Tripp Lite U357-1M2-NVMEG2 Manuale utente

1111 W. 35th Street, Chicago, IL 60609 USA

tripplite.com/support

Owner’s Manual

WARRANTY REGISTRATION

win an ISOBAR®surge protector in our monthly drawing!

tripplite.com/warranty

USB 3.2 Gen 2 M.2 SSD

Enclosure (PCle and NVMe)

with USB Hub for PlayStation 5

Model: U357-1M2-NVMEG2

Español 15 • Français 29

Русский 43 • Deutsch 57

21-10-337 9340FC.indb 121-10-337 9340FC.indb 1 12/3/2021 1:23:24 PM12/3/2021 1:23:24 PM

Product Features

Package Contents

System Requirements

• USB-A ports support USB 3.2 Gen 2 data transfer

speeds up to 10 Gbps

• LEDs indicate power is on and read/write is

occurring

• Aluminum case maintains fast heat dissipation,

which allows for stable, smooth file transfers

• Hot-swappable enclosure supports multi-size M.2

SSD specifications (42 mm, 60 mm, 80 mm),

PCle and NVMe protocol, SSD TRIM and UASP

acceleration, and M.2 M-Key and B&M-Key socket

• Plug-and-play operation with no software required

for easy, immediate installation

• U357-1M2-NVMEG2 M.2 SSD Enclosure

• USB-A Cable (M/F)

• Aluminum Sheet

• (2x) Silicone Sheets

• Owner’s Manual

• Playstation®

• Windows®8, 10 or 11

21-10-337 9340FC.indb 221-10-337 9340FC.indb 2 12/3/2021 1:23:24 PM12/3/2021 1:23:24 PM

Optional Accessories

Installation

• U324-Series USB 3.2 Extension Cables

Notice:

• This product uses the M-Key interface, which

belongs to the NVMe protocol channel. When

installing the M.2 SSD for this product, please

check the hard disk interface and protocol channel.

• Although the USB end of the product supports

hot-swapping when installing the M.2 SSD, it

must be done when the power is off.

• When disassembling and installing the hard disk

box, take care to prevent any accessories from

becoming lost.

1. Hold the product as shown below, and slide the

upper cover to the left to remove it.

21-10-337 9340FC.indb 321-10-337 9340FC.indb 3 12/3/2021 1:23:25 PM12/3/2021 1:23:25 PM

Installation

2. Slide the M.2 card into the enclosure at an angle.

3. Gently press down on the M.2 SSD, and snap it

into the standard rubber cartridge.

21-10-337 9340FC.indb 421-10-337 9340FC.indb 4 12/3/2021 1:23:28 PM12/3/2021 1:23:28 PM

Installation

4. Place a silicone sheet and then the aluminum

sheet over the M.2 SSD card.

5. Attach the upper cover to the enclosure by pressing

it and sliding it to the right.

21-10-337 9340FC.indb 521-10-337 9340FC.indb 5 12/3/2021 1:23:29 PM12/3/2021 1:23:29 PM

Installation

Note: For use with a PlayStation 4 game console or

computer, the U357-1M2-NVMEG2 must be

used with the included USB cable (M/F).

21-10-337 9340FC.indb 621-10-337 9340FC.indb 6 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

Operation

21-10-337 9340FC.indb 721-10-337 9340FC.indb 7 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

Operation

When you install a new disk in the enclosure and

connect it to your PS5 console, you must format the

disk in the Storage settings. Note: Disk formatting will

erase all previous data on the disk, so proceed with

caution.

21-10-337 9340FC.indb 821-10-337 9340FC.indb 8 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

Operation

PS5 consoles only support games with PS4 attributes

to run on external disks. If you want to run games

with PS5 attributes, you must copy them to the PS5’s

built-in storage device.

21-10-337 9340FC.indb 921-10-337 9340FC.indb 9 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM

Specifications

Input Connection 2x USB-A (Male)

Output Connection 1x USB-A (Female)

Data Transfer Rates

10 Gbps (USB 3.2 Gen 2)

LED Solid White – Power On

Flashing White – Read and Write

Material Aluminum

Maximum Drive

Capacity

No capacity limit,

but PS5 requires

external devices to

be 250 Gb to 8 Tb

Operating

Temperature Range

32° to 131°F

(0° to 55°C)

Storage

Temperature Range

14° to 158°F

(-10° to 70°C)

Relative Humidity 10 to 85% RH,

Non-Condensing

Dimensions

(H x W x D)

4.7 x 1.8 x 0.6 in. /

120 x 45 x 16 mm

21-10-337 9340FC.indb 1021-10-337 9340FC.indb 10 12/3/2021 1:23:30 PM12/3/2021 1:23:30 PM
