite U209-000-R Manuale utente

Tripp Lite World Headquarters

1111 W. 35th Street, Chicago, IL 60609 USA

(773) 869-1234, www.tripplite.com

USER’S MANUAL

USB to Serial Adapter

Model #: U209-000-R

NOTE: Follow these installation and operating procedures to ensure correct

performance and to prevent damage to this unit or to its connected devices.

their respective owners. Technical specifications are subject to change without notice.

200205099 93-2072 U209-000-R OM.qxd 6/5/02 4:26 PM Page

System Requirements

1. USB enabled PC system with a USB port

2. Operating systems: Windows®98 or Windows®2000

3. CD-ROM Drive (to load drivers)

Installation

1. With the computer booted up, insert mini-CD and plug the USB to

Serial Adapter into the computer’s USB port; the New Hardware

Wizard appears; click on Next to continue.

2. In the dialog box that appears, leave the default choice (Search for

the best driver for your device); click on Next to continue.

3. In the, Ready to install, dialog box, that appears, click on Next to

continue. Files are now copied to your hard disk.

4. After the driver files have been copied to the hard disk, a dialog box

appears to tell you that the installation has finished. Click on Finish.

Windows now finishes up the installation.

Checking the Installation

1. Open the My Computer folder.

2. Open the Control Panel folder.

3. Open the System folder.

4. Click on the Device Manager tab.

5. On Windows®98, click on the plus sign in front of Universal Serial

Bus Controllers heading to see the Universal Serial Bus Controller

listing. If installation was successful, you should see an entry for

USB to Serial Cable in the listing. On Windows®2000, the device

will show up under ports as an additional Comm Port.

200205099 93-2072 U209-000-R OM.qxd 6/5/02 4:26 PM Page

Uninstalling the Driver

1. Open the system folder:

(My Computer -> Control Panel -> System)

2. Click on the Device Manager tab.

3. Click on the plus sign in front of Universal Serial Bus Controllers

heading to see the Universal Serial Bus Controller listing.

4. Select USB to Serial Cable.

5. Click the Remove button.

Peripheral Installation

1. With the USB to Serial Adapter already installed, plug the peripheral

into the adapter and then turn the peripheral on.

2. Follow the Installation Wizard’s on-screen instructions to complete

the installation.

200205099 93-2072 U209-000-R OM.qxd 6/5/02 4:26 PM Page

Read if Experiencing Installation Problems

When Using a Tripp Lite USB to Serial Adapter

(U209-000-R) on a Laptop/Notebook PC.

The following procedure may be required if you have a laptop that does

not have a hardwired native serial port. On this type of unit, the

manufacturer may have eliminated the serial chipset on the motherboard

thereby disabling the USB adapter’s port emulation feature. If this is the

cause of your problem, the following procedure will resolve this issue.

Please follow the instructions in their entirety.

Creating a Virtual Com Port on Your Laptop/

Notebook:

1. Open Add New Hardware (Start - Settings - Control Panels -

Add New Hardware).

2. Add New Hardware Wizard Introduction screen will appear.

Click “Next”.

3. Computer will search for connected devices. Either a prompt will

appear asking you to select a device from a list or it will ask you if

you want to search for new devices. If asked to select from a list,

click “No” and then “Next”. If not prompted, simply click “Next”. If

prompted to select from a list, the next screen will ask if you want to

search for new drivers. Click “Next”.

200205099 93-2072 U209-000-R OM.qxd 6/5/02 4:26 PM Page

4. The following screen will alert you to the fact it will now search for

new devices. Click “Next”. (Note: This may take several minutes

depending on your system. The screen may go black for a few

seconds. This is normal.)

5. When done, select “Next”.

6. A list of device types will appear. Scroll down to:

Ports (Com & LPT). Click “Next”.

7. A two-paned list will appear. On left under Manufacturers, select

“Standard Port Types”. On the right under Models, select

“Communications Port”. Click “Next”.

8. You will be prompted to set up the properties and settings of the Com

Port. Leave values as defaults. Click “Next”.

