Tripp Lite Easy Pull Long-Run Display Cable EZA-100 Manuale utente

Tripp Lite

1111 West 35th Street

Chicago, IL 60609 USA

Telephone: +(773) 869 1234

E-mail: [email protected]

Model #: EZA-100

100-ft. Easy Pull Long-Run Display Cable - Type-A Analog PVC Trunk Cable

Highlights

Versatile trunk cable allows for a variety of connection options

Easily pulls through conduit or confined spaces with included end caps with

integrated pull tabs

High quality RGB style VGA cable supports resolutions up to 1600 x 1200

Description

Tripp Lite's EZA-100 100 ft. Easy Pull VGA Trunk cable makes pulling video cable through conduit or confined areas a breeze. Threaded ends

feature screw on pull-caps, which can be attached to fish tape. Choose from a variety of connector choices that easily screw on to the threaded ends

of the trunk cable. Trunk cables are available in 35 ft., 50 ft. and 100 ft. PVC as well as 35 ft. and 50 ft. plenum. Cable ends are colored-coded

green to denote VGA applications (Digital trunk cables are Yellow). Cable features triple-shielded construction with 75 ohm coax conductors for

RGBHV signals supporting resolutions up to 1600 x 1200.

Applications

Use where standard VGA cables won't fit, such as conduit or confined wall or ceiling spaces

Package Includes

Easy Pull Type-A VGA Analog PVC Trunk Cable, 100 ft.

Features

Eliminates the need to field terminate VGA connectors

Detachable, screw-on connectors

Allows cable to be run according to code - inside conduit, drop ceilings, etc.

Makes pulling long cables fast and easy

Protects entire cable from strain, dirt, debris and damage

Choose from a variety of connector combinations for the perfect fit

Available in 35 ft., 50 ft. and 100 ft. PVC lengths and 35 ft. and 50 ft. plenum jackets

Specifications

OVERVIEW

Intended Application Home Theater/AV, Connecting Peripherals

Display Style Easy Pull

INPUT

Cable Length (ft.) 100

Cable Length (m) 30.48

PHYSICAL

Color Black & Green

CONNECTIONS

Connector A

EASY PULL A (FEMALE)

Connector B

EASY PULL A (FEMALE)

Number of Connectors 2

WARRANTY

Product Warranty Period

(Worldwide)

Lifetime limited warranty

Related Items

Optional Products

Product Type Related Model Description Qty.

Video Cables & Adapters EZA-035 35-ft. Easy Pull Long-Run Display Cable

Type-A Analog PVC Trunk Cable

Video Cables & Adapters EZA-035-P 35-ft. Easy Pull Long-Run Display Cable

Type-A Analog Plenum Trunk Cable

Video Cables & Adapters EZA-050 50-ft. Easy Pull Long-Run Display Cable

Type-A Analog PVC Trunk Cable

Video Cables & Adapters EZA-050-P 50-ft. Easy Pull Long-Run Display Cable

Type-A Analog Plenum Trunk Cable

Video Cables & Adapters EZA-VGAAF-2 Easy Pull Type-A Connectors

F/F set of VGA with Audio and Faceplates

Video Cables & Adapters EZA-VGAAM-2 Easy Pull Type-A Connectors

M/M set of VGA with Audio

Video Cables & Adapters EZA-VGAAX-2 Easy Pull Type-A Connectors

M/F set of VGA with Audio and Faceplate

Video Cables & Adapters EZA-VGAF-2 Easy Pull Type-A Connectors

F/F set of VGA with Faceplates

Video Cables & Adapters EZA-VGAM-2 Easy Pull Type-A Connectors

M/M set of VGA

Video Cables & Adapters EZA-VGAX-2 Easy Pull Type-A Connectors

M/F set of VGA with Faceplate

More information, including related products, owner's manuals, and additional technical specifications, can be found online at

www.tripplite.com/en/products/model.cfm?txtModelID=3784.

improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