9. When completed, select “Next”.

10. You will be prompted to restart. Click “Yes”.

11. After restart, reinstall the USB-Serial Adapter onto the Virtual Com Port.

If Your Computer Does Not Boot Up After You

Install Your Com Port, do the Following:

1. Disconnect the USB-Serial Adapter. Boot your machine in Safe

Mode. (To do this, press “F8” when you first boot up. Press it

repeatedly until you get a selection screen, choose “Safe Mode”).

2. After boot up, go into your device manager and select the Com Port.

3. Click “Remove”. Follow the prompts and restart as normal.

200205099 93-2072 U209-000-R OM.qxd 6/5/02 4:26 PM Page

Installing the USB to Serial Adapter’s Driver*:

* May vary slightly depending upon installed O/S version.

1. Open Device Manager (Start-Settings-Control Panels-System;

Device Manager Tab).

2. Select the USB-Serial Adapter. It will appear as Unknown Device,

Composite Device or USB Device. It will appear under “Other

Devices” or “Universal Serial Bus Controller”.

3. Click “Properties”.

4. Click on “Reinstall Drivers”.

5. In Add New Hardware Wizard click “Next”.

6. It will now conduct a search, choose “Next”.

7. Select “Specify Location”. Next click “Browse” or select the driver

location. Select either the drivers on the CD (Example: D:\U209-000-R)

or the one downloaded. Note, if you are using Windows ME you

need to use the WIN98 driver. Click “Next”.

8. If detected, click “Next”. (If not go back and try again).

9. When done click “Finish”.

10. Connect your Serial Device to the USB-Serial Adapter.

200205099 93-2072 U209-000-R OM.qxd 6/5/02 4:26 PM Page

Specifications

Function Description

Data Transfer Rate Over 500 Kbps

LED Data Transfer / Handshaking (orange)

Power Consumption 450 mW

USB Specification V1.1 Compliant

DB-9 Assignments

Pin Assignment

6 DSR

7RTS

8 CTS

9RI

Pin Assignment

1CD

2 RXD

3 TXD

4 DTR

5 GND

200205099 93-2072 U209-000-R OM.qxd 6/5/02 4:26 PM Page

FCC Radio/TV Interference Notice

Note: This equipment has been tested and found to comply with the limits

for a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses

and can radiate radio frequency energy, and if not installed and used in

accordance with the instruction manual, may cause interference to radio

communications. However, there is no guarantee that interference will not

occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures: reorient or

relocate the receiving antenna; increase the separation between the

equipment and receiver; connect the equipment into an outlet on a circuit

different from that which the receiver is connected; consult the dealer or an

experienced radio/television technician for help. The user must use

shielded cables and connectors with this product. Any changes or

modifications to this product not expressly approved by the party

responsible for compliance could void the user’s authority to operate the

equipment.

200205099 93-2072 U209-000-R OM.qxd 6/5/02 4:26 PM Page

LIFETIME LIMITED WARRANTY

TRIPP LITE warrants its products to be free from defects in materials and

workmanship for life. TRIPP LITE’s obligation under this warranty is limited to

repairing or replacing (at its sole option) any such defective products. To obtain

service under this warranty, you must obtain a Returned Material Authorization

(RMA) number from TRIPP LITE or an authorized TRIPP LITE service center.

Products must be returned to TRIPP LITE or an authorized TRIPP LITE service

center with transportation charges prepaid and must be accompanied by a brief

description of the problem encountered and proof of date and place of purchase.

This warranty does not apply to equipment, which has been damaged by

accident, negligence or misapplication or has been altered or modified in any

way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES,

EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY

AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit

limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s)

or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE

FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL

DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF

ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP

LITE is not liable for any costs, such as lost profits or revenue, loss of equip-

ment, loss of use of equipment, loss of software, loss of data, costs of

substitutes, claims by third parties, or otherwise.

The policy of TRIPP LITE is one of continuous improvement. Specifications are

subject to change without notice.

200205099 93-2072 U209-000-R OM.qxd 6/5/02 4:26 PM Page

1111 W. 35th Street, Chicago, IL 60609 USA

773.869.1234 (USA) • 773.869.1212 (International)

www.tripplite.com
